Drawper

Drawper

Vaibhav Sharma

|
10 installs
| (2) | Free
A fast whiteboard canvas inside VS Code with system architecture and database schema panels that generate code (SQL, Prisma, Drizzle, TypeScript, docker-compose). Files use the .dpr extension.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

Drawper: sketch your system, ship the schema

VS Code File type Status License

What it is · Demo · Features · Getting started · Usage


What is Drawper?

Drawper is a VS Code extension that puts a fast whiteboard inside your editor, built for the two diagrams developers draw most: system architecture and database schemas. You sketch boxes and arrows, and Drawper turns what you drew into real, runnable code.

Most diagram tools stop at a picture, and the picture goes stale the moment the code changes. Drawper keeps the diagram and the code connected:

  • Draw it, then generate it. Tables and columns become SQL, Prisma, Drizzle or TypeScript. Components become a docker-compose.yml with a Node scaffold per service.
  • Read what you already have. Open any existing schema file and Drawper draws the ER diagram for you, following foreign keys across files.
  • Think on top of your code. Draw arrows, pens and notes directly over a live copy of your source file.
  • Stay in your repo. Drawings are plain .dpr JSON files that diff cleanly and live next to the code they describe.

Sketch on the canvas, connect with arrows, generate code

Sketch, connect, generate.

Who it is for

If you are... Drawper helps you...
Designing a new service Whiteboard the architecture, then scaffold it with one click
Modelling a database Draw tables and relations, then export SQL, Prisma or Drizzle
Joining an existing codebase See the whole schema as an ER diagram, across files
Migrating ORMs Convert Prisma, TypeORM, Django, SQLAlchemy or Mongoose models to another format
Explaining code to a teammate Annotate the real file with arrows and notes

Demo

Drawper demo

Screenshots

Architecture canvas. Drop components, connect them with arrows, generate a runnable docker-compose.

Architecture canvas

Schema editor. Design tables and columns visually and export them as SQL, Prisma, Drizzle or TypeScript.

Schema editor

Relations with arrows. Draw an arrow from one table to another and Drawper adds the foreign key column for you. The arrow starts at the table that holds the key and points at the table it references.

Relations drawn with an arrow

Schema viewer. Open any file that defines tables and see an ER diagram with foreign keys drawn for you.

Schema viewer

Features

  • Opens fast. Code-split webview (about 750 KB up front), the document is embedded in the page, and the extension only activates when you use it.
  • Architecture panel. Client, API, worker, gateway, database, cache, queue and storage components. Arrows between them become dependencies.
  • Schema panel. Visual table and column editor with primary keys, nullable, unique and foreign keys. Renaming a table or column updates every foreign key that points at it.
  • Relations by arrow. Join two tables with an arrow and the foreign key is created, then flows into every generator.
  • Code generation. SQL, Prisma, Drizzle (with relations()), TypeScript types and docker-compose.yml with a Node scaffold per service.
  • Relation queries. One click writes ready-to-run SQL joins plus Drizzle and Prisma relation queries for every relation.
  • Convert code from the IDE. Turn an existing schema file into another format without opening the canvas. See Convert code.
  • Schema viewer for existing code. A CodeLens appears above schema definitions: View in Drawper. It shows the file's tables plus related tables from other files (foreign keys are followed across imports), and a Whole app toggle shows every schema in the workspace. "Go to" jumps to the right file.
  • Draw on your code. Canvas (editor title bar, status bar or above a selection) opens the whole file as a live, locked card on <file>.annotations.dpr beside the editor, with pens, arrows and notes on top. Those drawings are also shown over the real editor (display only; relies on an unofficial VS Code trick, tune drawper.overlay.charWidthRatio if it drifts sideways, or turn it off with drawper.overlay.enabled). Add to canvas drops just the selected code on a canvas as a card. Paste screenshots with Ctrl+V.
  • Icons and SVG. Built-in icon library, SVG import, and paste SVG markup straight onto the canvas.
  • Resizable side panel. Drag its left edge; the width is remembered.
  • Panel themes. Pick Blue, Yellow, Mint, Coral or Violet from the Theme button in the panel header; the choice is remembered.
  • Plain JSON files. Drawings are saved as .dpr and diff cleanly.

Schema sources the viewer understands

Source Detected from
Prisma model X { ... }
SQL CREATE TABLE and ALTER TABLE ... FOREIGN KEY
Drizzle pgTable, mysqlTable, sqliteTable, singlestoreTable, mssqlTable, schema.table(...), composite primaryKey and foreignKey
TypeORM @Entity() classes
SQLAlchemy __tablename__ models
Django models.Model classes
Mongoose new Schema({ ... })

Generate targets

Target Output
SQL schema.sql
Prisma schema.prisma
Drizzle schema.ts (drizzle-orm/pg-core)
TS types types.ts
Relation queries queries.sql, queries.drizzle.ts, queries.prisma.ts
docker-compose docker-compose.yml and services/<name>/

Files are written next to your drawing in <name>-generated/.

Relations and queries

Draw an arrow with the Arrow tool (A) between two tables. Drawper adds a <table>_id column to the table the arrow starts from, with a foreign key to the primary key of the table it points at. Existing foreign keys are never duplicated, and the same relation flows into SQL, Prisma, Drizzle and TypeScript output.

Relation queries turns every relation into both directions of a join:

-- orders -> customers (many-to-one), columns shortened here
SELECT
  orders.id AS orders_id,
  orders.customer_id AS orders_customer_id,
  customers.id AS customers_id
FROM orders
LEFT JOIN customers ON orders.customer_id = customers.id;
await db.query.orders.findMany({ with: { customer: true } });      // Drizzle
await prisma.order.findMany({ include: { customer: true } });      // Prisma

Convert code from your IDE

You do not need a canvas to convert a schema. Open any file that defines tables (Prisma, SQL, Drizzle, TypeORM, SQLAlchemy, Django or Mongoose) and use any of these:

Where How
CodeLens above the first table Convert to Drizzle / Prisma / SQL…
Right-click in the editor Drawper: Convert Schema To…
Right-click a file in the Explorer Drawper: Convert Schema To…
Command Palette (Ctrl+Shift+P) Drawper: Convert Schema To…

Pick a target (Drizzle, Prisma, SQL, TypeScript types or Relation queries) and the converted code opens beside your file, saved in <file>-converted/.

For example, a Prisma schema becomes Drizzle with its relations in two clicks, and a TypeORM or Django model becomes SQL.

Getting started

git clone https://github.com/Vaibhav9526/Drawper.git
cd Drawper
npm install
npm run compile

Then press F5 in VS Code to launch the Extension Development Host.

To build an installable package:

npm run package   # produces drawper-<version>.vsix
code --install-extension drawper-0.1.0.vsix

Usage

Command What it does
Drawper: New Drawing Creates sketch-N.dpr in the workspace and opens it
Drawper: Open Drawing Canvas Opens the current .dpr, or lets you pick one
Drawper: View Schema in This File Shows an ER diagram for the schema in the active file
Drawper: Convert Schema To… Converts the schema in the active file to Drizzle, Prisma, SQL, TS types or relation queries
  1. Run Drawper: New Drawing.
  2. Add components or tables from the side panel.
  3. Draw arrows between components with the Arrow tool (A).
  4. Click a generate button to write code.

Development

npm run compile            # tsc for src/, esbuild bundle for src/webview into media/dist
npm run watch              # tsc --watch (extension host)
npm run watch:webview      # esbuild --watch (webview)
npm run typecheck:webview  # type-check the webview
npm test                   # compile, then parser tests and generator round-trip tests

Project structure

Drawper/
├── src/
│   ├── extension.ts       # activation, custom editor, schema CodeLens, webview host
│   ├── model.ts           # .dpr document model, arrow-to-relation detection
│   ├── relations.ts       # foreign keys from arrows, relation naming
│   ├── codegen.ts         # SQL / Prisma / Drizzle / TS / queries / docker-compose generators
│   ├── schemaParsers.ts   # Prisma, SQL, Drizzle, TypeORM, SQLAlchemy, Django, Mongoose
│   └── webview/           # React UI: canvas, side panel, shapes, icons
├── media/
│   └── brand/             # logo.svg (source) and logo.png (marketplace icon)
├── docs/images/           # README screenshots, banner and workflow art
└── scripts/               # webview build and parser tests

Brand

Blue #005FFF
Ink #2E2936
Yellow #FFD900
Coral #EC5451
Mint #87DAC7
Violet #8B5CF6

License

MIT
