EXPRESSsuite

A Visual Studio Code extension that provides language support and rich-content viewers for the EXPRESS (ISO 10303-11) information modeling language used by ISO TC 184/SC 4 STEP standards.

EXPRESSsuite is an independently maintained derivative of the NIST-developed easyEXPRESS (Sylvere Krima, Allison Barnard Feeney, Rosemary Astheimer; U.S. National Institute of Standards and Technology). EXPRESSsuite has its own product and Visual Studio Marketplace identity, TRThurman.expresssuite; it is not the NIST-owned easyEXPRESS application or listing. Pursuant to NIST's Software Licensing Statement, this project carries a notice of modifications in NOTICE.md and acknowledges NIST as the source of the original software. NIST-developed software is not subject to copyright protection within the United States under 17 U.S.C. § 105.

If you reference, cite, or build on this work, see § Citation below or the machine-readable CITATION.cff.

Features

Language support (existing)

• Syntax highlighting and validation for .exp files.
• IntelliSense with auto-completion of entities, types, and attributes.
• Code navigation: Go to Definition, Peek Definition, Find All References, Go to Symbol.
• Refactoring: Rename Symbol with cross-file scope tracking.
• Code snippets for common EXPRESS patterns.

SC4 validation

EXPRESSsuite reports additional ISO TC 184/SC 4 authoring problems in the standard VS Code Problems view:

• Entity-name case is significant (project requirement) — EXPRESSsuite is tailored for ISO 10303 development, where the case of an entity name carries meaning: ARM entity names begin with an uppercase letter (Product), MIM and integrated-resource entity names are lowercase (product), and the two are different entities. In a short form, references bind only to the exact spelling, so SUBTYPE OF (mesh) does not name ENTITY Mesh, and an ARM reference written in lowercase is an error in the ARM. This is a deliberate project departure from ISO 10303-11:2004 7.1.2, which makes letter case insignificant outside string literals (project ruling, 2026-10-29). The published SMRLv8 follows the convention without exception in its ARMs (3,460 of 3,460 entity names) and MIMs (1,359 of 1,359). In a long form (a schema whose name ends in _lf), which WG11 N239 makes unique regardless of case for tools that fold case, every name binds regardless of case (project ruling, 2026-10-30).

• Schema-name case (project requirement) — a schema whose name ends in arm or mim begins with an uppercase letter (Mesh_topology_arm, Mesh_topology_mim; project ruling, 2026-10-30). The published SMRLv8 follows this in every module arm.exp and mim.exp (1,735 ARM and 1,737 MIM schema names); the only exceptions are 104 lowercase copies in modules/analytical_model/arm_concatenated.exp and mim_concatenated.exp. Schema names that do not end in arm or mim are uncontrolled (project ruling, 2026-10-30). A schema reference (USE FROM, REFERENCE FROM) binds only to the exact spelling, as an entity reference does, so REFERENCE FROM GEOMETRY_SCHEMA does not name geometry_schema (project ruling, 2026-10-30). No diagnostic checks the naming rule yet.

• Case is not significant in type, attribute, function, rule and subtype-constraint names (project requirement) — two spellings that differ only in case denote the same declaration, as ISO 10303-11:2004 7.1.2 provides; only entity names and the schema-name rule above carry case (project ruling, 2026-10-30). The linker binds accordingly: an exact match first, otherwise a match regardless of case among the kinds that do not carry case, so SELF\Value_with_unit.Unit names the attribute unit and x : Unit_kind names TYPE unit_kind, while SUBTYPE OF (mesh) still does not name ENTITY Mesh in a short form. The casing diagnostics below are style hints and remain.

• Declaration-name casing — entities in schemas whose names end in _arm must begin with an uppercase letter. Entities in other schemas and all type names must be lowercase. Casing diagnostics include a quick fix.

• Duplicate interfaced declarations — within one schema's scope an identifier may be declared or explicitly interfaced once only (ISO 10303-11:2004 10.1 b). duplicate-interfaced-declaration is reported in every schema in whose scope one identifier denotes two different declarations of any kind, whether both are local, one is interfaced, or both arrive through USE FROM chains; it is anchored at the local declaration or at the interface line that brought the declaration in, with related information at every declaration. The scope follows clause 11: a USE FROM re-exports along chains and under renames (11.1, 11.3), a REFERENCE FROM sees what the foreign schema declares or use's but never chains (11.2, 11.3), explicit item lists are honoured, one declaration reached by several routes counts once, and implicit interfaces bring no identifier (11.4). In a short form an entity name is case-significant and every other kind is compared without regard to case (project rulings); in a long form (_lf) every identifier is compared without regard to case and identical repeated definitions are the warning redundant-declaration (WG11 N239). The scope relation is proved in lean/ExpressSuite/Interfaces.lean.

• Duplicate loop indices — a LOCAL variable must not redeclare the index implicitly declared by a REPEAT increment control. Loop-index and variable names are compared without regard to case.

• Informal proposition signatures — annotations such as (*"schema.entity.wr:IP1" ... *) must have a matching --IP1: signature as the final entry inside the corresponding ENTITY or TYPE. Missing, malformed, misplaced, and unmatched signatures are reported, as are malformed .IPn and .ipn annotation keys.

• Attribute redeclaration types — the type of SELF\e.attr : T must be the same as, or a specialization of, the original attribute's type (ISO 10303-11:2004 9.2.3.4, 9.2.7). Defined types and selects are seen through on both sides, so narrowing compound_item_definition to a LIST [2:3] OF point_and_vector_member is accepted, while LIST OF REAL is not. The relation is proved sound in lean/.

• Index qualifiers — x[1] is reported when the declared type of x can never hold an aggregate value (ISO 10303-11:2004 12.6.1).

• Ambiguous attribute references — x.a is reported when a is declared by two or more entities at the same nearest depth of the declared type of x (ISO 10303-11:2004 12.7.3, last sentence); qualify it with a group reference such as x\e.a.

Attribute references resolve as 12.7.3 prescribes: x.a is looked up in the declared type of x, its supertypes and its subtypes, nearest first, never in a sibling entity; x\e may name any entity in the same subtype/supertype graph (12.7.4) and x\e.a then means e's own declaration. Hover, go-to-definition, completion and validation all follow this one rule, which is proved against the clause text in lean/.

The same check is available on demand as EXPRESSsuite: Detect Duplicate Declarations in Schema Closure from the Command Palette or an EXPRESS editor's context menu: it lists the clashes in the scope of the schema at the cursor, computed by the same scope index as the live diagnostic, handles cycles and renamed resources, and publishes navigable diagnostics for declaration names supplied by more than one schema in that closure.

Annotation viewers (new in 0.4.0)

Four surfaces that render the annotated EXPRESS convention used by SC 4 schema authors — Metanorma AsciiDoc inside (*"tag" body *) named-remark comments:

• Hover provider — rich MarkdownString popups showing the description of the entity at the cursor, with cross-references rendered as clickable links and embedded math (stem:[…]) shown as inline SVG glyphs.
• Show Description — a webview panel beside the editor with the full description rendered via Asciidoctor.js, with embedded math typeset via Plurimath (the same converter Metanorma uses).
• Show EXPRESS-G Diagram — interactive SVG viewer for <schema>expg<N>.svg diagrams; click any labelled box to jump to the entity's source declaration.
• AsciiMath Playground — live-preview webview for AsciiMath input. Renders prose-with-math fragments in place; supports stem:[…] (AsciiMath) and latexmath:[…] (LaTeX). "Insert at cursor" pastes the source as stem:[…] into the active editor.

Note to STEP developers: long-form and concatenated files are not currently supported.

Install

From a packaged .vsix

code --install-extension expresssuite-0.4.0.vsix

The package installs as TRThurman.expresssuite. It does not replace or publish a new version under the NIST easyEXPRESS Marketplace identity.

(Use code-insiders --install-extension … for VS Code Insiders.) Reload the window after install. The extension activates on the first .exp file encountered in the workspace.

From source (development)

git clone https://github.com/TRThurman/EXPRESSsuite.git
cd EXPRESSsuite
npm ci
npm run build

To launch a development host with the extension loaded:

code --extensionDevelopmentPath="$(pwd)" --disable-extensions

To package a .vsix from source:

npm i -g @vscode/vsce
vsce package

Quick start

Open any .exp file with named-remark annotations (e.g. those in wg12-step). The four viewer surfaces are reachable as:

Performance and diagnostic logs land in the Output panel under EXPRESSsuite.

Privacy and confidentiality

EXPRESSsuite itself makes zero outbound network calls. Every webview is configured with CSP connect-src 'none'; the extension host source contains no fetch, no http(s) import, no telemetry. Math rendering happens entirely on your machine via Plurimath (in a node:worker_threads worker) and MathJax (lazy-loaded for hover SVGs).

⚠ However, modern VS Code (and especially VS Code Insiders) bundles GitHub Copilot Chat as a built-in feature. Its right-click context-menu entries (Explain, Add File to Chat, Open Inline Chat, Review) DO send the cursor word, enclosing scope, surrounding source lines, and snippets from other open editors to GitHub/Microsoft endpoints. --disable-extensions does NOT remove these.

For pre-publication standards work under non-disclosure, the recommended workflow is:

1. Sign out of GitHub in the affected VS Code window (account icon at bottom-left → Sign Out). Without auth, Copilot Chat cannot reach its API.
2. Or set "chat.disableAIFeatures": true in the workspace's .vscode/settings.json.
3. Best practice: a dedicated, signed-out window for any sensitive schema work; sign back in for non-confidential projects.

The companion white paper (see below) documents the data flows and verification steps in detail.

Documentation

Project documentation under docs/:

Rendering the white paper

The white paper is written in AsciiDoc to dogfood the format the extension renders. To preview it:

As HTML — in VS Code

Install the Asciidoctor extension for VS Code:

code --install-extension asciidoctor.asciidoctor-vscode

Open docs/easyEXPRESS-viewers.adoc, then Cmd+K V (preview to the side) or Cmd+Shift+V (preview in the same column). The preview updates as the file is edited.

As HTML — from the command line

asciidoctor docs/easyEXPRESS-viewers.adoc -o docs/easyEXPRESS-viewers.html
open docs/easyEXPRESS-viewers.html

As PDF

gem install asciidoctor-pdf
asciidoctor-pdf docs/easyEXPRESS-viewers.adoc -o docs/easyEXPRESS-viewers.pdf
open docs/easyEXPRESS-viewers.pdf

As Metanorma standoc (publication fidelity)

gem install metanorma-cli metanorma-standoc
metanorma compile docs/easyEXPRESS-viewers.adoc -t standoc -x html,pdf

This path uses Plurimath to render embedded math, exactly matching the rendering the extension itself produces.

Build, lint, test

npm run build        # langium-generate + tsc + esbuild
npm run lint         # eslint
npm test             # vitest, the unit suite
npm run test:smrlv8  # the SMRL v8 corpus against its baselines (minutes, multi-GB heap)
npm run rebuild      # clean build from scratch

Continuous integration runs the build/lint/test matrix on macOS, Ubuntu, and Windows via .github/workflows/ci.yaml, audits the production dependencies, runs the SMRL v8 corpus on one Linux runner, and uploads platform-specific .vsix artifacts.

The SMRL v8 corpus

test-fixtures/smrlv8 holds the EXPRESS schema files of the published ISO 10303 SMRL v8 (1,410 .exp files, byte-identical to the distribution, nothing else from it). npm run test:smrlv8 loads the 1,287 files the default settings admit as one workspace, then the 103 long forms directly, and compares every diagnostic with the baselines in test-fixtures/smrlv8-baseline. The baselines pin behaviour on real schemas, not correctness; the known false-positive classes are listed in that folder's README. After an intended change, regenerate them and review the diff:

EXPRESS_UPDATE_SMRLV8_BASELINE=1 npm run test:smrlv8

Origin and licensing

The original easyEXPRESS was developed at the U.S. National Institute of Standards and Technology by Sylvere Krima, Allison Barnard Feeney, and Rosemary Astheimer. The original NIST-developed software is not subject to copyright protection within the United States under 17 U.S.C. § 105. The complete NIST Software Licensing Statement is preserved in LICENSE.md.

In compliance with NIST's stated requirement that modified works should carry a notice stating that you changed the software and should note the date and nature of any such change, this repository includes NOTICE.md summarising the modifications since the fork point.

This fork is maintained by Thomas Thurman (TRThurman Consulting) under the MIT License for code originating in this fork.

Citation

If you use this software in academic, standards, or regulatory work, please cite both:

The NIST original (the substrate this work builds on):

Krima, S., Barnard Feeney, A., and Astheimer, R. easyEXPRESS: A Visual Studio Code Extension for ISO 10303-11. U.S. National Institute of Standards and Technology, 2024. https://github.com/usnistgov/easy-express. Public-domain in the U.S. under 17 U.S.C. § 105.

This fork (when the modifications are material to the work cited):

Thurman, T. EXPRESSsuite. TRThurman Consulting, 2025–. https://github.com/TRThurman/EXPRESSsuite. MIT-licensed for code originating in this derivative.

A machine-readable Citation File Format entry is provided as CITATION.cff. GitHub renders this as a "Cite this repository" button on the repository home page; tools such as Zenodo and CFF-aware reference managers consume it directly.

If you have downstream-renamed or rebadged this software (e.g. as a derivative product with a different name), the citation requirement still applies to both the NIST original and this intermediate fork; see NOTICE.md for the chain of attribution.

Contributing

For bug reports and feature requests, please open an issue.

For code contributions, the development workflow is:

1. Fork the repository and create a topic branch.
2. Make changes; ensure npm run lint and npm test pass.
3. Open a pull request against main.

Larger changes (new viewer surfaces, parser changes, security model adjustments) are guided by the design protocol document — see DESIGN-viewers-integration.md for the phased process used for the 0.4.0 release.
