Variable Explorer for VS Code

A powerful variable inspection and editing tool for Python development in Visual Studio Code, inspired by Spyder's Variable Explorer.

Features

Variable Inspection

• Real-time variable tracking: Automatically displays all variables in your Python namespace
• Type information: Shows the type, size, and value of each variable
• Collection support: Inspect lists, tuples, dicts, DataFrames, Series, and more
• Sortable columns: Click column headers to sort by name, type, size, or value
• Smart filtering: Filter variables by name with the built-in search function
• Exclude patterns: Hide private variables, uppercase constants, and more with customizable filters

Interactive Data Views

• List and Tuple exploration: Click on any list or tuple to view its contents in a detailed modal
• Dictionary navigation: Click through nested dictionaries to explore complex JSON-like structures
• Advanced DataFrame viewer: Professional table view for pandas DataFrames with:
  • Custom index preservation: Named, numeric, and datetime indices display correctly
  • Smart pagination: Handle DataFrames with thousands of rows (50/100/250/500/All rows per page)
  • Real-time search/filter: Search across all columns as you type to filter rows instantly
  • CSV export: Export DataFrames (or filtered results) to CSV with one click
  • Auto-sizing columns: Column widths adapt to header text length for better readability
  • Type tooltips: Hover over column headers to see data types
  • Sortable columns: Click any column (including index) to sort
  • NaN styling: Missing values are clearly marked with italic + dimmed style
• NumPy array visualization: Interactive heatmap visualization for 1D and 2D arrays with customizable formatting
• Breadcrumb navigation: Track your path through nested structures with clickable breadcrumbs

Inline Editing

• Scalar editing: Double-click numbers, strings, and booleans to edit them inline
• Long string editor: Strings longer than 40 characters open in a modal text editor
• Type-safe updates: Automatic type validation when editing variables
• Real-time updates: Changes are immediately reflected in your Python namespace

Modern Interface

• VSCode theme integration: Automatically matches your VSCode theme
• Color-coded types: 33 distinct colors for different data types with 3 beautiful themes (Default, Warm, Cold)
• Resizable columns: Drag column borders to resize or auto-fit to content
• Modal popups: Clean, focused views for exploring complex data
• Custom branding: Beautiful logo integration in empty states and tab icons
• Empty state: Clean, minimalist view when no variables are defined

Installation

1. Install from the VS Code Marketplace
2. Search for "Variable Explorer" in the Extensions view
3. Click Install

Usage

Opening the Variable Explorer

Use the command palette (Cmd+Shift+P / Ctrl+Shift+P) and run:

• "Show Variable Explorer" - Opens the Variable Explorer panel

Running Python Code

The Variable Explorer works with Python code executed through:

• Run File: Execute an entire Python file (F5)
• Run Code: Execute selected Python code (F9 or Shift+Enter)
• The extension maintains a persistent Python namespace across executions

Inspecting Variables

View all variables:

• All variables in the current namespace are displayed in the main table
• Click the refresh button to update the variable list

Search and filter:

• Click the search icon to filter variables by name
• Use the options menu to exclude private variables, uppercase constants, callables, modules, and more
• Choose from 3 color themes (Default, Warm Sunset, Cold Ocean) to match your preference

Explore collections:

• Lists/Tuples: Click on the value to see all items
• Dictionaries: Click to view key-value pairs, then click nested values to drill down
• DataFrames: Click to see a professional table view with:
  • Custom indices (named, datetime, numeric) preserved and displayed
  • Pagination controls for large DataFrames (up to thousands of rows)
  • Column headers that auto-size to their content
  • Sortable columns including the index column
  • Data type information on hover
• NumPy Arrays: Click to view interactive heatmap visualization with color-coded values
• Nested structures: Use breadcrumb navigation to move back up the hierarchy

Sort data:

• Click any column header in the main table or modals to sort
• Click again to toggle between ascending/descending order

Resize columns:

• Drag column borders to manually resize
• Use the options menu to auto-fit rows or columns to content

Editing Variables

Short strings, numbers, and booleans:

1. Double-click the value cell
2. Edit the value inline (cell turns grey)
3. Press Enter to save or Escape to cancel

Long strings (>40 characters):

1. Double-click the value cell
2. Edit in the modal text editor
3. Click "Save" or press Cmd+S / Ctrl+S

Supported types for editing:

• int, float, complex - Any numeric value
• bool - true, false, 1, 0, yes, no
• str - Any text value

Managing Variables

Clear all variables:

• Click the trash icon in the toolbar to clear the namespace
• This removes all user-defined variables (built-ins are preserved)

Refresh:

• Click the refresh icon to update the variable list

Keyboard Shortcuts

Data Type Support

Variable Explorer supports 33+ data types with distinct color coding:

Basic Types

• int, float, complex - Numeric values
• Decimal, Fraction - High-precision numbers
• str - Strings
• bool - Booleans
• NoneType - None values

Collection Types

• list, tuple - Sequences
• dict, OrderedDict, defaultdict, Counter - Dictionaries (with nested navigation)
• set, frozenset - Sets
• deque - Double-ended queues

Scientific Computing

• numpy.ndarray - NumPy arrays (with heatmap visualization)
• pandas.DataFrame - DataFrames (with table view)
• pandas.Series - Series
• torch.Tensor - PyTorch tensors
• tensorflow.Tensor - TensorFlow tensors
• JAX arrays

Special Types

• Path, PurePath - File paths
• UUID - Unique identifiers
• Pattern - Regex patterns
• datetime, date, timedelta - Date/time objects
• range, enumerate, zip - Iterables
• Generator objects
• bytes, bytearray, memoryview - Binary data
• Exception types
• Functions, classes, and modules

Configuration

The extension uses your default Python interpreter configured in VS Code:

{
  "python.defaultInterpreterPath": "/path/to/python"
}

Tips & Tricks

1. DataFrame Search: Type in the search box to instantly filter DataFrame rows across all columns
2. Export Filtered Data: Search for specific rows, then click the export icon to save only those rows to CSV
3. Nested dictionaries: Click through JSON-like structures by clicking on dict/list values in the modal
4. DataFrames with custom indices: Use df.set_index('column_name') and the index will be preserved with the correct name
5. Large DataFrames: All rows and columns are loaded - use pagination to navigate or search to filter
6. Wide DataFrames: Scroll horizontally to see all columns, or use search to find specific data
7. DataFrame navigation: Change rows per page (50/100/250/500/All) using the dropdown in pagination controls
8. main() function locals: Enable "Capture main() locals" in settings to inspect variables inside your main() function
9. Large strings: Use the modal editor for multi-line strings and better formatting
10. Type preservation: Edited values maintain their original type
11. Breadcrumbs: Click any part of the path to jump back to that level
12. Variable Search: Use the main search function to quickly find specific variables in large namespaces
13. Filters: Exclude private variables and other patterns to focus on relevant data
14. Color Themes: Choose from 3 visual color palette themes to personalize your type color-coding

Troubleshooting

Variables not showing:

• Ensure you've run Python code first
• Click the refresh button
• Check that Python is properly configured

Edit not working:

• Verify the variable type is supported for editing
• Check for validation errors in VS Code notifications

Modal not closing:

• Click outside the modal or press Escape
• Click the X button in the modal header

Requirements

• Visual Studio Code 1.80.0 or higher
• Python 3.6 or higher
• pandas (for DataFrame support)
• numpy (for NumPy array support)

Contributing

Contributions are welcome! Please feel free to submit issues or pull requests.

License

MIT License - See LICENSE file for details

Changelog

Version 0.1.9 (Latest)

• Critical Backend Fix: Fixed "Python backend not started" error when refreshing Variable Explorer
• Backend Persistence: Python backend now persists when webview panel is closed
• Improved Error Handling: Better error messages and status checks in refresh command
• Race Condition Prevention: Enhanced synchronization when running code before backend fully starts
• Auto-Recovery: Refresh now automatically attempts to restart backend if it's not running
• UI Fix: Corrected search button placement in toolbar header

Version 0.1.8

• UI Fix: Fixed search button placement in toolbar header

Version 0.1.7

• DataFrame Search/Filter: Real-time search across all DataFrame columns with instant filtering as you type
• CSV Export: Export entire DataFrames or filtered results to CSV files with one click
• Performance Improvements: Optimized JSON handling for DataFrames with 1000+ columns
• Visual Enhancements: New color palette selector with visual swatches instead of text labels
• Fixed Modal Footer: Pagination controls now stay visible in a fixed footer, not affected by horizontal scrolling
• Improved UX: All rows and columns are now loaded by default (no artificial limits)
• Bug Fixes: Fixed buffer overflow issues with very wide DataFrames

Version 0.1.6

• DataFrame Index Preservation: Custom indices (named, numeric, datetime) are now correctly preserved and displayed
• Index Name Display: Index column header shows the actual index name instead of always "Index"
• Unlimited Rows: Removed 100-row limit for DataFrames - now supports thousands of rows with smart pagination
• Smart Pagination: Navigate large DataFrames with First/Prev/Next/Last buttons and adjustable rows per page (50/100/250/500/All)
• Auto-sizing Column Headers: Column widths automatically adapt to header text length for better readability
• Improved NaN Display: NaN values now styled with italic text and dimmed opacity for clarity
• Column Type Tooltips: Hover over DataFrame column headers to see data types
• Enhanced Sorting: Sort by any column including custom index columns
• Subtle Pagination UI: Redesigned pagination controls with minimal, VS Code-native styling
• main() Locals Capture: New setting to expose local variables from main() function (disabled by default)
• Performance: Optimized rendering for wide DataFrames with 50+ columns

Version 0.1.5

• Sponsorship Support: Added Buy Me a Coffee integration for users who want to support development
• Sponsor Command: New "Support Variable Explorer" command accessible via Command Palette
• Enhanced Documentation: Updated README with support badges and links

Version 0.1.4

• Enhanced Type Support: Added support for 33+ data types including PyTorch/TensorFlow tensors, Path objects, UUID, Decimal, Fraction, and more
• Color Themes: Three beautiful color palettes (Default, Warm Sunset, Cold Ocean) for type color-coding
• NumPy Array Visualization: Interactive heatmap viewer for 1D and 2D arrays with customizable formatting
• Improved Branding: Updated logo integration in empty states and tab icons
• Bug Fixes: Fixed modal display issues when switching between DataFrames and arrays
• Performance: Optimized type detection and color application

Version 0.1.3

• Added extension icon and branding
• Improved marketplace presence

Version 0.1.2

• Initial marketplace release
• Core variable inspection and editing features

Support

If you find Variable Explorer useful, consider supporting its development:

Your support helps maintain and improve this extension!

Acknowledgments

Inspired by the Spyder Variable Explorer, bringing similar functionality to VS Code.
