VSCode Extension for LilyPond

This is an extension to help you when editing LilyPond files in VS Code. It provides:-

• Syntax highlighting
  • Integrates with Scheme extensions to highlight embedded Scheme
• Red squiggles for (some) syntax errors as you type, before even running LilyPond
• Tab-completion of built-in commands, and variables in your file
• Go to definition and find references for variables (only basic foo = { music } for now, not Scheme commands)
• Build tasks for engraving in preview/publish modes
  • Optional engrave on save
  • Problem parser gives you red squiggles for LilyPond warnings and errors
• Side-by-side PDF preview, which auto-updates when the PDF changes
• Supports LilyPond's point-and-click PDFs:
  • Hovering/clicking an item in the PDF highlights/selects the relevant text in the .ly file.
  • Your cursor or selection in the .ly file highlight the relevant notation in the PDF.
• Code actions and refactorings to:
  • Add the right \version to a new file, or run convert-ly to update an old file
  • Extract the selected music to a variable
  • Inline a variable where it's used
  • Unfold repeats (e.g. \repeat volta 2 { a b c | } → a b c | a b c)
  • Add explicit notes and/or durations to music that omits it (e.g. g4 g g g to g4 g4 g4 g4).

I made this because I've been using Frescobaldi for years, but I want the full power of VS Code's text editor. None of the existing LilyPond extensions had working point-and-click sync between the PDF and .ly file. I hope to grow this extension to eventually match all the capabilities of a LilyPond-specific editor like Frescobaldi with refactoring actions and better diagnostics for common errors.

Requirements

• For most functionality you will need LilyPond installed. You can get it from https://lilypond.org/
• Optional If you make much use of embedded scheme (using # or #(…#)) , you might want an extension for scheme, for example https://marketplace.visualstudio.com/items?itemName=sjhuangx.vscode-scheme

How to use

• In the settings, set lilypondStudio.executablePath to the path to your LilyPond executable.

• Open a .ly file.

• Hit ctrl-shift-b to "run build task" and then choose "Engrave (Preview)" from the list. You can also set it as the default build task if you like.

  • Preview mode embeds point-and-click information in the generated PDF, so you can click on notes to go to the right place in the source file, and vice-versa. This makes the file much larger, and it gives away the path to the source file on your computer. When making a PDF to distribute or keep, use "Engrave (Publish)".

• The PDF will automatically open next to the input file and update live whenever it is updated on disk.

• By default the PDF is written alongside the .ly file. To keep engraved output somewhere else, set lilypondStudio.outputDirectory (relative paths are relative to the source file, and ${workspaceFolder} works). For different directories per set of build options, give an individual task in your tasks.json its own outputDirectory.

• The build options come from the lilypondStudio settings — outputDirectory, includeDirs, and commandOptions for anything else you want on the command line. A task in your tasks.json can override any of them, so you can keep several build configurations side by side:

• Edit the file and hit ctrl-shift-b again.

• You can have changes engraved automatically on every save. Turn this on in the language menu (the { } icon in the bottom-right). This always re-runs the last build task you ran by hand. The setting is saved between sessions but you always need to run a build task to activate it.

Build tasks and options (advanced)

The default build tasks run LilyPond in the input file's directory and generate a PDF with the same name as the input file. You can change this behaviour globally using VS Code's settings, and for particular build tasks by defining them in tasks.json. If a build task sets one of these values, it overrides the value in the settings.

{
    "type": "lilypond",
    "label": "Engrave for A3 handout",
    "mode": "publish",
    "outputDirectory": "${workspaceFolder}/handouts",
    "commandOptions": ["-dpaper-size=a3"]
}

Output directory

Some people like to have the .pdf files in a different directory such as output. Set outputDirectory in a build task or in your settings. You can use relative or absolute paths, and variable substitution. The output directory will be created if it doesn't exist. You can't set the output filename itself this way (like you can with --output).

Include directories

Add paths to LilyPond's --include option with the includeDirs array. A value set in the build task completely replaces the list from the settings, it doesn't combine the two lists.

Other command-line options

Options in the commandOptions array are passed as-is to LilyPond. They override all other options. You can use this for any weird workflow you want.

If you turn off PDF output or change the output directory here instead of with outputDirectory, the PDF preview will not be able to find the output file.

Known issues and limitations

• There are MacOS and Linux builds, and the automated tests run on those platforms, but I only use Windows, so please let me know if anything is wrong. I'm also interested in whether anyone would want this in web (vscode.dev) instead of desktop.
• Embedding LilyPond inside scheme (using #{…#}) doesn't quite work yet.
• Creating the build tasks gets a bit confused with multi-root workspaces but it seems to work fine regardless.
• The PDF preview looks for <name>.pdf in your configured output directories and next to the source file, so a score renamed with \bookOutputName won't be found automatically. There's no support for more complex workflows with book mode and multiple output files.
• No MIDI input/output or previewing MIDI files.
• You can use snippets if you like, but the extension doesn't ship with any. If you find some useful, please let me know and I'll include them!
• It doesn't understand drum mode or figured bass, and understanding of markup commands is still rudimentary.

Developers

Building from source

The extension's TypeScript is built with npm run compile (or npm run watch while developing). The bundled language server is a separate Rust crate, ly-lsp, included here as a git submodule in ly-lsp/ so that each extension commit pins the exact server revision it ships with. Clone with --recurse-submodules, or run git submodule update --init in an existing checkout. It's built manually:

1. Build it in release mode: cargo build --release --manifest-path ly-lsp/Cargo.toml. Building the tree-sitter grammar needs a C compiler — MSVC on Windows.
2. Copy the resulting binary into this extension's server/ directory, e.g. ly-lsp/target/release/ly-lsp.exe → server/ly-lsp.exe.

The extension looks for the binary at server/ly-lsp.exe on Windows and server/ly-lsp elsewhere, and packages it into the .vsix. If it's missing, the language-server features are simply disabled — everything else still works. Because the binary is native, releases are published as platform-specific packages (win32-x64, linux-x64, darwin-x64, darwin-arm64); VS Code installs whichever matches, so most users never see the distinction.

While iterating on the server you can skip the copy step: set lilypondStudio.languageServerPath to your build output (e.g. ly-lsp/target/release/ly-lsp.exe) and the extension will use that in preference to the bundled binary, restarting the server whenever the setting changes.
