Vyne for Visual Studio Code

Syntax highlighting, bracket matching, and language support for the Vyne programming language.

✨ Features

• Full syntax highlighting for every Vyne construct
• Generic type highlighting — Box<T>, Pair<A, B>, nested Array<Box<T>>
• String interpolation with embedded expression highlighting
• Type annotation scopes for :: (distinct from other operators)
• Module injection syntax — fn :: MathUtils square(...)
• Bracket matching, auto-closing, and smart indentation
• Code folding with # region / # endregion markers
• Semantic-color-aware — uses standard TextMate scopes so it inherits your theme's palette

📦 Installation

From the Marketplace (once published)

1. Open VS Code.
2. Press Ctrl+P (or Cmd+P on macOS).
3. Paste: ext install tuncay-gafarli.vyne-language
4. Press Enter.

From a .vsix file

1. Download vyne-language-0.1.0.vsix.
2. In VS Code, open the Command Palette (Ctrl+Shift+P).
3. Run Extensions: Install from VSIX....
4. Select the file.

Or from the terminal:

code --install-extension vyne-language-0.1.0.vsix

### From source

```bash
git clone https://github.com/your-username/vyne-vscode
cd vyne-vscode
npm install -g @vscode/vsce
vsce package
code --install-extension vyne-language-0.1.0.vsix

🎨 Recommended Themes

The grammar uses standard TextMate scopes, so it inherits colors from any theme that supports semantic highlighting. Best results with:

🔍 Scope Reference

Every Vyne construct maps to a standard TextMate scope. This table is useful if you want to write a custom theme or override specific colors.

Declarations

Identifiers

Literals

Keywords

Types

Operators

Built-ins

🧪 Try It

Open any .vy file. To verify all scopes are working, save this as test.vy:

# Vyne syntax highlight test
ruleset { dynamic_casting, verbose }

use lib "vcolors.vy";

interface Box<T> {
    value :: T;
}

interface Pair<A, B> {
    first  :: A;
    second :: B;
}

group MathUtils {
    PI = 3.14159;
}

enum Status {
    Ok, Error, Pending
}

fn identity<T>(x :: T) -> T {
    return x;
}

fn :: MathUtils square(n :: Int64) -> Int64 {
    return n * n;
}

fn main() {
    b :: Box<Int64> = Box<Int64>(42);
    p :: Pair<Int64, String> = Pair<Int64, String>(7, "seven");

    name :: String = "World";
    greeting = "Hello, {name}!";

    out(b.value);
    out(p.first);
    out(greeting);

    x :: Int64 = 10;
    y = identity<Int64>(x);
    z = x ?? 0;

    result = [1, 2, 3] |> MathUtils.square;

    try {
        throw "error";
    } catch (e) {
        out(e);
    } finally {
        out("done");
    }

    defer {
        out("cleanup");
    }
}

main();

Then use Ctrl+Shift+P → Developer: Inspect Editor Tokens and Scopes and click any token to confirm it's highlighting correctly.

🛠 Development

The extension is a pure TextMate grammar — no language server, no runtime dependency. Edits to syntaxes/vyne.tmLanguage.json take effect immediately.

Live iteration

1. Open the vyne-vscode/ folder in VS Code.
2. Press F5. A new Extension Development Host window opens.
3. Open any .vy file in that window.
4. Edit the grammar in the main window.
5. Press Ctrl+R in the Extension Development Host to reload.

Debugging a token

If a token colors wrong:

1. Ctrl+Shift+P → Developer: Inspect Editor Tokens and Scopes.
2. Click the token.
3. The panel shows:
   • Language: vyne
   • TextMate scope: the deepest matched scope
   • All scopes: the full stack, from most general to most specific
4. Match the deepest scope against syntaxes/vyne.tmLanguage.json to find which pattern matched, then adjust it.

Packaging

vsce package

Produces vyne-language-0.1.0.vsix in the project root.

📁 Project Structure

vyne-vscode/
├── package.json                  # Extension manifest
├── language-configuration.json   # Brackets, comments, indentation
├── syntaxes/
│   └── vyne.tmLanguage.json      # The grammar itself
├── .vscodeignore                 # Files excluded from the package
├── README.md                     # This file
├── CHANGELOG.md                  # Version history
├── LICENSE                       # MIT
└── icon.png                      # (optional) 128×128 extension icon

🎨 Customizing Colors

If your theme doesn't color a Vyne-specific scope the way you want, override it in your settings.json:

{
  "editor.tokenColorCustomizations": {
    "textMateRules": [
      {
        "scope": "keyword.operator.pipeline.vyne",
        "settings": { "foreground": "#FF79C6", "fontStyle": "bold" }
      },
      {
        "scope": "keyword.operator.type-annotation.vyne",
        "settings": { "foreground": "#8BE9FD" }
      },
      {
        "scope": "entity.name.type.generic-param.vyne",
        "settings": { "foreground": "#50FA7B", "fontStyle": "italic" }
      },
      {
        "scope": "variable.parameter.vyne",
        "settings": { "foreground": "#FFB86C" }
      }
    ]
  }
}

The scopes above are the ones most themes don't have built-in rules for. Adding them gives you complete control over the Vyne look.

🐛 Known Limitations

• TextMate is regex-based, not a real parser. Extremely contrived code (e.g. a<b where a is capitalized and the line ends in () may highlight slightly differently than the actual Vyne parser would parse it.
• No semantic tokens yet. Parameter vs. local variable distinction relies on naming convention (variable.parameter matches parameters because they appear inside fn (...) — but a local named x at the top level of a function also matches variable.other.vyne).
• Cross-file type resolution is not possible in a TextMate grammar. If you write x :: MyStruct and MyStruct is defined in another file, the grammar still colors it correctly (PascalCase → entity.name.type.vyne) without needing to know where MyStruct lives.

🤝 Contributing

Issues and pull requests are welcome.

When reporting a syntax highlighting bug:

1. Include the smallest .vy snippet that reproduces the issue.
2. Include the output of Developer: Inspect Editor Tokens and Scopes.
3. Note which theme you're using.

📜 License

MIT © 2026 Tuncay Gafarli

🔗 Related

• Vyne compiler — github.com/your-username/vyne
• Vyne runtime — included in the compiler repo under runtime/
• Vyne external modules — vcolors, and others shipped under modules/external/

Made with ❤️ for the Vyne programming language.
