Power Automate Copilot DevKit

Power Automate Copilot DevKit brings Power Automate cloud flow editing into VS Code, with guardrails for working safely against real Dataverse solutions.

• Download and edit flows locally as readable JSON, then validate, compare, and upload changes back with drift checks and backups.
• Install bundled GitHub Copilot (GHCP) skills so Copilot can help edit flow JSON, expressions, error handling, and performance patterns directly in your workspace.

This README has two parts:

• User Guide: install the VSIX and use the extension.
• Developer Guide: build, debug, package, and extend the code.

User Guide

Installation Guide

Prerequisites

Before installing the extension, make sure you have:

• VS Code 1.90.0 or newer.
• Microsoft Power Platform CLI (pac) installed and available on PATH.
• Access to a Power Platform environment.
• An unmanaged Power Platform solution that contains the cloud flow you want to edit.
• Optional: GitHub Copilot recommended for natural-language flow editing and the bundled GHCP skill guidance.

Install pac from the Microsoft documentation: https://learn.microsoft.com/power-platform/developer/cli/introduction

Install From VSIX

1. Get the extension .vsix file, for example power-automate-copilot-devkit-0.1.0.vsix.
2. Open VS Code.
3. Open the Extensions view.
4. Select the ... menu in the Extensions view.
5. Choose Install from VSIX....
6. Select the .vsix file.
7. Reload VS Code if prompted.
8. Confirm that the Power Automate lightning icon appears in the Activity Bar.

If pac is not on PATH, set powerAutomateCopilotDevKit.pacPath to the full path of the Power Platform CLI executable.

Usage Guide

Features

• Download flows as editable JSON under solutions/<solution-name>/Workflows/.
• Upload a flow with smart validation, server drift detection, diff review, remote backup, and connection-reference checks.
• Static analysis and linting warn about flow shape issues, invalid runAfter targets, missing connection references, foreach race risks, missing error handling, platform limits, and expression pitfalls.
• GHCP skills help Copilot generate better Power Automate JSON, expressions, error handling, and performance patterns.
• Compare a local flow with the server copy before uploading.
• Pull a server flow and discard local changes when the cloud copy should win.
• Open the flow or solution in the Power Automate and Power Apps maker portals.
• List and link connection references when a flow needs environment-specific connections.

Initial Setup

1. Click the Power Automate lightning icon in the VS Code Activity Bar.
2. Select Sign in to Power Automate... or run Power Automate: Sign In.
3. Complete the Power Platform sign-in flow.
4. Select the environment that contains your solution.
5. Select the solution that contains the flow.
6. Install the GHCP skills when prompted, or run Power Automate: Install Flow Skill into Workspace.
7. Run Download Solution (Export + Unpack) from the pinned solution.
8. Open the downloaded flow under solutions/<solution-name>/Workflows/*.json.

Editing A Flow

You can edit a flow in two ways:

• Open the flow definition from the Power Automate tree and edit the JSON manually.
• Ask GitHub Copilot to update the flow JSON using natural language.

After editing:

1. Save the flow file.
2. Review warnings and errors in the Problems panel.
3. Run Upload Flow when you are ready to push the local flow to the server.

Useful GHCP prompts:

Upload this flow to push my local changes to the server.
Pull this flow and discard my local changes.
View this flow in the Power Automate portal.
Download the pinned solution.
List my SharePoint connection references.
Help me add error handling to this flow.
Help me make this flow use safer retry and runAfter patterns.

Common Commands

What Upload Checks

Upload Flow updates one flow definition. It does not pack and import the entire solution.

Before uploading, the extension:

• Parses the flow JSON.
• Runs static validation and linting.
• Warns when connection references are missing or not bound to an active connection.
• Checks whether the server copy changed since the last download.
• Lets you view a diff, upload your version, pull the server version, or cancel when drift is detected.
• Backs up the current remote flow JSON under .power-automate-copilot-devkit/backups/.
• Deactivates and reactivates active flows during upload when configured to do so.

GHCP Skill Docs

The extension includes Power Automate guidance for GitHub Copilot under resources/skill/docs/flow-skill/. Installing the skill into your workspace helps Copilot follow the project's flow-authoring patterns.

The bundled docs cover:

• Error handling and try/catch/finally scope patterns.
• Retry, runAfter, and failure-path guidance.
• Performance and platform limits.
• Expert flow patterns.
• Power Automate expression examples.

User Settings

Most users can keep the defaults.

In untrusted workspaces, workspace-scoped pacPath and solutionsRoot values are ignored. Use user or global settings, or trust the workspace.

Troubleshooting

Developer Guide

Use this section when you want to build, debug, package, or extend the extension code.

Project Structure

Build And Debug

Install dependencies:

npm install

Build the extension bundle:

npm run build

Run TypeScript checking:

npm run compile

Watch and rebuild during development:

npm run watch

Package a VSIX:

npm run package

Press F5 in VS Code to launch the Extension Development Host.

How To Extend

Add A Command

1. Add the command contribution in package.json.
2. Add menu placement in package.json if the command should appear in the tree, editor, Explorer, or command palette.
3. Implement the command under src/commands/.
4. Register the command in src/extension.ts with the existing register(...) helper.
5. Reuse existing services such as AuthService, PacCli, DataverseClient, and FlowTreeProvider instead of creating parallel access paths.

Add A GHCP Tool

1. Add contributes.languageModelTools metadata in package.json.
2. Implement the tool under src/tools/.
3. Register the tool in src/extension.ts with vscode.lm.registerTool.
4. Prefer wrapping an existing command/service path so user confirmations and safeguards stay consistent.

Add Validation

1. Add rules in src/validation/flowLinter.ts.
2. Keep findings read-only; validation should not rewrite the user's flow JSON.
3. Return stable rule IDs, severities, JSON paths, and offsets when possible.
4. Update diagnostics or tests if validation behavior changes.

Add Tree Behavior

1. Update src/tree/FlowTreeProvider.ts for new nodes, labels, icons, or refresh behavior.
2. Add or adjust contextValue strings for menu targeting.
3. Update package.json menu contributions to show commands in the right tree context.
4. Keep network work lazy and cached where possible so the tree stays responsive.

Add Configuration

1. Add the setting under contributes.configuration.properties in package.json.
2. Read values through src/config.ts.
3. Use trusted configuration helpers for settings that affect local executable paths or workspace-relative paths.
4. Document user-facing settings in the User Guide.

Add Or Update GHCP Skill Docs

1. Update files under resources/skill/docs/flow-skill/.
2. Keep guidance concise and directly useful for editing Power Automate flow JSON.
3. Confirm Power Automate: Install Flow Skill into Workspace still installs the expected files.

Safety And Design Notes

• Keep pac calls inside PacCli; it uses process spawning without a shell.
• Validate solution names, workflow IDs, and environment IDs before using them in CLI or Dataverse operations.
• Preserve upload safeguards: linting, connection checks, drift detection, remote backup, ETag conditional PATCH, and state restore behavior.
• Keep upload scoped to one flow unless the product intentionally changes.
• Respect untrusted workspace behavior for pacPath and solutionsRoot.
• Prefer existing command and service paths for GHCP tools so agent-mode behavior matches the UI.
• Do not bypass FlowManifest when changing download, upload, drift, backup, or baseline behavior.

Developer Command Reference
