MarkCanvas

MarkCanvas is an experimental VS Code custom editor for Markdown. It opens .md files in a rendered, canvas-like editing experience powered by Milkdown/Crepe while keeping the Markdown file itself as the source of truth.

What It Does

• Edit Markdown in a rendered custom editor instead of a plain text buffer
• Preview Mermaid code fences inline
• Detect linked draw.io SVG assets and jump back to the source diagram file
• Stay in sync with external edits, undo/redo, and VS Code theme changes

Why MarkCanvas

Traditional Markdown editing is text-first. MarkCanvas explores a different workflow: keep Markdown as Markdown, but interact with it through a richer visual editor inside VS Code.

This project is a good fit if you want:

• a custom-editor approach instead of a separate preview pane
• a lightweight visual editing layer without introducing a proprietary document format
• better handling for Mermaid and draw.io-heavy Markdown documents

Current Scope

MarkCanvas currently targets desktop VS Code and local Markdown files.

Known limitations:

• Web extension support is out of scope for the current version
• draw.io support only applies to linked SVG files that end with .drawio.svg or contain embedded draw.io metadata
• Markdown remains canonical; MarkCanvas does not maintain a parallel document model

Getting Started

Run From Source

Requirements:

• VS Code 1.45 or later
• Node.js 20 or later
• npm

Install dependencies and build the extension:

npm install
npm run build

Then open this repository in VS Code and press F5 to launch an Extension Development Host.

Inside the development host:

1. Open any Markdown file.
2. Run MarkCanvas: Open in MarkCanvas.

You can also use the Open in MarkCanvas entry from the explorer or editor context menu for .md files.

Development

Useful scripts:

• npm run build: build the extension and webview bundles into dist/
• npm run watch: rebuild on file changes during development
• npm run typecheck: run TypeScript type checking without emitting files
• npm run test: run the roundtrip and extension test suites
• npm run test:roundtrip: run Markdown roundtrip tests
• npm run test:extension: run the VS Code extension smoke tests
• npm run package:vsix: create a .vsix package
• npm run package:vsix:pre-release: create a pre-release .vsix package

Manual verification notes live in docs/manual-test.md. A sample showcase document is available in docs/demo-showcase.md.

Project Layout

• src/extension.ts: extension activation and command registration
• src/provider.ts: custom editor provider and document synchronization
• src/webview: webview UI, rendered editing behavior, and previews
• test: roundtrip and extension test suites
• docs: sample content, manual test notes, and implementation docs

Contributing

Contributions, issues, and pull requests are welcome. See CONTRIBUTING.md for development and contribution guidelines.

Security

If you find a security issue, please report it privately when possible. See SECURITY.md.

Code of Conduct

This project follows CODE_OF_CONDUCT.md.

License

Released under the MIT License.
