ISO GQL Language Support by Ultipa

The VS Code extension specifically designed for ISO/IEC 39075 Graph Query Language standard

This extension provides complete syntax highlighting, autocomplete, hover documentation, and intelligent language features for ISO GQL files.

🆕 What's New in v0.2.2

• ISO GQL File Icons: Dedicated transparent icon theme for .gql files with graph structure design
• Dual Comment Support: Both -- (SQL-style) and // (C-style) line comments are now supported
• Enhanced Documentation: Improved CLAUDE.md with detailed architecture and development guidelines

See CHANGELOG.md for complete version history.

🎯 Features

⚡ ISO Standard Compliant: Built from the official ISO/IEC 39075 specification, not generic GraphQL 📁 Dedicated .gql File Support: Specifically designed for .gql files (not .graphql)
🗄️ Session & Transaction Support: Full highlighting for session management and transaction control commands 🤖 IntelliSense Support: Auto-completion, hover documentation, and function signatures 🔧 HDC Operations: Heterogeneous Distributed Computing server management ⚙️ EXEC Procedures: Procedure execution with graph context support

🚀 Advanced Language Features

• ISO GQL Keywords: Complete SESSION, TRANSACTION, MATCH, INSERT command support (399+ keywords)
• Graph Pattern Matching: Advanced node, edge, and path pattern recognition with quantifiers
• Session Management: SET/RESET/CLOSE session commands with parameter binding
• Transaction Control: START TRANSACTION, COMMIT, ROLLBACK support
• Property Graph Constructs: Native support for nodes, edges, and graph expressions
• Advanced Functions: Aggregation, scalar, string, temporal, mathematical, and predicate functions (60+ functions)
• HDC Operations: Distributed computing with HDC servers, graphs, and algorithms
• EXEC Procedures: Procedure calls with optional graph context and parameter passing

Supported Language Features

Core Query Language

• Graph pattern matching (MATCH, OPTIONAL MATCH, WHERE, RETURN)
• Data manipulation (INSERT nodes/edges, DELETE, REMOVE, SET properties)
• Path quantifiers with correct GQL syntax: ((pattern)){1,5}, pattern*, pattern+
• Path modes: SHORTEST, ACYCLIC, SIMPLE, TRAIL, WALK
• Variable assignment with LET (not WITH - GQL doesn't use WITH for query composition)
• Filtering with FILTER statements

Data Definition & Schema

• Schema operations (CREATE/DROP SCHEMA, GRAPH, INDEX, USER, ROLE)
• Property graph management
• Type definitions and constraints
• CAST operations for type conversion

Session & Transaction Management

• Session commands (SESSION SET/RESET/CLOSE)
• Transaction control (START TRANSACTION, COMMIT, ROLLBACK)
• Parameter binding and configuration

Advanced Operations

• HDC (Heterogeneous Distributed Computing): Server management, graph distribution, algorithm execution
• EXEC Procedures: Procedure calls with graph context and parameter passing
• Set operations (UNION, INTERSECT, EXCEPT)
• Grouping and aggregation (GROUP BY, HAVING)
• System commands (SHOW, EXPLAIN, PROFILE, DEBUG)

Functions & Expressions

• Mathematical: ABS, CEIL, FLOOR, ROUND, LOG, EXP, POWER, SQRT, trigonometric functions
• String: UPPER, LOWER, TRIM (LEADING/TRAILING/BOTH), SUBSTRING, REPLACE, LENGTH functions
• Temporal: DATE, TIME, TIMESTAMP, DURATION operations
• Aggregation: COUNT, SUM, AVG, MIN, MAX, COLLECT_LIST, statistical functions
• Graph: ELEMENT_ID, PROPERTY_EXISTS, PATH_LENGTH, SAME, DIFFERENT
• Utility: COALESCE, NULLIF, SIZE, CARDINALITY

Installation

Install this extension from the VS Code Marketplace:

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "ISO GQL Language Support by Ultipa"
4. Click Install

Usage

Basic Usage

Simply open any .gql file in VS Code and enjoy comprehensive language support:

• Syntax Highlighting: All ISO GQL keywords, functions, and operators are highlighted
• Auto-completion: Type keywords and get intelligent suggestions with documentation
• Hover Documentation: Hover over functions and keywords to see detailed descriptions
• Function Signatures: Get parameter hints when typing function calls

Comment Styles

ISO GQL supports multiple comment styles:

-- SQL-style line comment (press Ctrl+/ or Cmd+/ to toggle)
// C-style line comment (also supported)
/* Block comment
   spanning multiple lines */

Example GQL Code

-- Session and transaction management
SESSION SET SCHEMA company_database;
START TRANSACTION READ WRITE;

// Graph pattern matching with path quantifiers
MATCH path = ((person:Person)-[r:KNOWS]->(friend:Person)){1,3}
WHERE person.name = "Alice"
LET relationship_strength = AVG(r.weight)
RETURN person, friend, relationship_strength
ORDER BY relationship_strength DESC;

// HDC operations
HDC ADD SERVER "server1" WITH CONFIG "hdcConfig.json";
EXEC PROCEDURE analyze_network() WITH GRAPH social_network;

COMMIT;

Using ISO GQL File Icons

This extension provides a dedicated file icon theme for .gql files to distinguish them from GraphQL files:

1. Press Ctrl+Shift+P (or Cmd+Shift+P on Mac)
2. Type "Preferences: File Icon Theme"
3. Select "ISO GQL File Icons" from the list
4. Your .gql files will now display the ISO GQL icon in the file explorer

Note: If you're using another icon theme (like Material Icon Theme), it will take precedence. The language icon in the status bar and breadcrumbs will always show the ISO GQL icon when a .gql file is open.

Key Differences from Cypher/Neo4j

• Use INSERT for creating nodes/edges (not CREATE)
• Use LET for variable assignment (not WITH)
• Path quantifiers apply to entire patterns: ((pattern)){1,5}
• CREATE is only for schemas, graphs, indexes, users, roles
• No WITH clause for query composition

Contributing

Found a bug or have a feature request? Please open an issue on our GitHub repository.

Resources

• ISO/IEC 39075 GQL Standard
• Ultipa Graph Database
• Extension Documentation
• Changelog

License

MIT

Publisher

Ultipa - Leading Graph Database Technology Provider

Enjoy using ISO GQL Language Support! If you find this extension helpful, please consider rating it on the VS Code Marketplace.
