MAD — Mermaid Auto-Doccing

Replace // description comments with //@ tags.
Your code stays readable. Enriched with diagrams.

Why?

Documentation rots. Diagrams drift. When your architecture diagram lives in Confluence or a wiki, it's outdated the moment you commit.

MAD inverts the problem: put the diagram inside the code. //@ tags replace your plain // description comments — same line position, same readability, but now they double as machine-readable documentation. Tags sit directly above what they describe: classes, methods, branches, error paths. Save the file and MAD generates a valid Mermaid diagram. No context-switching. No manual diagramming. Documentation that can't fall out of sync because it is the code.

See it in action

Here's a login controller. The //@ tags on the left replace regular comments. The diagram on the right is what MAD generates — automatically, on save.

//@::graph LR

//@Entry
class LoginController {
  //@Entry1:Handle login
  async handleLogin(email, password, ip) {
    //@->RateLimiter1:Check rate limit
    const allowed = await rateLimiter.check(ip);
    if (!allowed) return error.tooManyRequests();

    //@->Auth1:Authenticate
    const user = await auth.authenticate(email, password);
    if (!user) return error.invalidCredentials();

    if (user.twoFactorEnabled) {
      //@->TwoFactor1:Challenge 2FA
      return twoFactor.initiateChallenge(user);
    }

    //@->Auth2:Create session
    const session = await auth.createSession(user);
    //@->Dashboard1:Show dashboard
    return send.success(session);
  }
}

//@Auth
class AuthService {
  //@Auth1:Authenticate
  async authenticate(email, password) { … }
  //@Auth2:Create session
  async createSession(user) { … }
}

graph LR
  Entry1[Handle login] -->|Check rate limit| RateLimiter1
  Entry1 -->|Authenticate| Auth1
  Auth1 -->|Challenge 2FA| TwoFactor1
  Entry1 -->|Create session| Auth2
  Auth2 -->|Show dashboard| Dashboard1

Every //@Group becomes a subgraph. Every //@Group1:Label becomes a node. Every //@->Target:Label becomes an edge. What you see in the diagram is exactly what the code does — every branch, every error path, every external call.

How it works

 You write                  MAD parses                  You get
─────────────            ─────────────────          ─────────────────
 //@Auth                Auth  → subgraph node       Live Mermaid diagram
 //@Auth1:Login         Auth1 → step node           in a preview panel
 //@->Db1:Save           Auth → Db1 edge            with full controls

How you interact with MAD

Supported diagrams

Add a //@:: directive anywhere in your file to declare the diagram type.

Benefits that compound

Agent integration

MAD runs a local HTTP server (127.0.0.1 only) that CLI agents can call:

# Health check
curl http://127.0.0.1:$(cat /tmp/mad-server.port)/health
# → {"status":"ok","version":"1.7.14"}

# Validate a file and get its diagram
curl -X POST http://127.0.0.1:$(cat /tmp/mad-server.port)/validate \
  -H 'Content-Type: application/json' \
  -d '{"filePath":"/path/to/file.ts"}'
# → {"status":"ok","mermaidCode":"graph LR\n  ...","warnings":[]}

Agents use this to read your architecture, validate MAD tags, and keep a better understanding of your codebase.

Core rules (one sentence each)

• Replace your // comments with //@ tags — same position, same readability, now diagramed!
• One tag per code line — declaration (//@Name), connection (//@->Target), or both (//@Name->Target) but not stacked
• Document every code path — every method, every branch, every error, every external call
• Use numbered hierarchy — Group1 for entry points, Group1.1 for sub-steps
• Connections live above the source — //@->Target:Label goes on the line above the code that makes the call

Quick start

1. Install the extension

Install MAD from the VS Code Marketplace in any VS Code-derived IDE (VS Code, Cursor, Windsurf, etc.).

2. Install the skill

Your agent needs the MAD skill to understand //@ syntax:

npx skills add juliocrfilho/mad

This installs .agents/skills/mad/SKILL.md — the reference your agent uses to write valid MAD tags.

3. Tell your agent to use it

Say to your agent:

"Document this file with MAD tags using the mad skill."

The agent will read the skill, scan your code, and add //@ tags above every class, method, branch, and external call. Save the file and your diagram is ready.

Running tests

npm test
# → 29 tests, 0 failures across 6 diagram-type suites

Update snapshots after diagram changes:

NODE_PATH=test/mocks node --test-update-snapshots --test test/mad-outputs.test.mjs

Extension settings

Architecture

MAD itself is documented with MAD tags. Open extension.ts — every step of the activation sequence is tagged with //@Setup1 through //@Setup24. Save the file and MAD generates its own flowchart.

License

MIT
