llmdbg for VS Code

This extension connects VS Code's debugger UI to the bundled llmdbg Python Debug Adapter Protocol implementation. On first use it creates a private Python environment in VS Code's per-extension storage. It does not use or modify the opened workspace's virtual environment. The private environment owns the model runtime dependencies, including gb10-load-llm, Transformers, and PyTorch. Environment creation and dependency installation use uv, allowing cached packages to be shared efficiently across environments. After this release is active, installing a newer llmdbg VSIX automatically reloads the VS Code window by default. Set llmdbg.autoReloadAfterUpdate to false to opt out.

Prototype quick start

1. Run llmdbg: Create Starter Files from the Command Palette, or create/open a .llmdbg.py Python model program (recommended) or legacy .llmdbg file. The command creates examples for GPT-2 and every supported Qwen3.5 size (0.8B, 2B, 9B, and 27B), plus matching .vscode/launch.json entries, without overwriting existing files.
2. Press F5 while that file is active. If prompted, select llmdbg.
3. Wait for the private debugger environment to be created on first use.
4. Expand Variables and use Step Over to advance through model layers.

VS Code assigns *.llmdbg.py the dedicated llmdbg Python language mode. This keeps Python highlighting but makes F5 select llmdbg; ordinary *.py files continue to use the normal Python debugger.

The Python format uses from llmdbg import gpt2, debug, ordinary functions, loops, indexing, and slicing. See the repository gpt2.llmdbg.py example. Tensor handles keep model tensors in llmdbg's runtime, and assignments such as hidden[1843] = 0 become replayable interventions. The compact format remains available; for example:

model = "openai-community/gpt2"
revision = "main"
device = "auto"
dtype = "auto"
prompt = "The capital of France is"
token = 3
stop_on_entry = false

def attention():
    layernorm
    qkv_projection
    attention_mixing
    output_projection
    residual_add

def mlp():
    layernorm
    expansion
    gelu
    projection
    residual_add

submodule = "token_embedding"

layer = 0
attention()
mlp()

layer = 1
attention()
mlp()

The extension can start directly from the active .llmdbg file, so a launch.json is optional. If one is used, it only needs a llmdbg launch with "config": "${file}".

Runtime backends

The extension owns a private Python environment and selects its PyTorch backend automatically. Windows and Linux use an NVIDIA CUDA wheel when nvidia-smi reports a supported driver; Apple Silicon macOS uses MPS; other supported systems use CPU. Current PyTorch releases no longer provide Intel macOS wheels, so automatic macOS setup requires Apple Silicon. Model programs should normally specify device="auto" and dtype="auto". The automatic dtype is BF16 on capable CUDA GPUs, FP16 on other CUDA GPUs and MPS, and FP32 on CPU.

Run llmdbg: Show Runtime Diagnostics to see the resolved backend, PyTorch build, CUDA/MPS availability, GPU, and memory. Run llmdbg: Rebuild Python Runtime to repair the private environment or apply a backend override.

The debugger keeps that same .llmdbg document active while stepping. Runtime state appears in the debugger panels; it does not create or switch to a second *.execution.llmdbg editor and never rewrites the configuration file. After layer = N, each attention() or mlp() call selects the corresponding transformer-block operation and can receive a breakpoint. The older explicit submodule = "transformer.h.N.mlp" spelling remains supported. Repeated assignments are intentionally valid in the llmdbg source language; this file is not TOML. Unlisted model operations are omitted from the debug trace.

Use Step Into (F11) at an attention() or mlp() call to enter its definition above. The active line advances through the five internal operations with F10, while the outer call remains the parent stack frame. Use Shift+F11 to finish the submodule and return to the next outer operation. Breakpoints can be placed directly on those internal operation lines; Continue enters the corresponding call and stops on the selected line.

Set token = 3 in the source to make that zero-based position the default for ordinary breakpoints. A conditional breakpoint such as token=4 overrides the default for one submodule. In a .llmdbg.py program, comment out the token = N assignment to let ordinary breakpoints stop at every token position; the existing with debug(..., token=token) call may remain unchanged. llmdbg prefills earlier tokens into the KV cache and executes the selected token as a one-token cached forward pass. The Token scope shows its position, token ID, decoded text, and prompt prefix. Use layer=6 to stop only in zero-based transformer block 6. Combine filters with token=4, layer=6; llmdbg parses the condition without assigning to the Python-like layer local.

Watch one zero-based dimension with residual_stream[42], output[42], input[42], or delta[42]. Run llmdbg: Plot Current Vector to open a Matplotlib workbench. Supply a vector expression or pasted list, select an editable named plotting snippet, and render a PNG. Snippets are persisted in VS Code extension storage as *.plot.py files. Each defines plot(vector, vector_name, plt, np) and returns a Matplotlib figure, so the file remains valid Python without unresolved injected globals. Compact edit/new/trash icons open the files in VS Code, create them, or move them to the system trash; the plot panel itself does not embed a code editor. Use the Lens button beside the plot icon in the debug toolbar after an MLP GELU activation. Its dedicated Neuron Lens panel shows the five most active neurons and, for each neuron, the top tokens from its W_down → W_unembed output direction with token IDs and direction logits. Qwen3.5 0.8B, 2B, 9B, and 27B additionally show each raw activation relative to a packaged per-layer calibration scale, including its measured sign side. GPT-2 has the same calibrated relative-activation display for its post-GELU MLP hidden activations. Choose J-Lens to transport each direction through an ordinary averaged Jacobian, R-Lens to use the RelP transport map, or All lenses to compare both with the direct Logit Lens. Lens artifacts are downloaded lazily from sida/llmdbg on Hugging Face and cached locally. The catalog covers Qwen3.5 2B, 9B, and 27B with both J-Lens and R-Lens maps (and also retains the earlier 0.8B maps). Large 9B/27B files resolve to the R-Lens authors' pinned, checksum-verified release rather than being duplicated.

The methods are from Verbalizable Representations Form a Global Workspace in Language Models (J-Lens) and R-Lens: Making J-Lens More Faithful on Early Layers. The debugger also exposes explicit Residual stream (output) and Delta scopes.

Attention stops expose their 768D LayerNorm output, combined 2304D QKV projection, 768D attention-mixing result, and 768D output projection. Watch these as attention_qkv[42], attention_mixing[42], and attention_projection[42]. MLP stops additionally expose the 3072D linear expansion before activation, the 3072D expansion after GELU, and the 768D projection. These appear as debugger scopes and plot choices and support indexed Watches: layernorm[42], mlp_expansion_pre_activation[42], mlp_expansion[42], and mlp_projection[42].

At an MLP stop, expand Top activated neurons to inspect the five largest post-GELU activations. Every neuron includes its output-direction norm, five direct vocabulary projections through W_down @ W_unembed, and five scores scaled by the current activation. Add top_neurons to Watch to keep the expandable neuron and token results updated while stepping between MLP stops.

Stops occur before the highlighted submodule. After Step Over, its values appear as the previous operation's output. Use Set Value on Watch entries such as output[42], mlp_expansion[1843], or top_neurons[0].activation to replay the token with that intervention and observe changed downstream layers.

The prototype loads GPT-2 through gb10-load-llm, captures embedding, attention, and MLP outputs, and shows a logit-lens interpretation at every stop. The Debug Console supports layer, operation, meaning, input, and output. The Variables pane exposes a frame-aware Local variables scope with source names such as model, prompt, tokens, token_pos, x, layer, and completed function locals. Values that do not exist yet—such as x before token embedding—are omitted. The same names work in Watch, hover, and the Debug Console.

The model is lazy-loaded on the first F5 and kept in a persistent host owned by the extension. Ending a debug session does not unload its GPU tensors. Later F5 runs with the same model, revision, device, and dtype reuse the resident model and perform only the prompt forward pass. Changing any of those model settings replaces the resident model; closing or reloading VS Code releases it.

During extension development, set llmdbg.developmentSourcePath in workspace settings to the directory containing the llmdbg Python package. Python changes are then used on the next debug session without rebuilding the VSIX.
