Bugrock JSON UI Schemas

Screens

Name	Version
inventory_screen	>=0.12
start_screen	>=0.12
play_screen	>=0.12
pause_screen_trial	>=0.12 <0.16
trial_upsell_screen	>=0.12
xbl_login_screen	>=0.12
anvil_screen	>=0.13
chest_screen	>=0.13
furnace_screen	>=0.13
gamepad_layout_screen	>=0.13
language_choice_screen	>=0.13 <0.16
test_anims_screen	>=0.13
brewing_stand_screen	>=0.14
debug_screen	>=0.14
disconnect_screen	>=0.14
enchanting_screen	>=0.14
holographic_postrender_screen	>=0.14
hud_screen	>=0.14
invite_screen	>=0.14 <0.16
modal_screen	>=0.14
pocket_redstone	>=0.14 <0.16
portfolio_screen	>=0.14
progress_screen	>=0.14
redstone_screen	>=0.14
ui_holo_cursor	>=0.14
vr_alignscreen	>=0.14
vr_scheme_screen	>=0.14
achievement_screen	>=0.15
realms_create	>=0.15
realms_invitation	>=0.15 <0.16
realms_invitation_shell	>=0.15 <0.16
realms_pending_invitations	>=0.15
realms_settings_screen	>=0.15
resource_packs_screen	>=0.15
resource_pack_purchase_screen	>=0.15 <=1.4
skin_pack_purchase_screen	>=0.15
skin_picker_screen	>=0.15
store_screen	>=0.15 <=1.0
survey_screen	>=0.15
toast_screen	>=0.15
xbl_first_launch	>=0.15 <=1.19
xbl_failed	>=0.15 <=1.0
xbl_optional_signin	>=0.15
horse_screen	>=0.15
horse_screen_pocket	>=0.15
add_external_server_screen	>=0.16
anvil_screen_pocket	>=0.16
authentication_screen	>=0.16
beacon_screen	>=0.16
beacon_screen_pocket	>=0.16
brewing_stand_screen_pocket	>=0.16
chalkboard_screen	>=0.16
chat_screen	>=0.16
death_screen	>=0.16
enchanting_screen_pocket	>=0.16
file_upload_screen	>=0.16
furnace_screen_pocket	>=0.16
horse_screen	>=0.16
horse_screen_pocket	>=0.16
in_bed_screen	>=0.16
local_world_picker_screen	>=0.16
npc_interact_screen	>=0.16
pause_screen	>=0.16
pocket_containers	>=0.16
realms_whitelist (realms_allowlist >=1.16)	>=0.16 <=1.15
settings_screen	>=0.16
create_world_upsell_screen	>=1.0
credits_screen	>=1.0
global_pause_screen	>=1.0
manifest_validation_screen	>=1.0
mashup_screen	>=1.0 <=1.11
mashup_home_screen	>=1.0 <=1.11
mashup_panorama_screen	1.0
patch_notes_screen	>=1.0
structure_editor_screen	>=1.0
ugc_viewer_screen	>=1.0
world_templates_screen	>=1.0
coin_purchase_screen	>=1.1
command_block_screen	>=1.1
convert_purchases_to_xbl_screen	>=1.1
mashup_home_screen	>=1.1
mob_effect_screen	>=1.1
realms_purchase_info_screen	>=1.1 <=1.11
remix_preview_screen	>=1.1 <=1.7
safe_zone_screen	>=1.1
sign_screen	>=1.1
storage_management	>=1.1
store_home_screen	>=1.1 <=1.6
store_item_list_screen	>=1.1
trade_screen	>=1.1
trade_screen_pocket	>=1.1
third_party_store_screen	>=1.1
world_panorama_screen (panorama_screen >=1.16)	>=1.1 <=1.15
auto_save_info_screen	>=1.2
book_screen	>=1.2
comment_screen	>=1.2
feed_screen	>=1.2
how_to_play_screen	>=1.2
host_options_screen	>=1.2
late_join_pregame_screen	>=1.2
inventory_screen_pocket	>=1.2
manage_feed_screen	>=1.2
non_xbl_user_management_screen	>=1.2
permissions_screen	>=1.2
post_rating_screen	>=1.2
screenshot_screen	>=1.2
screenshot_picker_screen	>=1.2
server_form	>=1.2
server_item_purchase_screen	>=1.2 <=1.4
world_conversion_error_report_screen	>=1.2
xbl_console_signin	>=1.2
xbl_console_signin_succeeded	>=1.2
xbl_friend_finder	>=1.2
xbl_profile_card (profile_card >=1.13)	>=1.2 <=1.12
xbl_report_user	>=1.2 <=1.18
adhoc_inprogess_screen	>=1.4
adhoc_screen	>=1.4
hdr_calibration_screen	>=1.4
item_detail_description_screen	>=1.4
pack_settings_screen	>=1.4
simple_inprogress_screen	>=1.4
store_filter_menu_screen	>=1.4
store_search_screen	>=1.4
store_sort_menu_screen	>=1.4
store_inventory_screen	>=1.5
store_sales_item_list_screen	>=1.5
chat_settings_menu_screen	>=1.6
tabbed_upsell_screen	>=1.6
code_screen	>=1.7 <=1.14
store_data_driven_screen	>=1.7
sync_iaps_to_xbl_screen	>=1.7
expanded_skin_pack_screen	>=1.8
library_item_screen	>=1.8 <=1.14
library_modal_screen	>=1.8
library_screen	>=1.8 <=1.14
braze_screen	>=1.9 <=1.19
game_tip_screen	>=1.9
bundle_purchase_warning_screen	>=1.10
loom_screen	>=1.10
loom_screen_pocket	>=1.10
win10_trial_conversion_screen	>=1.10
blast_furnace_screen	>=1.11
cartography_screen	>=1.11
cartography_screen_pocket	>=1.11
grindstone_screen	>=1.11
grindstone_screen_pocket	>=1.11
perf_turtle	1.11 >=1.13
smoker_screen	>=1.11
stonecutter_screen	>=1.11
stonecutter_screen_pocket	>=1.11
trade_2_screen	>=1.11
trade_2_screen_pocket	>=1.11
update_version	>=1.11
authentication_modals	>=1.12
choose_realm_screen	>=1.12
content_log_history_screen	>=1.12
course_screen	>=1.12 <=1.14
pdp_screen	>=1.12
pdp_screenshots_section	>=1.12 <=1.16
account_transfer_error_screen	>=1.13
custom_templates_screen	>=1.13
world_conversion_complete_screen	>=1.13
day_one_experience_intro_screen	>=1.13
day_one_experience_screen	>=1.13
edu_play_screen	>=1.13 <=1.14
edu_pause_screen	>=1.13 <=1.14
edu_world_templates_screen	>=1.13 <=1.14
edu_worlds_screen	>=1.13 <=1.14
ip_join_screen	>=1.13 <=1.14
immersive_reader	>=1.13
joincode_entry_screen	>=1.13 <=1.14
lesson_quiz_screen	>=1.13 <=1.14
multiplayer_lesson_screen	>=1.13 <=1.14
realms_plus_ended_screen	>=1.13
persona_screen	>=1.13
edu_permissions_screen	>=1.13 <=1.14
profile_screen	>=1.13
realmsplus_upgrade_notice_screen	>=1.13
token_faq_screen	>=1.13
profile_card	>=1.13
confirm_msa_unlink_screen	>=1.14
gamepad_disconnected	>=1.14
edu_discovery_dialog	>=1.15
emote_wheel_screen	>=1.15
account_banned_screen	>=1.16 <=1.18
smithing_table_screen	>=1.16
smithing_table_screen_pocket	>=1.16
jigsaw_editor_screen	>=1.16
online_safety_screen	>=1.16
panorama_screen	>=1.16
realms_allowlist	>=1.16
store_gift_promotion_screen	>=1.16 <=1.20
cloud_upload_screen	>=1.17
realms_slots_screen	>=1.17
toolbox_mode_screen	>=1.17 <=1.18
storage_migration_generic_screen	>=1.18
update_dimensions	>=1.18
world_recovery_screen	>=1.18
xbl_immediate_signin	>=1.18
smithing_table_2_screen	>=1.19
smithing_table_2_screen_pocket	>=1.19
confirm_delete_account_screen	>=1.19
display_logged_error_screen	>=1.19
gathering_info_screen	>=1.19
notificationcenter_screen	1.19
persona_cast_character_screen	>=1.19
thanks_for_testing_screen	>=1.19
store_promo_timeline_screen	>=1.19
submit_feedback_screen	>=1.19
xbl_console_qr_signin	>=1.19
encyclopedia_screen	>=1.20
realmsPlus_purchase_warning_screen	>=1.20
csb_purchase_error_screen	>=1.20
csb_screen	>=1.20
csb_buy_now_screen	>=1.20
csb_purchase_amazondevicewarning_screen	>=1.20
csb_purchase_warning_screen	>=1.20
csb_view_packs_screen	>=1.20
csb_welcome_screen	>=1.20
persona_sdl	>=1.20
crafter_screen_pocket	>=1.21

Features

Feature	Version
Variables	>=0.14
_global_variables	>=1.2

UI Element Types

Name	Version	Allowed Properties
panel	>=0.12	Controls, Layout and Data Binding
input_panel	>=0.12	Input, Focus, Sound, Controls, Layout and Data Binding
image	>=0.12	Sprite, Controls, Layout and Data Binding
grid	>=0.12	Grid, Controls, Layout and Data Binding
grid_item	>=0.12 <=0.14	Controls, Layout and Data Binding
label	>=0.12	Text, Controls, Layout and Data Binding
button	>=0.12	Button, Input, Focus, Sound, Controls, Layout and Data Binding
screen	>=0.12	Screen, Sound, Controls, Layout and Data Binding
tab	>=0.12 <=0.16	Tab, Controls, Layout and Data Binding
scrollbar	>=0.12 <=0.14	Controls, Layout and Data Binding
scroll_box	>=0.12	Input, Controls, Layout and Data Binding
stack_panel	>=0.15	Stack Panel, Controls, Layout and Data Binding
toggle	>=0.14	Toggle, Input, Focus, Sound, Controls, Layout and Data Binding
slider	>=0.15	Slider, Input, Focus, Sound, Controls, Layout and Data Binding
slider_box	>=0.15	Slider Box, Input, Controls, Layout and Data Binding
dropdown	>=0.16	Dropdown, Toggle, Input, Focus, Sound, Controls, Layout and Data Binding
edit_box	>=0.13	Text Edit, Input, Focus, Sound, Button, Controls, Layout and Data Binding
custom	>=0.12	Custom, Controls, Layout and Data Binding
scroll_view	>=0.15	Scroll View, Input, Controls, Layout and Data Binding
scroll_track	>=0.15	Input, Controls, Layout and Data Binding
factory	>=0.14	Controls, Layout and Data Binding
selection_wheel	>=1.15	Selection Wheel, Input, Focus, Sound, Controls, Layout and Data Binding
grid_page_indicator	>=1.19	Grid Page Indicator, Grid, Controls, Layout and Data Binding
label_cycler	>=1.19	Label Cycler, Cycler, Controls, Layout and Data Binding
image_cycler	>=1.19	Image Cycler, Cycler, Controls, Layout and Data Binding
collection_panel	>=1.19	Controls, Layout and Data Binding
tooltip_trigger	>=1.21.80	Tooltip Trigger, Input, Focus, Controls, Layout and Data Binding
carousel_label	>=0.14? <=?	Carousel Label, Controls, Layout and Data Binding

Properties

Control

Name	Version	Type
controls	>=0.12	array of UI elements
variables	>=0.14	object or array of objects
visible	>=0.12	boolean
ignored		boolean
modifications		array of modifications
anims		array of strings
disable_anim_fast_forward		boolean
animation_reset_name		string
visible		boolean
enabled	>=0.13	boolean
layer	>=0.13	integer
z_order	0.12	integer
alpha	>=0.12	float (>=0.0 and <= 1.0)
propagate_alpha		boolean
clips_children	>=0.12	boolean
allow_clipping	>=0.13	boolean
clip_offset	>=0.13	Vector [x, y]
clip_state_change_event		string
enabled_scissor_test		boolean
property_bag	>=0.12	object
selected		boolean
use_child_anchors		boolean
grid_position	>=0.12	Vector [column, row]
debug		white, black, gray, red, blue, green, yellow or purple

Layout

Name	Version	Type
anchor_from	>=0.12	Value Version top_left >=0.12 top_middle >=0.12 top_right >=0.12 left_middle >=0.12 center >=0.12 right_middle >=0.12 bottom_left >=0.12 bottom_middle >=0.12 bottom_right >=0.12 Enum
anchor_to	>=0.12	Value Version top_left >=0.12 top_middle >=0.12 top_right >=0.12 left_middle >=0.12 center >=0.12 right_middle >=0.12 bottom_left >=0.12 bottom_middle >=0.12 bottom_right >=0.12 Enum
contained	>=0.12	boolean
draggable	>=0.12	boolean
follows_cursor	>=0.12	boolean
offset	>=0.12	Vector [x, y]
size	>=0.12	Vector [width, height]
max_size	>=0.16	Vector [width, height]
min_size	>=0.16	Vector [width, height]
inherit_max_sibling_width	>=1.2	boolean
inherit_max_sibling_height	>=1.2	boolean
use_anchored_offset	>=1.1	boolean

Data Binding

Name	Version	Type
bindings	>=0.12	array of BindingItem
binding_collection_name	>=0.12 <=?	string

BindingItem

Name	Version	Type
ignored		boolean
binding_type	>=0.12	global, collection, collection_details or view
binding_name	>=0.12	string
binding_name_override	>=0.12	string
binding_collection_name	>=0.13	string
binding_collection_prefix	>=0.15	string
binding_condition	>=0.14	always, visible, once, always_when_visible or visibility_changed
source_control_name	>=0.15	string
source_property_name	>=0.15	string
target_property_name	>=0.15	string
resolve_sibling_scope	>=1.1	boolean

Stack Panel

Name	Version	Type
orientation	>=0.15	Value Version vertical horizontal

Text

Name	Version	Type
text	>=0.12	string
color	>=0.12	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
locked_color	>=0.16	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
shadow	>=0.12	boolean
font_size	>=0.12	small, normal, large or extra_large
font_scale_factor	>=1.11	float (0 >=)
localize	>=0.13	boolean
line_padding	>=1.11	number
font_type	>=0.14	string
backup_font_type	>=1.13	string
text_alignment	>=1.1	left,center and right
hide_hypen	>=1.11	boolean
locked_alpha	>=0.16	float (0.0 >= and <= 1.0)
enable_profanity_filter	>=1.11	boolean
notify_on_ellipses	>=1.11	array of strings
alignment	>=0.12 <=1.0	left,center or right
use_place_holder	>=0.14 <= 0.16	boolean
place_holder_text	>=0.14 <= 0.16	string
place_holder_text_color	>=0.14 <= 0.16	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue

Sprite

Name	Version	Type
texture	>=0.12	string
uv	>=0.12	Vector [u, v]
uv_size	>=0.12	Vector [width, height]
nineslice_size	>=0.12	integer, Vector [x, y] or Vector [x0, y0, x1, y1]
base_size	>=1.2	Vector [width, height]
color	>=0.13	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray, blue
tiled	>=0.13	boolean, x, y, xy or yx
tiled_scale	>=1.0	Vector [x, y]
clip_direction	>=0.12	left, right, up, down or center
clip_ratio	>=0.12	float (0.0 >= and <= 1.0)
clip_pixelperfect	>=0.15	boolean
keep_ratio	>=1.12	boolean
bilinear	>=1.11	boolean
fill	>=0.16	boolean
grayscale	>=0.16	boolean
force_texture_reload	>=1.1	boolean
$fit_to_witdh	>=1.11	boolean
zip_folder	>=0.15	string
texture_file_system	>=0.15	RawPath or InAppPackage
allow_debug_missing_texture	>=1.11	boolean
pixel_perfect	>=1.11	boolean

TTS

Name
tts_name
tts_control_header
tts_section_header
tts_control_type_order_priority
tts_index_priority
tts_toggle_on
tts_toggle_off
tts_override_control_value
tts_inherit_siblings
tts_value_changed
ttsSectionContainer
tts_ignore_count
tts_skip_message
tts_skip_children
tts_value_order_priority
tts_play_on_unchanged_focus_control
tts_ignore_subsections
text_tts

Sound

Name	Version	Type
sound_name	>=0.12	string
sound_pitch	>=0.12	string
sound_volume	>=0.12	float
sounds		array of SoundItem

SoundItem

Name	Type
sound_name	string
sound_pitch	float
sound_volume	float
min_seconds_between_plays	number
event_type	string
button_name	string

Button

Name	Version	Type
default_control	>=0.12	string
hover_control	>=0.12	string
pressed_control	>=0.12	string
locked_control	>=0.16	string

Toggle

Name	Version	Type
radio_toggle_group	>=0.14	boolean
toggle_name	>=0.14	string
toggle_default_state	>=0.14	boolean
toggle_group_forced_index	>=0.14	integer
toggle_group_default_selected	>=0.14	integer
reset_on_focus_lost	>=1.14	boolean
toggle_on_button	>=1.11	string
toggle_off_button	>=1.11	string
enable_directional_toggling	>=1.11	boolean
toggle_grid_collection_name	>=0.14	string
checked_control	>=0.14	string
unchecked_control	>=0.14	string
checked_hover_control	>=0.14	string
unchecked_hover_control	>=0.14	string
checked_locked_control	>=0.14	string
unchecked_locked_control	>=0.14	string
checked_locked_hover_control	>=0.16	string
unchecked_locked_hover_control	>=0.16	string

Slider

Name	Type
slider_track_button	string
slider_small_decrease_button	string
slider_small_increase_button	string
slider_steps	integer
slider_direction	vertical or horizontal
slider_timeout	number
slider_collection_name	string
slider_name	string
slider_select_on_hover	string
slider_selected_button	string
slider_deselected_button	string
slider_box_control	string
background_control	string
background_hover_control	string
progress_control	string
progress_hover_control	string

Unused/No Longer Works

Name	Type
slider_render_bar_background_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
slider_render_bar_progress_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
slider_render_bar_outline_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
slider_render_bar_background_hover_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
slider_render_bar_progress_hover_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
slider_render_bar_outline_hover_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue

Slider Box

Name	Type
indent_control	string

Dropdown

Name	Version	Type
dropdown_name	>=0.16	string
dropdown_content_control	>=0.16	string
dropdown_area	>=0.16	string

Grid

Name	Type
grid_dimensions	Vector[columns, rows]
maximum_grid_items	integer (0 >=)
grid_dimension_binding	string
grid_rescaling_type	vertical or horizontal
grid_fill_direction	vertical or horizontal
precached_grid_item_count	integer
grid_item_template	string

Text Edit

Name	Type
text_box_name	string
text_edit_box_grid_collection_name	string
constrain_to_rect	boolean
enabled_newline	boolean
text_type	ExtendedASCII, IdentifierChars or NumberChars
max_length	integer (0 >=)
text_control	string
place_holder_control	string
can_be_deselected	boolean
always_listening	boolean
virtual_keyboard_buffer_control	string

Scroll View

Name	Type
scrollbar_track_button	string
scrollbar_touch_button	string
scroll_speed	number
gesture_control_enabled	boolean
always_handle_scrolling	boolean
touch_mode	boolean
scrollbar_box	string
scrollbar_track	string
scroll_view_port	string
scroll_content	string
scroll_box_and_track_panel	string
jump_to_bottom_on_update	boolean
allow_scroll_even_when_content_fits	boolean

Focus

Name	Type
default_focus_precedence	integer
focus_enabled	boolean
focus_wrap_enabled	boolean
focus_magnet_enabled	boolean
focus_identifier	string
focus_change_down	string
focus_change_up	string
focus_change_left	string
focus_change_right	string
focus_mapping	array of FocusMappingItem
focus_container	boolean
use_last_focus	boolean
focus_navigation_mode_left	string
focus_navigation_mode_right	string
focus_navigation_mode_down	string
focus_navigation_mode_up	string
focus_container_custom_left	contained, none, custom, stop or empty string
focus_container_custom_right	array of FocusCustomItem
focus_container_custom_down	array of FocusCustomItem
focus_container_custom_up	array of FocusCustomItem

Unused/No Longer works

These properties were misspelled. It took a while for the devs to notice. Classic json ui devs...

Name	Type
focus_nagivation_mode_right	string
focus_nagivation_mode_left	string
focus_nagivation_mode_down	string
focus_nagivation_mode_up	string

FocusMappingItem

Name	Type
focus_identifier	string
focus_change_right	string
focus_change_left	string
focus_change_up	string
focus_change_down	string

FocusCustomItem

Name	Type
other_focus_container_name	string

Input

Name	Type
button_mappings	array of ButtonMappingItem
modal	boolean
inline_modal	boolean
always_listen_to_input	boolean
always_handle_pointer	boolean
always_handle_controller_direction	boolean
hover_enabled	boolean
prevent_touch_input	boolean
consume_event	boolean
consume_hover_events	boolean
gesture_tracking_button	string

ButtonMappingItem

Name	Version	Type
from_button_id		string
to_button_id		string
button_up_right_of_first_refusal		boolean
mapping_type		global, focused, pressed or double_pressed
ignored		boolean
input_mode_condition		any, gaze, not_gaze, not_gamepad or gamepad_and_not_gaze
ignore_input_scope		boolean
scope		global, view or controller
consume_event		boolean
handle_select		boolean
handle_deselect		boolean
condition	<?	Value Version none >=0.12 hover >=0.12 focus >=0.12 gesture >=0.12

Screen

Name	Type
render_only_when_topmost	boolean
screen_not_flushable	boolean
always_accepts_input	boolean
render_game_behind	boolean
absorbs_input	boolean
is_showing_menu	boolean
is_modal	boolean
should_steal_mouse	boolean
low_frequency_rendering	boolean
screen_draws_last	boolean
vr_mode	boolean
force_render_below	boolean
send_telemetry	boolean
close_on_player_hurt	boolean
cache_screen	boolean
load_screen_immediately	boolean
gamepad_cursor	boolean
gamepad_cursor_deflection_mode	boolean
should_be_skipped_during_automation	boolean

Custom

Name

Type

renderer

hover_text_renderer, 3d_structure_renderer, splash_text_renderer, ui_holo_cursor, trial_time_renderer, panorama_renderer, actor_portrait_renderer, banner_pattern_renderer, live_player_renderer, web_view_renderer, hunger_renderer, bubbles_renderer, mob_effects_renderer, cursor_renderer, progress_indicator_renderer, camera_renderer, horse_jump_renderer, armor_renderer, horse_heart_renderer, heart_renderer, hotbar_cooldown_renderer, hotbar_renderer, hud_player_renderer, live_horse_renderer, holographic_postrenderer, enchanting_book_renderer, debug_screen_renderer, gradient_renderer, paper_doll_renderer, name_tag_renderer, flying_item_renderer, inventory_item_renderer, credits_renderer, vignette_renderer, progress_bar_renderer, debug_overlay_renderer, background_renderer, bundle_renderer, editor_gizmo_renderer, dash_renderer, bohr_model_renderer or toast_renderer Also in Netease Edition: netease_paper_doll_renderer or netease_mini_map_renderer

Progress Bar Renderer

Name	Type
primary_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
secondary_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue

Gradient Renderer

Name	Type
gradient_direction	vertical or horizontal
color1	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
color2	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue

Name Tag Renderer

Name	Type
text_color	Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
background_color	Vector [red, green, blue, alpha] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue

Paper Doll Renderer

Name	Type
camera_tilt_degrees	number
starting_rotation	number
use_selected_skin	boolean
use_uuid	boolean
use_skin_gui_scale	boolean
use_player_paperdoll	boolean
rotation	number

Also In Netease Edition

Name	Type
modelsize	number
animation_looped	boolean
animation	string

Netease Paper Doll Renderer

Name	Type
screen_offset	Vector [x, y]
screen_scale	float
mob_body_rot_y	number
mob_head_rot_y	number
init_rot_y	number
skeleton_model_name	string
entity_identifier	string
modelsize	number
animation_looped	boolean
animation	string

Netease MiniMap Renderer

Name	Type
use_default_face_icon	boolean
face_icon_bg_color	Vector [red, green, blue, alpha] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
enable_live_update	boolean
live_update_interval	integer
highest_y	0 or -1

Grid Page Indicator

Name	Type
grid_item_when_current	string
grid_item_when_not_current	string
cycler_manager_size_control_target	string

Selection Wheel

Name	Type
inner_radius	number
outer_radius	number
state_controls	array of strings
slice_count	integer
button_name	string
iterate_left_button_name	string
iterate_right_button_name	string
initial_button_slice	integer

Cycler

Name	Type
target_cycler_to_compare	string
next_sub_page_button_name	string
prev_sub_page_button_name	string

Label Cycler

Name	Version	Type
text_labels		array of strings

Image Cycler

Name	Version	Type
images		array of ImageItem

ImageItem

Name	Type
texture_path	string

Tooltip Trigger

Name	Type
tooltip_name	string
tooltip_top_content_control	string
tooltip_bottom_content_control	string
tooltip_area	string (control name)
tooltip_tts_value	string

Tab

Name	Version	Type
tab_index		integer
tab_control		string
tab_content		string

Carousel Label

Name	Version	Type
always_rotate		boolean
rotate_speed		number
hover_color		Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
hover_alpha		float (0.0 >= and <= 1.0)
pressed_color		Vector [red, green, blue] or white, black, yellow, orange, green, purple, nil, cyan, red, grey, gray or blue
pressed_alpha		float (0.0 >= and <= 1.0)

Operations

In Size/Offset/MaxSize/MinSize/Variables

+ and -

In Bindings

<, >, +, -, * and /

Collection Names

Name	Version	Works in (Screen)
armor_items	>=0.12
hotbar_items	>=0.12
inventory_items	>=0.12
crafting_input_items	>=0.12
#network_world_item	>=0.12	play
#local_world_item	>=0.12	play

Button IDs

Name	Version	Works in (Screen)
button.menu_select		*
button.menu_ok		*
button.scrollbar_skip_track
button.menu_up		*
button.menu_down		*
button.menu_left		*
button.menu_right		*
button.menu_select		*
button.menu_play
button.menu_buy_game
button.menu_continue
button.menu_cancel		*
button.menu_exit		*
button.menu_local_world_item
button.menu_local_world_item_edit
button.menu_network_world_item
button.menu_network_world_item_remove
button.menu_local_world_create
button.menu_network_add_external
button.menu_tab_left
button.menu_tab_right
button.armor_take_place
button.menu_secondary_select
button.controller_select
button.menu_auto_place
button.controller_secondary_select
button.armor_auto_place
button.menu_inventory_drop
button.armor_drop_one
button.menu_inventory_drop_all
button.armor_drop_all
button.menu_double_select
button.armor_coalesce_stack
button.crafting_in_take_all_place_all
button.crafting_in_take_half_place_one
button.crafting_in_auto_place
button.crafting_in_drop_one
button.crafting_in_drop_all
button.crafting_in_coalesce_stack
button.crafting_out_take_one
button.crafting_out_auto_place_max
button.crafting_out_drop_one
button.crafting_out_drop_all
button.inventory_take_all_place_all
button.inventory_take_half_place_one
button.inventory_auto_place
button.inventory_drop_one
button.inventory_drop_all
button.inventory_coalesce_stack
button.hotbar_take_all_place_all
button.hotbar_take_all_place_all
button.hotbar_take_half_place_one
button.hotbar_auto_place
button.hotbar_drop_one
button.hotbar_drop_all
button.hotbar_coalesce_stack
button.menu_inventory_cancel
button.cursor_drop_all
button.cursor_drop_one

Binding Names

Name	Version
#button_left_trigger_description
#button_right_trigger_description
#button_dpad_description
#button_thumbstick_description
#gamepad_helper_visible
#button_a_description
#button_b_description
#button_x_description
#button_y_description
#development_version
#version
#playername
#header
#description_1
#description_2
#file_size
#local_world_item_grid_dimension
#player_count
#game_online
#game_unavailable
#game_offline
#game_type_external
#game_type_remote
#game_type_xbox_live
#network_world_item_grid_dimension
#local_world_item_count
#network_world_item_count
#inventory_stack_count
#item_durability_visible
#item_durability_total_amount
#item_durability_current_amount
#crafting_selected_item
#crafting_selected_item_stack_count
#progress_bar_visible
#progress_bar_total_amount
#progress_bar_current_amount
#survival_crafting_output_item
#survival_crafting_output_hover_text
#survival_crafting_output_item_stack_count
#work_bench_output_item
#work_bench_output_hover_text
#work_bench_output_item_stack_count
#stone_cutter_output_item
#stone_cutter_output_hover_text
#stone_cutter_output_item_stack_count
