Tabbed Emulator

A VS Code extension that runs Android emulators and iOS Simulators inside a VS Code tab — no separate window needed. Touch and keyboard input are forwarded directly to the device.

Data flow — Android

1. Boot — AndroidSession spawns the emulator process headlessly (-no-window) with gRPC enabled on a configurable port (default 8554). It polls adb every 1.5 s until sys.boot_completed=1.

2. Streaming — Once booted, EmulatorClient calls streamScreenshot on the emulator's gRPC server. The emulator pushes PNG-encoded frames continuously. Each frame is base64-encoded in the extension host and sent to the webview via postMessage.

3. Rendering — The webview sets the PNG as the src of an <img> element. No canvas — the browser handles decoding.

4. Input — Pointer events on the <img> are translated from CSS pixels to device coordinates and sent back to the extension host as touch messages. The extension host calls sendTouch on the gRPC client. Keyboard events (after the user taps once) are forwarded the same way via sendKey.

Data flow — iOS

1. Boot — IosSession runs baguette boot --udid <UDID> then waits on xcrun simctl bootstatus. If the simulator is already booted, the existing one is reused.

2. Shared server — BaguetteServer is a ref-counted singleton that spawns one baguette serve --port 8421 process for the whole extension. iOS tabs share it; it shuts down when the last tab closes.


4. Input — The same WebSocket carries {type:'touch1-down/move/up', x, y, width, height} for pointers and {type:'key', code, modifiers} / {type:'type', text} for keyboard. KeyboardEvent.code (e.g. KeyA) is passed through unchanged.

Prerequisites

• Node.js 18+
• VS Code 1.85+
• For Android: Android SDK with
  • emulator binary ($ANDROID_HOME/emulator/emulator)
  • adb binary ($ANDROID_HOME/platform-tools/adb)
  • At least one AVD created in Android Studio
• For iOS (macOS only):
  • Apple Silicon Mac (arm64) — baguette is not built for Intel
  • Xcode 26.3+ with iOS Simulator runtime installed
  • baguette v0.1.73 — tested/pinned version. Install via the tddworks tap:

    brew install tddworks/tap/baguette
    baguette --version   # expect 0.1.73


    The extension will surface a warning on startup if a different version is detected (pre-1.0 baguette ships breaking changes; the stream CLI was broken in some intermediate builds and the WS wire schema is not yet stable).
  • At least one iOS Simulator created in Xcode (Window → Devices and Simulators → Simulators)

Local Development

1. Install dependencies

npm install

2. Build

npm run build

Or watch for changes:

npm run watch

The build uses esbuild and outputs a single bundle to out/extension.js. The proto files are copied to out/proto/ as part of the build.

3. Run in the Extension Development Host

Press F5 in VS Code (or use Run > Start Debugging).

This launches a second VS Code window with the extension loaded. Open the Command Palette (Cmd+Shift+P) and run:

Tabbed Emulator: Open Android Emulator
Tabbed Emulator: Open iOS Simulator

Pick a device from the list — it boots headlessly and a new tab opens with the live screen. Note that iOS Simulator state (apps, signed-in accounts, etc.) persists between sessions, unlike Android's -no-snapshot boot.

4. View logs

Open the Output panel and select Tabbed Emulator from the dropdown to see emulator stdout/stderr and gRPC events.

Extension Settings

Commands

Packaging (VSIX)

To install permanently without the Extension Development Host:

npm install -g @vscode/vsce
vsce package
code --install-extension tabbed-emulator-0.0.1.vsix
