NuGet Config Visual Editor (nuget-config-editor)

A Visual Studio Code extension that provides a friendly visual editor for working with NuGet's nuget.config files.

This extension lets you view and manage package sources and package source mappings using a table-based GUI instead of editing XML by hand. It focuses on clarity, accessibility, and preserving configuration intent when saving changes.

Key features

• Visual, table-based editor for nuget.config package sources: add, edit, remove, enable/disable sources.
• Mappings panel: manage package source mappings (pattern-based mappings) with add/remove and validation support.
• Preserve unknown XML sections where possible and validate values before saving.
• Theme-aware UI and accessibility support (ARIA labels, keyboard navigation).
• Integrated file picker for workspaces with multiple nuget.config files.

Getting started

1. Install the extension from the VS Code Marketplace or load it from this repository in Extension Development Host.
2. Open a folder or workspace containing a nuget.config file.
3. Right-click a nuget.config file in the Explorer and choose "Open With..." → "NuGet Config Visual Editor", or open the command palette (Ctrl+Shift+P) and run "NuGet Config: Open Visual Editor".
4. Use the table to add, edit, enable/disable, or remove package sources. Switch to the Mappings panel to manage source mappings.

Settings

The extension contributes the following settings (available in Settings UI):

• nugetConfigEditor.logLevel (string) — Log level for the extension output (e.g. info, debug, error).
• nugetConfigEditor.preferVisualEditor (boolean) — When true, open nuget.config files in the visual editor by default.
• nugetConfigEditor.preserveUnknownXml (boolean) — Attempt to preserve unknown XML nodes/sections when saving changes.

Usage tips

• Changes are saved back to the nuget.config XML file; review diffs in source control if you want to inspect XML edits.
• If your workspace contains several nuget.config files, use the file picker to choose which config to edit.
• Some advanced or custom XML nodes may not round-trip perfectly; enable preserveUnknownXml to reduce loss of unknown content.

Known limitations

• Comment preservation in XML is best-effort — some comments or formatting may change when saving.
• Very large or heavily customized nuget.config files may show limited round-trip fidelity for uncommon XML structures.

VS Code Git diff viewing

Because this is a custom editor, if it is set as default, when viewing a diff it will render both editor views and you won't be able to see the actual diff. You'll want to switch to the Text Editor to see it. This is a known limitation of the VS Code custom editor extensbility points microsoft/vscode#138525 right now.

Because of this I recommend having this setting in your workspace or user settings:

"workbench.editorAssociations": {
   "{git}:/**/nuget.config": "default",
   "nuget.config": "timheuer.nuget-config-editor"
}

Contributing

If you'd like to contribute, please open issues or pull requests in this repository. Keep change sets focused and include tests where appropriate.

License

See the repository license for details.
