Tyhp Language Support for VS Code / Cursor

Syntax highlighting and a Language Server Protocol client for .tyhp and .tyhpdef files, plus a standalone PHP grammar, Tyhp CLI discovery / install, workspace/tyhp.json awareness, build/lint tasks, XDebug proxy debugging, and a status bar.

Product: Tyhp Language (tyhp-lang). Publisher: Tyhp. Extension ID: Tyhp.tyhp.

This extension is installed locally (symlink, copy, or sideload VSIX). Publishing to the VS Code Marketplace or Open VSX is a separate step from building the VSIX.

Local QA: the repeatable sideload / packaging / editor checklist is QA.md. It is a human matrix plus notes on what this repo’s unit tests already cover — not a claim that every GUI item was clicked in this environment.

Features

• Tyhp language (source.tyhp) — full standalone grammar for .tyhp and .tyhpdef files:
  • Optional <?tyhp / <?tyhpdef open tags (tagless files highlight as Tyhp code from line 1)
  • Classic mode with open/close tags for inline HTML interleaving
  • async / await
  • struct, extension, type alias declarations
  • operator overload declarations (arithmetic, comparison, conversion)
  • using blocks and := using-assignment
  • is type checks
  • typeof, nameof, variable_exists expressions
  • deprecated, obsolete modifiers
  • decimal type and (decimal) cast
  • with keyword
  • Generic type parameters (<T>, <T extends Type>, nested generics)
  • Constructor delegation (: parent(...), : void)
  • Type interpolation in strings ("${TypeName}", "${A|B}", "${Type+}")
• File icons for .tyhp and .tyhpdef (light/dark language icons; optional Tyhp File Icons theme with default/light/high-contrast variants and distinct .tyhp vs .tyhpdef glyphs)
• Tyhp CLI — find tyhp on PATH, install from GitHub Releases (global or extension-only), and keep an extension-only binary updated or pinned
• Language server — launches one tyhp language_server per owned tyhp.json over stdin/stdout using the resolved CLI (at most tyhp.languageServer.maxSessions, default 8). A project owns a file when that file matches its include / exclude globs (same rules as tyhp build, including ../ overlays). Servers start when you open an owned file and stop when that project has no open Tyhp documents or is evicted for the cap. Files that match no project stay TextMate-only. Diagnostics, hover, go-to-definition, completion, and the rest of the language server features appear through the standard VS Code Language Client. Logs: Output panel > Tyhp Language Server. Trace: tyhp.languageServer.trace.
• Workspace — indexes every tyhp.json under the workspace (or the single file forced by tyhp.projectPath). The status bar, tasks, and XDebug proxy follow the active editor’s owner. Opening a Tyhp file with no owner and no ancestor tyhp.json offers Tyhp: Initialize Project (tyhp init --yes).
• Tasks — tyhp: build and tyhp: lint run against the resolved CLI and pass --tyhp-project when a project file is known. Lint uses --format=json.
• XDebug proxy — start/stop tyhp xdebug_proxy and contribute a PHP Debug launch snippet that listens on the proxy IDE port so breakpoints can hit .tyhp sources. Logs: Output panel > Tyhp XDebug Proxy.
• Status bar — compact project + LSP + CLI health + XDebug proxy listening state. Click for Restart Language Server, Install CLI, Initialize Project, and Start/Stop/Restart XDebug Proxy.
• PHP (Tyhp) (source.tyhp.php) — full standalone PHP grammar, manually selectable for .php files
• Comment toggling, bracket matching ({}, [], (), <>), auto-closing pairs, folding, and indentation

Language light/dark file icons show in the explorer without changing your file icon theme. The optional Tyhp File Icons theme (File Icon Theme picker) maps .tyhp vs .tyhpdef with default, light, and high-contrast variants. It only defines Tyhp glyphs, so keep your existing theme selected unless you want those mappings.

Highlighting QA samples: samples/highlight-audit.tyhp, samples/highlight-audit.tyhpdef, and samples/highlight-audit.md.

Development (compile + F5)

The extension has a TypeScript entry point (src/extension.ts). Language contributions (TextMate grammars) load from package.json regardless; compiling is required so main can activate without an error.

From this directory (vscode/):

npm install
npm run compile
npm test

npm run package compiles, then esbuild-bundles src/extension.ts (including vscode-languageclient) into out/extension.js so the VSIX does not need node_modules at runtime, then runs npm run check-package and fails the build if any tsc per-module out/<folder>/*.js would be packed. Run npm run check-package on its own to re-check an existing build without repackaging.

F5 (Extension Development Host): open this folder (vscode/) as the workspace in VS Code or Cursor, then press F5. That uses .vscode/launch.json (Run Extension). The first launch compiles/watches via .vscode/tasks.json.

To package a local VSIX (does not publish):

npm run package
# or: npx vsce package

Local Installation

Option 1: Symlink (recommended for development)

Changes to the grammar are picked up on each window reload — no reinstall needed. Run npm install and npm run compile in this folder so out/extension.js exists.

Important: The symlink target must be an absolute path (e.g. /Users/you/repos/tyhp-ide-plugin/vscode). Do not use a relative path like ./vscode — ln -s resolves relative targets from the extensions directory, not your current shell directory, which creates a broken self-referential symlink.

The symlink must also use Cursor/VS Code's expected folder name: {publisher}.{name}-{version} (from package.json). For this extension that is Tyhp.tyhp-<version> — currently Tyhp.tyhp-0.8.2.

If you previously installed as tyhp-lang.tyhp-language-<version> (old folder / old name) or tyhp-lang.tyhp-0.8.1 / 0.7.0 / 0.5.0, remove that install first.

From the clone root (tyhp-ide-plugin):

rm -rf ~/.cursor/extensions/Tyhp.tyhp-0.8.2   # Cursor
ln -s "$(pwd)/vscode" ~/.cursor/extensions/Tyhp.tyhp-0.8.2

rm -rf ~/.vscode/extensions/Tyhp.tyhp-0.8.2  # VS Code
ln -s "$(pwd)/vscode" ~/.vscode/extensions/Tyhp.tyhp-0.8.2

Or use an explicit absolute path:

Cursor:

rm -rf ~/.cursor/extensions/Tyhp.tyhp-0.8.2
ln -s "/path/to/tyhp-ide-plugin/vscode" ~/.cursor/extensions/Tyhp.tyhp-0.8.2

VS Code:

rm -rf ~/.vscode/extensions/Tyhp.tyhp-0.8.2
ln -s "/path/to/tyhp-ide-plugin/vscode" ~/.vscode/extensions/Tyhp.tyhp-0.8.2

Then fully quit and reopen Cursor/VS Code (Cmd+Q, not just "Reload Window"). If you previously had a broken install, also remove the extension from ~/.cursor/extensions/.obsolete if it lists tyhp-lang.tyhp-0.8.1, tyhp-lang.tyhp-0.8.0, tyhp-lang.tyhp-0.6.0, tyhp-lang.tyhp-0.5.0, tyhp-lang.tyhp-0.4.0, tyhp-lang.tyhp-0.3.1, or tyhp-lang.tyhp-language-0.2.1.

Option 2: Sideload a VSIX

Build the VSIX from vscode/ (requires npm install once):

cd vscode
npm install
npm run package

vsce package writes tyhp-0.8.2.vsix in this folder. Sideload it — this does not publish to the Marketplace:

Cursor:

cursor --install-extension tyhp-0.8.2.vsix

VS Code:

code --install-extension tyhp-0.8.2.vsix

You can also use Install from VSIX… in the Extensions view (… menu).

A global vsce is optional; npm run package uses the local @vscode/vsce devDependency. Equivalent:

npx vsce package

Option 3: Copy to extensions directory

From the clone root, compile first (npm run compile inside vscode/), then copy. The folder name must be Tyhp.tyhp-<version>:

Cursor:

cp -r vscode ~/.cursor/extensions/Tyhp.tyhp-0.8.2

VS Code:

cp -r vscode ~/.vscode/extensions/Tyhp.tyhp-0.8.2

Then fully quit and reopen the editor.

Tyhp CLI binary

The extension locates a tyhp executable and records it in tyhp.path. The language server, tasks, and the XDebug proxy use the same resolution API (resolveTyhpBinary()) rather than reading the setting ad hoc.

Discovery

1. If tyhp.path is set, that value wins (absolute path, ~/…, or a command name on PATH). A missing or non-file path shows an error on the status bar; click it or run Tyhp: Install / Update CLI.
2. If tyhp.path is empty, activation and Tyhp: Refresh Tyhp binary search PATH for tyhp / tyhp.exe. A hit writes tyhp.path (User settings by default; Workspace / folder scope if that override already exists).

Install / Update

Tyhp: Install / Update CLI downloads an official compiler binary from GitHub Releases:

After a successful install, tyhp.path and tyhp.binary.installMode (path | global | extension) are updated.

tyhp.binary.pinnedVersion (extension-only): if non-empty, install/keep that GitHub tag and do not auto-update to other versions. Tags may omit the leading v (805.1.0-beta.1 = v805.1.0-beta.1).

Startup auto-update is delayed ~5s and skipped when a check ran in the last 6 hours (pin enforcement still runs).

Release artifacts

Source: GitHub Releases for tyhpproject/tyhp — the same assets as scripts/install.sh / scripts/release.sh.

• API: GET https://api.github.com/repos/tyhpproject/tyhp/releases?per_page=20 (first non-draft, including prereleases). Do not use /releases/latest (it hides prereleases). A pin uses /releases/tags/{tag}.
• Asset names: tyhp-{os}-{arch} or tyhp-{os}-{arch}-fxdependent, with .exe on Windows. os is osx | linux | win; arch is x64 | arm64. Published set: tyhp-osx-arm64, tyhp-osx-x64, tyhp-linux-x64, tyhp-linux-arm64, tyhp-win-x64.exe, and matching -fxdependent variants. There is no win-arm64 asset.
• Variant: Extension-only always downloads the self-contained asset. Global matches the install scripts: framework-dependent when a .NET 9 runtime is detected, otherwise self-contained.
• Checksums: each release includes checksums.txt (GNU sha256sum lines from scripts/release.sh). The download is hashed with SHA-256 and compared; a missing checksums file or mismatch aborts the install.
• Auth: optional GITHUB_TOKEN or GH_TOKEN environment variable (GitHub API rate limits).
• Missing assets: if the repo has no public compiler binaries yet, install fails with a clear error — set tyhp.path to a locally built tyhp instead.

Commands

Workspace and tyhp init

The extension indexes every tyhp.json under the workspace (**/tyhp.json, skipping node_modules, vendor, .git, bin, obj, dist, build). A file is owned by the project whose include / exclude globs match, resolved relative to that tyhp.json directory — the same Matcher rules as tyhp build. Empty include owns nothing (the repo-root tyhp.json with "include": [] is not an LSP project). Nested projects such as runtime/packages/core/tyhp.json can own both ./tyhp_src/**/*.tyhp and sibling-package paths like ../php/_tyhpdef/**/*.tyhpdef.

If several projects match, one owner is chosen (do not merge two type worlds): nearest ancestor tyhp.json, else fewest path hops, else shortest then lexicographic path.

Set tyhp.projectPath to a tyhp.json file (or a directory that contains one) to force a single project and skip scanning others. Files outside that project’s include stay TextMate-only.

If you open a .tyhp / .tyhpdef file that has no owner and no ancestor tyhp.json up to the workspace root, a prompt offers Initialize Project. An ancestor that exists but does not include the file stays silent (TextMate only). tyhp.projectPath also suppresses the prompt. The command (also in the Command Palette) runs the resolved CLI:

<resolved tyhp> init --yes

cwd is the workspace folder that contains the file (or the first folder). --yes accepts init defaults without prompting. --tyhp-project is not passed: that flag requires an existing file. After a successful init, the workspace index reloads and a language server starts when an owned file is open.

Build/lint tasks and the XDebug proxy use the active editor’s owner tyhp.json as --tyhp-project.

Tasks

Terminal → Run Task… lists:

Both use resolveTyhpBinary() (never tyhp.path directly). Build uses the $tyhp problem matcher for rustc-style file(line,col): error TYHP####: … headers. Lint JSON is shown in the terminal (VS Code problem matchers are line-based; matching the JSON document is optional).

You can also put a task in .vscode/tasks.json:

{
    "version": "2.0.0",
    "tasks": [
        {
            "type": "tyhp",
            "action": "build",
            "label": "tyhp: build"
        }
    ]
}

Status bar

The left status bar item shows Tyhp, the owner project folder name (or not in a Tyhp project), LSP ready / starting / error, CLI health, and proxy when tyhp xdebug_proxy is listening. Click it for Restart Language Server, Install / Update CLI, Reveal CLI Path, Initialize Project (when the active file has no owner), and Start / Stop / Restart XDebug Proxy. Proxy logs: Output panel > Tyhp XDebug Proxy.

Language server

Opening a .tyhp / .tyhpdef file (language id tyhp — there is no separate tyhpdef language) starts tyhp language_server for the owning tyhp.json only, as a child process over stdin/stdout:

<resolved tyhp> language_server --quiet --stdio --tyhp-project=<path-to-that-project's-tyhp.json>

A second nested project gets its own process when you open a file it owns. At most tyhp.languageServer.maxSessions servers run at once (default 8); visible editors are started first so a workspace with many tyhp.json files cannot spawn one tyhp per package. Each client’s document middleware keeps other projects’ files off that server. Files with no owner never start a server (TextMate highlighting still works).

--tyhp-project is the owner file, or the forced tyhp.projectPath when that setting is set. Extra tokens from tyhp.languageServer.args are appended after those flags.

If the CLI binary is missing, activation still succeeds. The status bar shows CLI missing and Tyhp: Install / Update CLI remains available.

If the resolved CLI is too old (language_server is missing) or the process exits before initialize completes, the client does not retry in a loop. You get one error with Install / Update CLI, Open Settings (tyhp.path), or Show Output. Point tyhp.path at a current build, then Tyhp: Restart Language Server.

If a healthy server later crashes, the client restarts it with exponential backoff, then stops after a few failures instead of toasting forever. A server that only stays up briefly does not reset that counter. Stopping the extension host stops the server (deactivate → tracked child SIGTERM/SIGKILL).

Logs and LSP traces go to Output > Tyhp Language Server. Set tyhp.languageServer.trace to messages or verbose when debugging the protocol.

Debugging .tyhp (XDebug proxy)

The extension starts tyhp xdebug_proxy so the PHP Debug extension (xdebug.php-debug) can hit breakpoints in .tyhp sources. It does not reimplement DBGp and does not replace PHP Debug.

Prerequisites

1. Enable sourcemaps in tyhp.json and build the project (maps are .php.map files next to emitted PHP, usually under output.path, default build/):

{
    "build": {
        "generateSourcemap": true
    }
}

See Source map generation and XDebug proxy.

2. Install PHP Debug (xdebug.php-debug). It is the DBGp client; this extension only launches the proxy and contributes a launch snippet.

3. Point XDebug at the proxy XDebug port (default 9004), not the IDE port:

xdebug.mode = debug
xdebug.client_host = 127.0.0.1
xdebug.client_port = 9004
xdebug.idekey = tyhp

Start the proxy

Command Palette / status bar: Tyhp: Start XDebug Proxy. Argv (resolved CLI; flags are the real CLI switches):

<resolved tyhp> xdebug_proxy --tyhp-project=<path-to-tyhp.json> --ide-port=9003 --xdebug-port=9004 [--sourcemap-dir=<dir>] [--ide-key=<key>]

Ports: explicit tyhp.xdebugProxy.idePort / xdebugPort / sourceMapDir settings win; otherwise tyhp.json xdebugProxy.*; otherwise defaults 9003 (IDE) and 9004 (XDebug). --sourcemap-dir is omitted when unset so the CLI uses output.path. Tyhp: Stop XDebug Proxy sends SIGTERM to that process and waits for it to release the ports.

launch.json

Add a PHP Debug configuration that listens on the proxy IDE port (default 9003). The extension contributes this snippet and a debug configuration provider:

{
    "name": "Listen for Tyhp (XDebug proxy)",
    "type": "php",
    "request": "launch",
    "port": 9003
}

Minimal manual QA

1. generateSourcemap: true + Terminal → Run Task… → tyhp: build
2. Start the proxy (status bar or Tyhp: Start XDebug Proxy). Output > Tyhp XDebug Proxy should show XDebug Proxy started and loaded maps.
3. Install PHP Debug if prompted. Run Listen for Tyhp (XDebug proxy).
4. Set a breakpoint in a .tyhp file, then run the compiled PHP (browser or php) with XDebug client_port=9004. The breakpoint should hit in the .tyhp source, not only the emitted .php.

Misconfiguration

Settings (tyhp.*)

Uninstalling

If installed via symlink or copy, remove the folder from the extensions directory:

rm -rf ~/.cursor/extensions/Tyhp.tyhp-0.8.2
# or
rm -rf ~/.vscode/extensions/Tyhp.tyhp-0.8.2

If installed via VSIX:

cursor --uninstall-extension Tyhp.tyhp
# or
code --uninstall-extension Tyhp.tyhp
