MicroPython Workbench — MicroPython file manager for VS Code

---- fork of DanielBustillos/mpy-workbench to fix issues -----

Inspired by Thonny’s simplicity, this extension streamlines MicroPython development across multiple boards. It provides remote file management, an integrated REPL, and automatic two-way synchronization, enabling a smoother workflow within VS Code.

The extension leverages mpremote for all board interactions, including file transfer, REPL connectivity, and command execution.

Main features

• 📂 Remote file explorer for the device (open, download files/folders, upload, rename, delete)
• 🔄 Two-way sync: compare local files with the device and sync changed files
• 📝 Create a new file in the Files view and upload it to the board on first save
• 💽 Flash MicroPython firmware via esptool with board auto-detection (catalog driven)
• 💻 Integrated MicroPython REPL terminal
• ⏯️ Send commands to the board (stop, soft reset, etc.)
• 🧭 Files view shows the detected board name and status bar displays last auto-sync time

⚡ Connect to board and run a file

🔄 Autosync local folder contents

Sync utilities

These commands perform full or incremental synchronization between your local workspace and the connected MicroPython board:

• Check for differences: Lists new, changed, or deleted files between local and board.
• Sync Local → Board: Uploads only local files that are new or modified.
• Sync Board → Local: Downloads only board files that are new or modified.
• Upload all Local → Board: Uploads all non-ignored local files to the device.
• Download all Board → Local: Downloads all board files, overwriting local copies.
• Delete all files on board: Removes all files on the device.

Useful commands (Command Palette)

• MPY Workbench: Refresh — refresh the file tree
• MPY Workbench: Check files differences — show diffs and local-only files
• MPY Workbench: Sync changed Files (Local → Board) — upload changed local files
• MPY Workbench: Sync changed Files (Board → Local) — download changed board files
• MPY Workbench: Sync all files — full upload or download
• MPY Workbench: Upload Active File — upload the current editor file
• MPY Workbench: Select Serial Port — pick device port
• MPY Workbench: Open REPL Terminal — open MicroPython REPL
• MPY Workbench: Flash MicroPython Firmware — flash firmware using the bundled catalog and esptool
• MPY Workbench: Toggle workspace Auto-Sync on Save — enable/disable workspace auto-sync

Workspace config

The extension stores per-workspace settings and manifests inside a workspace folder named .mpy-workbench at your project root.

• Workspace override file: .mpy-workbench/config.json
• Sync manifest: .mpy-workbench/esp32sync.json

Use the command MicroPython WorkBench: Toggle workspace Auto-Sync on Save to enable or disable auto-sync for the current workspace. If no workspace config exists the extension falls back to the global setting microPythonWorkBench.autoSyncOnSave (default: false).

Auto-suspend and REPL restore

• microPythonWorkBench.serialAutoSuspend (default: true): closes REPL/Run terminals before file ops to avoid port conflicts, then restores what was open afterward (re-runs Run Active File, or reopens REPL).
• microPythonWorkBench.replRestoreBehavior (default: none): what to do when REPL is restored after auto-suspend/auto-sync:
  • runChanged: Auto run the changed/saved file in REPL after sync.
  • executeBootMain: send Ctrl-D so boards that auto-run main.py/boot.py after reset will restart.
  • openReplEmpty: reopen the REPL without sending anything.
  • none: do not reopen the REPL.

Status indicators

• Status bar shows MPY: AutoSync ON/OFF, a cancel-all-tasks button, and MPY: LastSync <time> after each auto-sync run.
• Files view header displays the detected board name/ID once a fixed serial port is selected.

Requirements

• Python 3.13.2
• Mpremote v1.26.1
• Firmware flashinOk.g: esptool available in the same Python environment. Install with pip install esptool. The extension checks python, py -3 (Windows), and esptool.py/esptool on PATH.
• The Python path used by the extension can be adjusted in the extension settings if a specific interpreter needs to be selected.

Firmware flashing

• Choose a specific serial port (not auto), then run MicroPython WorkBench: Flash MicroPython Firmware from the Command Palette or Board Actions view.
• The extension detects the board, picks the matching entry from assets/firmwareCatalog.json, downloads the image, and runs esptool at 460800 baud.
• Put the board in bootloader mode first; the REPL is automatically closed during flashing to free the port.
• Add more boards by appending entries to assets/firmwareCatalog.json (chip, flash mode/freq, offset, download URL, and aliases).

Next steps

• ✅ Broaden board compatibility (currently tested only with ESP32-S3 and ESP32-C3)
• 🔌 Expand the firmware catalog beyond the initial ESP32-C6 entry
• 🪟 Perform full Windows testing: validate mpremote compatibility with COM ports and ensure consistent behavior of file operations and REPL across Windows environments

Contributing

Issues and pull requests are welcome.

License

MIT — see the LICENSE file in this repository.
