RailsForge — Supercharged Ruby & Rails IDE

The all-in-one developer platform for Ruby and Ruby on Rails in VS Code & Cursor.

Why RailsForge?

Developers working with Ruby and Rails typically have to install 8 to 12 separate extensions (LSP, RuboCop, Brakeman, route finders, ERB helpers, test runners, and AI plugins) that do not share state.

RailsForge replaces this fragmented toolchain with a single, highly integrated extension. It features deterministic runtime environment detection, Hotwire/Stimulus intelligence, native VS Code Test Explorer integration, zero-downtime migration diagnostics, and a grounded local AI agent (@rails).

Core Features

⚡ 1. ActiveRecord Schema Peek & Association Explorer

• Instant Schema Tooltips: Hover over any ActiveRecord model (User, Order, Account) to view an instant Markdown table of database columns, types, nullability, defaults, and foreign keys directly from db/schema.rb.
• Zero Configuration: Automatically watches db/schema.rb and re-indexes on migration runs.

🚀 2. Fast MVC & Resource Navigation

Quickly jump across related Rails companion files using ergonomic keybindings:

🛣️ 3. Real-Time Route Resolver & Path Helpers

• URL Helper Autocompletion: Autocomplete named route helpers like users_path, edit_order_url, and api_v1_products_path.
• Interactive Route Search: Press Alt+R R to search all defined routes, HTTP verbs, URL patterns, and controller#action mappings.

⚡ 4. Native Hotwire, Stimulus & Turbo Orchestration

• Stimulus Autocompletion: Dynamically indexes app/javascript/controllers/ to autocomplete data-controller, data-action (click->controller#action), and data-*-target inside .html.erb, .haml, and .slim.
• Turbo Frame Navigation: Jump directly to definition and find references for <%= turbo_frame_tag "cart" %> and <turbo-frame id="cart"> across view templates.

🧪 5. Next-Gen Testing & FactoryBot Intelligence

• Test Explorer Integration: Automatically populates the VS Code Test sidebar with discovered RSpec (spec/) and Minitest (test/) hierarchies.
• FactoryBot Jump to Definition: Ctrl+Click / Cmd+Click on create(:user), build(:order), or build_stubbed(:account) jumps directly to its declaration in spec/factories/*.rb.
• Inline CodeLens: Directly above any describe, context, it, or test block:
  • ▶ Run Test — Executes the specific test line in an isolated terminal.
  • 🐞 Debug (rdbg) — Launches the Ruby 3.1+ native debugger (rdbg) session.

🏛️ 6. Design Principles Engine (SOLID, DRY, KISS, YAGNI & Demeter)

• SRP (Single Responsibility): Flags Fat Models and Fat Controllers ($> 200$ LOC or $> 10$ actions) with 1-click QuickFix: "Extract to Service Object" — a single WorkspaceEdit that creates the new service file and replaces only the selected code, leaving the rest of the file untouched.
• Law of Demeter: Detects deep association violations (user.account.billing.address.city) with a real Quick Fix that inserts delegate :method, to: :assoc for you.
• KISS (Keep It Simple): Warns against unnecessary dynamic metaprogramming (define_method, class_eval) for static logic.
• YAGNI (You Aren't Gonna Need It): Flags unused private helper methods with a Quick Fix that deletes the whole unused method.
• Hard-Coded Collaborators: MinimalDependencyGraph flags PaymentGatewayService.call(...)-style references to other indexed services/queries/policies and offers "Inject X via constructor" — adds a keyword constructor param and rewrites call sites in that file to use it.
• ✨ AI Suggest Fix: Every principle diagnostic also offers an AI-generated fix (via the local @rails agent) alongside the deterministic one, plus RailsForge: Fix All Deterministic Principle Violations in File to batch-apply the non-AI fixes.

📖 7. Version-Aware Documentation & Style Guide Engine

• Contextual Hover Docs: Hovering over core Rails DSLs (has_many, belongs_to, turbo_stream, before_action, delegate) renders concise explanations, code snippets, and direct links to official Rails Guides and the community Ruby Style Guide.

📊 8. RailsForge Architecture & Health Sidebar

Dedicated Activity Bar Panel displaying:

• Runtime Environment: Active Ruby, Rails, Hotwire, Testing framework, and migration safety status.
• Database & Models: Indexed table counts and column breakdowns.
• Routes & Hotwire: Route counts and registered Stimulus controller mappings.

🛡️ 9. DevSecOps & Zero-Downtime Migration Safety

• RuboCop Real-Time Engine: Live diagnostics, 1-click line disables (# rubocop:disable ...), and safe (-a) or unsafe (-A) autocorrect on save.
• Brakeman Security Audits: 1-click vulnerability scanning for SQL injection, mass assignment, XSS, and unpermitted parameters.
• Bundler-Audit Dependency Scanner: Audits Gemfile.lock for known CVEs.
• Strong Migrations Analyzer: Live linter for db/migrate/*.rb warning against table-locking operations with 1-click QuickFixes (algorithm: :concurrently).

🧱 10. Architecture & Refactoring Tools

• Extract to Service Object: Select business logic in controllers or models and extract it into a clean app/services/[name]_service.rb implementing the ApplicationService.call pattern.
• Extract to Query Object: Move complex ActiveRecord query chains into app/queries/[name]_query.rb.

🧩 12. Living Pattern Catalog ("How We Do X Here")

Unlike the static Refactoring Guru catalog (§10), this indexes your own project's app/services, app/queries, app/forms, app/policies, app/decorators, and concerns as you work:

• CodeLens on every Service/Query/Form/Policy class: 📋 N similar patterns in this project.
• RailsForge: Show Similar Patterns in This Project — quick-pick of the closest existing implementations (ranked by name and public-method overlap), so you check for prior art before writing a new CreateXService from scratch.
• Live re-indexing on file save/create/delete — no separate build step.
• Feeds directly into the @rails agent's grounding (below), so generated code is steered toward your existing patterns instead of reinventing them.

🔗 13. Cross-File "Related Files" CodeLens & Hover

Stops the "open 5-6 files to understand this class" loop:

• On a model (app/models/*.rb): CodeLens above the class shows 🔗 3 Services · 2 Queries · 1 Policy · 6 Specs — every indexed pattern that references the model by name or by Model.find/.create/.where-style usage, plus its RSpec/Minitest spec count.
• On a service/query/policy/decorator: CodeLens shows 🔗 Called by 7 · Depends on 3 · 2 Specs, sourced from the same collaborator graph the "Inject via constructor" Quick Fix uses (§6).
• Hover the class definition line for the same information inline, without a click.
• RailsForge: Show Related Files opens a quick-pick of everything found — services, queries, policies, callers, collaborators, and specs — each jumping straight to the right line.

💎 14. Standalone Ruby Scripts & Gem Support

RailsForge activates on any Ruby file, Gemfile, or .rb script — not only full Rails apps — and adjusts what it claims accordingly:

• hasRails detection: EnvironmentDetector only reports a Rails version when rails is an actual Gemfile.lock dependency. A standalone gem or script gets hasRails: false instead of a fabricated Rails version, and the Architecture sidebar shows "Not a Rails app" rather than a misleading Rails line.
• @rails agent grounding adapts: for a non-Rails project, the system prompt drops the "strictly uses Rails X" constraint and Rails-specific advice (Service Objects, N+1 prevention) in favor of plain-Ruby/SOLID guidance grounded only in gems that are actually declared as dependencies — it won't assume ActiveRecord/ActionController exist.
• Pattern catalog works in lib/, not just app/: ProjectPatternIndexer matches services/, queries/, forms/, policies/, decorators/, and concerns/ directories anywhere in the path, so a gem's lib/my_gem/services/*.rb is indexed the same way app/services/*.rb is — CodeLens, "show similar patterns", and the dependency graph all work unmodified.
• SRP still flags fat classes in lib/, just with generic "split this up" guidance instead of the Rails-specific "extract to app/services" quick fix, since a gem has no app/ convention to extract into.
• Still Rails-only: schema/route indexing, MVC navigation, migration safety, and Hotwire/Stimulus tooling need db/schema.rb/config/routes.rb/app/ structure that a plain gem or script doesn't have, and simply do nothing rather than error.

🧠 15. Semantic Code Search

RailsForge: Semantic Search — find existing code by meaning, not just name: type "charge a card" or "send a welcome email" and get ranked matches across your indexed Services/Queries/Policies/Forms/Decorators, even when the class name doesn't contain your words.

• Embedding-based when available: uses a local Ollama embedding model (railsForge.ollama.embeddingModel, default nomic-embed-text — pull it separately with ollama pull nomic-embed-text) to rank results by cosine similarity. Embeddings are cached in memory per pattern and only recomputed when that pattern's content actually changes — no SQLite/vector DB dependency.
• Automatic keyword fallback: if Ollama or the embedding model isn't available, search transparently falls back to token-overlap keyword matching over pattern names, public methods, and preview text, so the command always returns something useful instead of failing outright. Results are labeled 🧠 (semantic) or 🔤 (keyword) so you know which mode answered.
• Select a result to jump straight to that file and line.

🤖 11. Grounded Local AI Agent (@rails)

Powered by local Ollama (qwen2.5-coder:14b / 7b):

• Version Anti-Hallucination: Automatically discovers active Ruby and Rails versions from Gemfile.lock and .ruby-version, constraining the AI to compatible APIs only.
• Context Grounding: Injects relevant database schema tables, column definitions, route mappings, and a summary of existing Service/Query/Form/Policy patterns into prompts, with an explicit instruction to reuse or extend a close match before generating new code.
• Slash Commands in Chat:
  • @rails /explain — Explain complex queries, scopes, and associations.
  • @rails /service — Scaffold clean Service Objects with Result monads.
  • @rails /scaffold — Generate convention-compliant models, controllers, and migrations.
  • @rails /spec — Generate complete RSpec request and unit specs using FactoryBot.
  • @rails /optimize — Detect N+1 query risks and missing eager loads (.includes).
  • @rails /migrate — Generate safe, reversible ActiveRecord migrations.

Command Palette (Ctrl+Shift+P / Cmd+Shift+P)

Several of these only show in the palette for the relevant project type — see FEATURES.md §6.

Configuration Settings

Every setting lives under railsForge.* and works at either the user level (global settings.json) or the workspace level (.vscode/settings.json, wins over user settings) — there's nothing extension-specific to set up for that, it's how VS Code settings scoping already works. Full reference with defaults, live-vs-reload behavior, and descriptions: FEATURES.md §7.

{
  // Exclude project-specific directories from every RailsForge scan, on top of
  // the built-in node_modules/vendor/tmp/log/.git/coverage defaults
  "railsForge.excludePatterns": ["**/spec/dummy/**"],

  // Force a project type instead of auto-detecting (monolith/api_only/gem/script)
  "railsForge.projectType.override": "auto",

  "railsForge.rubocop.autocorrectOnSave": true,
  "railsForge.rubocop.mode": "safe",
  "railsForge.brakeman.scanOnSave": false,
  "railsForge.testing.framework": "rspec",
  "railsForge.schema.autoIndex": true,
  "railsForge.routes.autoIndex": true,

  "railsForge.ollama.host": "http://localhost:11434",
  "railsForge.ollama.model": "qwen2.5-coder:14b",
  "railsForge.ollama.embeddingModel": "nomic-embed-text",

  // Cloud AI providers — API keys are set via the "RailsForge: Set AI Provider
  // API Key" command (stored in SecretStorage), never here
  "railsForge.ai.provider": "ollama",
  "railsForge.ai.openai.model": "gpt-4o-mini",
  "railsForge.ai.anthropic.model": "claude-sonnet-4-5",

  // Optional legal-tech prompt guardrails for contract/policy/litigation workflows
  "railsForge.legal.skills.enabled": false,

  "railsForge.mcp.enabled": true,
  "railsForge.apiDocs.enabled": true,
  "railsForge.performance.cacheSize": 200
}

Legal-tech AI guardrails

Set railsForge.legal.skills.enabled to true when using @rails in legal-tech workspaces. RailsForge then injects legal-domain guardrails inspired by the lawve-ai/awesome-legal-skills vscode-extension-builder-lawvable skill pack: jurisdiction assumptions, confidentiality handling, source-text citation discipline, uncertainty callouts, and attorney-review reminders.

Installation

In VS Code

code --install-extension railsforge.vsix

In Cursor

cursor --install-extension railsforge.vsix

Or install manually via VS Code / Cursor Extensions View (Ctrl+Shift+X) $\to$ Click ... $\to$ Install from VSIX... $\to$ select railsforge.vsix.

Relationship to Ruby LSP

RailsForge is a companion to Shopify's ruby-lsp, not a replacement for it. Install both:

// .vscode/extensions.json
{ "recommendations": ["shopify.ruby-lsp", "nemesis.railsforge"] }

ruby-lsp (plus ruby-lsp-rails) remains the source of truth for Ruby syntax, diagnostics, and go-to-definition. RailsForge adds Rails-specific intelligence (schema peek, route search, pattern catalog, principle diagnostics, security scans, the local AI agent) on top. For deeper integration, RailsForge also ships an optional ruby-lsp add-on gem that injects schema context directly into ruby-lsp's own Hover responses — see ruby-lsp-addon/README.md for setup and the current scope (schema-aware hover today; route-aware completion and association-aware navigation are natural next steps on the same scaffold).

Roadmap

The pattern catalog and principle diagnostics above started as a regex/heuristic layer, deliberately kept dependency-light. That layer is now complemented by a persistent AST index (tree-sitter + SQLite, off the extension host thread — see "AST-Backed Analysis" above) that powers cross-file DRY detection, dependency cycle detection, guided multi-file extraction, and an MCP server. Remaining roadmap items are tracked in PRD.md; happy to scope any of them as a follow-up.

🧬 16. AST-Backed Analysis (tree-sitter + SQLite, off-thread)

A second, complementary index alongside the regex-based one above — built with real Ruby parsing (tree-sitter-ruby) and persisted to a workspace-local .railsforge/index.sqlite3 (gitignore it, like any other local cache) so it survives VS Code restarts instead of rebuilding from scratch. Indexing runs in a worker_threads worker, never on the extension host's own thread. Fails soft: if the native modules can't load on some platform or Node/Electron version — better-sqlite3 specifically requires Node >= 22.14 (checked via process.versions.napi before ever touching the module, since an unsupported version aborts the process rather than throwing) — these features silently disable themselves and nothing else in RailsForge is affected.

• RailsForge: Find Near-Duplicate Methods (DRY) — near-duplicate method bodies across the whole codebase (not just line-count heuristics), ranked by token-overlap similarity. Two methods with the same logic under different names/variables in different files are still flagged.
• RailsForge: Show Circular Dependencies — DFS cycle detection (A → B → C → A) over an AST-derived dependency graph that also understands include/prepend/extend, not just .call/.new.
• Guided Extract Service/Query: railsforge.extractService and railsforge.extractQuery now also (a) search the workspace for other exact copies of the selected code and offer to replace them too in the same multi-file edit, and (b) generate a companion RSpec skeleton at spec/services/*_spec.rb (or spec/queries/) when a spec/ directory exists, so extraction doesn't leave zero test coverage behind.
• RailsForge: Export Cursor Rules & Register MCP Server — writes .cursor/rules/railsforge.mdc (schema, routes, existing patterns, the "search before generating" rule) and registers the railsforge MCP server in .cursor/mcp.json.
• MCP server (dist/mcp/server.js, standalone — not loaded by the extension host) exposes get_schema, list_routes, list_patterns, find_similar_pattern, get_dependencies, and find_duplicate_methods as MCP tools, so any MCP-capable AI client can query the same project context the built-in @rails agent uses — not just Cursor/Claude Code.

Requirements

• Ruby $\ge 2.7$ & Rails $\ge 5.2$
• Bundler (Gemfile / Gemfile.lock)
• Node $\ge$ 22.14 — the AST-Backed Analysis features (§16) bundle native modules (better-sqlite3, tree-sitter-ruby) that require N-API >= 10, only available in Node 22.14+. If your VS Code/Cursor build bundles an older Node, §16 disables itself gracefully — everything else in RailsForge is unaffected.
• (Optional) Ollama running locally on http://localhost:11434 for @rails AI assistant features (ollama run qwen2.5-coder:14b or qwen2.5-coder:7b).
• The AST-Backed Analysis features (§16) bundle native modules with prebuilt binaries for macOS/Linux/Windows on x64 and arm64. If your platform or Node version isn't covered, §16 disables itself — everything else in RailsForge is unaffected.

CI/CD & Release Process

Three GitHub Actions workflows guard this repo:

Cutting a release:

1. Bump "version" in package.json to the new version.
2. Commit, merge to master.
3. Tag it and push the tag: git tag vX.Y.Z && git push origin vX.Y.Z.
4. The verify job runs automatically. If the tag/package.json versions don't match, it fails fast before anything is built or published.
5. The publish job then runs — see below for how to require a manual approval before it actually publishes anything.

One-time repo setup (not something this repo's code can configure for you):

• release environment (Settings → Environments → New environment named release, add required reviewers): without this, publish runs immediately after verify passes with no human check. With it, publishing to the Marketplace/Open VSX pauses for approval — recommended, since un-publishing a bad version afterward is much harder than a 30-second approval click.
• Secrets (Settings → Secrets and variables → Actions): VSCE_PAT (VS Code Marketplace personal access token) and/or OVSX_PAT (Open VSX token). Either or both can be set — publishing to a marketplace is skipped (not failed) if its secret is absent.
• Dependabot (.github/dependabot.yml) opens weekly update PRs for npm, the Ruby add-on's bundler dependencies, and the GitHub Actions themselves — those PRs go through the normal ci.yml checks like any other PR.

License

MIT License © 2026 Shubham Taywade.
