TASKING winIDEA Debug Extension for Visual Studio Code

Extension for debugging using winIDEA workspaces in Visual Studio Code.

More information on our website.

TASKING Hex Editor extension is needed for viewing debug memory and will be installed automatically.

Quick Setup

For initial setup, follow the Get Started with TASKING winIDEA walkthrough. If it doesn't open automatically on extension install, you can open it from the Welcome page, or from the command palette (Ctrl + Shift + p -> Welcome: Open Walkthrough -> Get Started with TASKING winIDEA)

The Walkthrough will guide you through the steps to install the necessary components, open an example workspace, and start debugging as quickly as possible.

Installing winIDEA

For this extension to work, an installation of winIDEA is needed. To install the latest version of winIDEA automatically:

1. Click Run and Debug tab
2. Click on the winIDEA Configuration title to open the dropdown menu
3. Click on the three dots and select Download latest version of winIDEA

The command can also be called from the command palette.

You will also be prompted to install the latest version whenever an update is available, or when you attempt to open a workspace when no version is installed.

Using a custom winIDEA version

If you prefer to use a version of winIDEA that you already have installed, you can also setup the extension to use it:

1. Click Run and Debug tab
2. Click on the winIDEA Configuration title to open the dropdown menu
3. Click on the three dots and select Select custom path to winIDEA install
4. Use the dialog to navigate to winIDEA install directory, and select winIDEA.exe

The command can also be called from the command palette.

Opening a Workspace

Creating a New Workspace

1. Open the winIDEA Configuration view
2. If open, close the current winIDEA workspace
3. If you want to create a blank workspace:
   1. Click on the New Workspace button
   2. Follow the New Workspace configuration wizard
   3. A blank workspace configured for your hardware will be opened
4. If you want to start from an winIDEA Example Workspace:
   1. Click on the Open Example Workspace button
   2. Choose an example for your target
   3. The example will be cloned and opened

Opening an existing winIDEA workspace

1. Open the winIDEA Configuration view
2. If open, close the current winIDEA workspace
3. Press the Select Workspace button
4. Select your winIDEA workspace .xjrf file
5. A VS Code workspace configured for your winIDEA workspace will be automatically generated and opened

Alternatively, you can also open .xjrf files in VSCode directly, and you will be given the option to convert them to a VSCode workspace.

Start debugging

To select a launch configuration, open the Run and Debug tab, and use the dropdown on the top left. By default, two launch configurations will be available:

1. winIDEA Download: This configuration will download the configured program file to target, reset it and start debugging.

2. winIDEA Reset: This configuration will only reset the target, load symbol files and start debugging without downloading the program files.

3. winIDEA Attach: This configuration will attach to an already running target.

You can add additional launch configurations to the .code-workspace file. Other parameters you can change are:

• stopOnEntryAt: On start debug, run program until this function.
• verifyDownload: After download, verify program.
• loadSymbolsOnly: Set to true to reset target without downloading
• showThreads: If an OS is loaded, show its threads in the Call Stack view

Building Examples

Examples with VS Code CMake are buildable with the CMake Tools extension. CMake and Ninja will be automatically installed and setup, you only need to set the path to the compiler folder.

Linux

• To use winIDEA installed through snap, set Custom install to true, and path to winIDEA to global.
• First start of winIDEA may time out due to wine setup taking a long time, opening workspace again should fix it.

Debug functionality

winIDEA Configuration view

This view contains all toggles and configuration windows available from winIDEA organized in a tree view. Press the save button to save and the X button to save and close the workspace, if you want to open a different one.

The dropdown in the title bar lists some useful commands, such as opening logs, opening extension settings, opening symbol browser etc.

If no workspace is opened, this view will contain buttons to open or create a workspace. Use:

• Open Workspace to open the currently configured workspace file,
• Select Workspace to select and open an existing .xjrf workspace file,
• New Workspace to create a new workspace, or
• Open Example Workspace to create a workspace from one of the winIDEA Example Workspaces.

Extension settings

To open settings for the winIDEA extension, open the dropdown menu in the winIDEA Configuration view and select Open extension settings. This will list all global settings under the User tab and settings for the current workspace under Workspace Some notable settings:

• Command Line Options: Pass these options to winIDEA when starting connection.
• Refresh SFR on Step: Automatically refresh the SFR view whenever the data may have changed. This may have a negative impact on performance.
• Show Window: show winIDEA GUI alongside vscode.

Other options will be set automatically using other commands.

Viewing log files

• Log output for the extension can be viewed through the output view (View -> open view -> output), select winIDEA debug.
• Unhandled exceptions will be reported to the output view, Extension host
• Log output from winIDEA can be opened through Command Palette: Open winIDEA log
• Log output from debug adapter can be opened through Command Palette: Open debug adapter log

SFRs view

This view contains a list of all available SFRs.

NOTE: by default, the SFR view does not update every step! Make sure to refresh it to ensure you get the latest values, or move the SFRs you want to monitor to the watch view. You can also enable automatic refresh in settings, but it may have a negative impact on performance.

• To refresh all values, press the refresh icon in view top right corner.
• Clicking on a group should expand it, loading all the children and their values.
• To edit a SFR, press the edit icon next to it. You can also use F2 to edit the last selected value.
• Right click -> add to watch will add the selected SFR to the watch view for easier monitoring.

Session Explorer view

Lists all configured SMPs, their cores and their statuses. Press on a core to switch debug focus to it.

Real-Time Watch view

Variables in the Real-time Watch view will update once per second. To add a variable, press the + button on the view, or right click on a variable in variables/code and select Add To Real-Time Watch.

Debug Memory view

Debug Memory view is implemented in the TASKING Hex Editor extension, which should be installed automatically. To open it, use the Open Debug Memory command, or use the View Binary Data button next to variables in any of the views.

• To go to a specific memory location, use the Go To Offset button in the memory views title bar, and enter the wanted offset.
• To go to a specific variable in memory, use the View binary data button next to variables, or use the Go To Variable button in the memory views title bar, and enter the wanted variable. The dropdown will list variables that are visible in the Variables view, so make sure to expand globals before using.

You can also use the view to edit debug memory: write your changes to the memory view, then save to write your changes to target.

Variables and Core Registers view

Global variables, local variables and registers are listed in the Variables view, which allows for monitoring, editing, adding to watch view and viewing in debug memory.

Sources

View all loaded source files in the Loaded Scripts view

Symbols

Use the Command Palette (Ctrl+Shift+P) and launch the TASKING winIDEA: Browse Symbols command to view all loaded symbols. The command can also be run from the winIDEA Configuration views drop down menu.

Hardware Breakpoints

Use the Command Palette (Ctrl+Shift+P) and launch the TASKING winIDEA: Setup Hardware Breakpoints command. This command is only available when debugging. The command can also be run from the winIDEA Configuration views drop down menu.
