VSay Remote Machines - VS Code Extension

Connect to your VSay managed machines directly from VS Code with WebSocket tunneling or SSH!

Features

• 🖥️ Machine Explorer - View all your VSay machines in the sidebar
• 🌐 WebSocket Tunneling - Connect without SSH using existing agent connection (NEW!)
• 🔌 SSH Connection - Traditional Remote-SSH connection support
• 📊 Resource Monitoring - See CPU, memory, and disk usage
• 🔄 Auto-Refresh - Keep your machines list up to date
• 💻 Integrated Terminal - Open SSH terminal directly in VS Code
• 📋 Copy IP - Quick copy machine IP addresses
• ⚡ Auto VS Code Server - Automatically installs VS Code server on remote machines

Prerequisites

1. VS Code version 1.80.0 or higher
2. VSay Backend running and accessible
3. VSay Agent installed on remote machines
4. (Optional) Remote-SSH Extension - Only needed for SSH-based connections

Installation for Development/Testing

Step 1: Install Dependencies

cd /Users/yesveer/Downloads/Yesveer-Dev/Laptops\ on\ Internet/vsay-vscode-extension
npm install

Step 2: Compile TypeScript

npm run compile

Step 3: Test in VS Code

1. Open the extension folder in VS Code:

   code /Users/yesveer/Downloads/Yesveer-Dev/Laptops\ on\ Internet/vsay-vscode-extension


2. Press F5 to open a new VS Code window with the extension loaded

3. In the new window, you'll see "VSay Machines" in the Activity Bar

Step 4: Configure API URL

1. Open VS Code Settings (Cmd+, on macOS)
2. Search for "VSay"
3. Set VSay: Api Url to your backend URL (default: http://localhost:8080)

Step 5: Login

1. Click the VSay icon in the Activity Bar
2. Click "Login to VSay" or use command palette (Cmd+Shift+P) → "VSay: Login to VSay"
3. Enter your email and password

Usage

View Machines

• Click the VSay icon in the Activity Bar
• All your machines will be listed with:
  • Status indicator (green = online, red = offline)
  • IP address
  • OS information
  • Resource usage (hover to see details)

Connect to Machine (WebSocket - Recommended)

1. Click the radio tower icon (📡) next to an online machine
2. VS Code server will be automatically installed on the remote machine
3. Connection established via existing WebSocket tunnel (no SSH configuration needed!)

Benefits:

• No SSH setup required
• Uses existing vsay-agent connection
• Automatic VS Code server installation
• Works through firewalls (uses existing agent tunnel)

Connect to Machine (SSH - Alternative)

1. Click the plug icon (🔌) next to an online machine
2. Enter SSH username when prompted
3. VS Code will open a new window connected via Remote-SSH

Note: Requires SSH access and Remote-SSH extension

Open Terminal

1. Click the terminal icon next to an online machine
2. Enter SSH username when prompted
3. An integrated terminal will open with SSH connection

Refresh Machines

• Click the refresh icon in the view title
• Or use command palette → "VSay: Refresh Machines"

Add New Machine

• Click the + icon in the view title
• Browser will open to your VSay portal's Add Machine page

Configuration

Access settings via Cmd+, → Search "VSay"

Available Settings

• vsay.apiUrl - VSay API server URL (default: http://localhost:8080)
• vsay.autoRefresh - Auto-refresh machines list (default: true)
• vsay.refreshInterval - Refresh interval in seconds (default: 30)

Development Commands

# Compile TypeScript
npm run compile

# Watch mode (auto-compile on save)
npm run watch

# Lint code
npm run lint

# Package extension
npm run package

Building for Production

To create a .vsix file for distribution:

# Install vsce (VS Code Extension Manager)
npm install -g @vscode/vsce

# Package the extension
npm run package

This creates a .vsix file that can be installed in VS Code:

• Go to Extensions view
• Click "..." menu → "Install from VSIX..."
• Select the generated .vsix file

SSH Configuration

The extension automatically manages SSH configuration in ~/.ssh/config:

• Each machine is added as Host vsay-{agent_id}
• Configurations include IP, username, and SSH options
• Manual SSH connections are also possible: ssh vsay-{agent_id}

Troubleshooting

Extension Not Loading

1. Check VS Code version (should be 1.80.0+)
2. Run npm run compile to rebuild
3. Check Output panel (View → Output → Select "VSay Remote Machines")

Login Failed

1. Verify API URL in settings
2. Check backend is running
3. Verify credentials are correct

SSH Connection Failed

1. Ensure Remote-SSH extension is installed
2. Check machine is online
3. Verify SSH access to machine
4. Check ~/.ssh/config for correct entries

Machines Not Showing

1. Click refresh button
2. Check you're logged in
3. Verify API connection in settings

Architecture

src/
├── extension.ts        # Main entry point, activation logic
├── authService.ts      # Authentication with VSay backend
├── machineProvider.ts  # TreeView data provider for machines
└── sshService.ts       # SSH connection handling

Contributing

1. Make changes in src/ directory
2. Run npm run compile to build
3. Press F5 to test in Extension Development Host
4. Test all features before submitting

License

MIT

Support

For issues and feature requests, please contact the VSay team.
