Skir Language Support for Visual Studio Code

This extension provides language support for the Skir language - a declarative language for representing data types, constants and APIs (similar to Protocol Buffer).

Website: https://skir.build

Features

• Syntax highlighting for .skir files
• Diagnostics — lexical, parse, type and breaking-change errors shown inline
• Go to definition — navigate to any symbol or imported module
• Hover documentation — shows the doc comment of a record, field, method or constant
• Find all references — lists every usage of a symbol across the workspace
• Rename symbol — renames a symbol and all its references in one step (local symbols only)
• Auto-completion — context-aware suggestions for field names, types, constants and more
• Automatic imports — suggests symbols from other modules and inserts the import statement automatically
• Format on save and on-demand formatting
• Import updates on file rename/move — when a .skir file is renamed or moved, the extension offers to update all import statements that reference it
• Comment toggling — line (//) and block (/* */) comments
• Bracket matching and auto-closing pairs

Skir Language

Skir is a language for representing data types, constants and APIs. It is designed for systems where different services are written in different languages but need to exchange structured data.

Example:

// shapes.skir

struct Point {
  x: int32;
  y: int32;
  label: string;
}

struct Shape {
  points: [Point];
  /// A short string describing this shape.
  label: string;
}

const TOP_RIGHT_CORNER: Point = {
  x = 600,
  y = 400,
  label = "top-right corner",
};

/// Returns true if no part of the shape's boundary curves inward.
method IsConvex(Shape): bool = 12345;

Go to Definition

Navigate to the definition of any symbol or import path:

• Place the cursor on a symbol name or an import path and press F12 (or right-click → Go to Definition).
• Works across files within the same Skir workspace.

Hover Documentation

Hovering over a record, field, method or constant shows the doc comment attached to that declaration.

Find All References

Place the cursor on any symbol and press Shift+F12 (or right-click → Find All References) to see every location in the workspace that references it.

Rename Symbol

Place the cursor on a symbol name and press F2 (or right-click → Rename Symbol) to rename it and all its references atomically. Renaming is only supported for symbols defined in the current workspace; symbols from external dependencies cannot be renamed.

Diagnostics

The extension continuously validates your files and reports errors in the Problems panel:

• Lexical and parse errors — syntax mistakes in .skir files.
• Type errors — unknown types, missing fields, etc.
• Breaking changes — when a skir-snapshot.json is present, any change that would break existing consumers (e.g. removed fields, changed types) is highlighted as a warning.
• Dependencies out of sync — a warning on skir.yml when the installed packages do not match the declared versions; run npx skir gen to fix.

Auto-Completion

Press Ctrl+Space (or ⌃Space on macOS) at any point in a .skir file to get context-aware suggestions:

• Field names and their expected types inside struct or constant literals.
• Type names (records, enums) visible in the current scope.
• Import paths when writing an import statement.

Suggestions are derived from the current state of all modules in the workspace, so they stay up to date as you edit.

Automatic Imports

When you press Ctrl+Space on an unqualified symbol name, the extension also suggests symbols from modules that are not yet imported in the current file. Selecting such a suggestion automatically inserts the corresponding import statement at the top of the file:

import { Point } from "geometry.skir";

Formatting

Documents are formatted automatically on save. You can also trigger formatting manually with Shift+Alt+F (or right-click → Format Document).

Import Updates on File Rename / Move

When you rename or move one or more .skir files (for example via the VS Code Explorer), the extension detects that other files in the same workspace may have import statements pointing to the old path. It then shows a prompt:

Update imports in N file(s)? — Update Imports / Skip

Choosing Update Imports rewrites the import block in every affected file so that paths reflect the new file location. The update is applied atomically as a single workspace edit, so it can be undone in one step with Ctrl+Z.

This also handles bulk operations: if several files are moved together (e.g. an entire directory), cross-references between the moved files are updated correctly, in addition to references from files that stayed in place.

Requirements

No special requirements for this extension.
