VS Code / Cursor extension

JSON-RPC stdio client for orchestra core. Webview chat + in-panel Settings + Ping smoke.

Architecture

Webview (chat / settings UI)
    ↕ postMessage
Extension Host (CoreSession)
    ↕ Content-Length JSON-RPC
orchestra core (subprocess)

Lifecycle: spawn once → initialize → session.start → many session.message. Business logic stays in core.

What works

Chat

• Orchestra: Open Chat — Cursor-like composer, sessions, streaming, tool chips
• Attachments / vision — drag-drop, paste, @ mentions; protocol v13 attachments[]
• Dry-run / Apply toggle — session.message with apply: true|false
• Pending ops bar — per-file review (↑↓ · a/x · Enter), filtered ops.apply, or Apply All via session.apply_pending
• LSP install modal — dedicated UI for lsp.install permission requests
• Permission / Question modals — permission/request, question/ask
• Mode pills → mode; Effort/Fast → profile
• Model picker → runtime.list_providers + runtime.set_model

Settings (in-panel, 6 tabs)

General · Models (provider catalog + API models, vision toggle) · Index & Graph · Agent · Tools & MCP · Plugins

Commands

• Orchestra: Open Chat
• Orchestra: Settings
• Orchestra: Ping Core

Protocol v13 — see docs/PROTOCOL.md. Handshake: protocol_version=13, ops_version=1, tools_version=12.

Run (Cursor / VS Code)

1. Install Orchestra AI Code from Marketplace (or VSIX)
2. Open a folder (File → Open Folder) — core needs a project root
3. Launch chat — any of:
   • Activity Bar (left): icon Orchestra (chat bubble) → sidebar chat
   • Status bar (bottom-right): click Orchestra
   • Command Palette (Ctrl+Shift+P): Orchestra: Open Chat
   • Shortcut: Ctrl+Shift+O (Cmd+Shift+O on macOS)
   • Editor title bar: chat icon when a file is open
4. First run: configure LLM in Orchestra: Settings (LM Studio / OpenAI-compatible API)
5. Debug wire: Output → Orchestra

There is no separate Cursor-style floating panel — chat lives in the left sidebar (Activity Bar → Orchestra). The editor-panel fallback remains if the sidebar view is unavailable.

Restart / Developer: Reload Window after updating the extension.

Dev (F5 from repo)

1. go build -o orchestra.exe ./cmd/orchestra in repo root
2. cd ui/vscode → npm install → npm run compile
3. Open Orchestra workspace → Run Orchestra Extension (F5)

Restart Extension Host after rebuilding orchestra.exe if the binary was locked.

Package / Marketplace

Bundled core layout (inside .vsix):

bin/win32-x64/orchestra.exe
bin/linux-x64/orchestra
bin/darwin-arm64/orchestra
bin/darwin-x64/orchestra

Extension auto-picks bin/<platform>-<arch>/ for the current machine. Override with Settings → Orchestra: Binary Path.

Build VSIX locally

cd ui/vscode
npm ci
npm run bundle:core        # current OS only (F5 dev)
npm run package            # → orchestra-*.vsix

Cross-platform fat VSIX (all four cores) — use CI, not bundle:core:all from Windows (cgo/tree-sitter):

# Tag push or manual run in GitHub Actions → vscode-vsix workflow
git tag vscode-v0.1.0 && git push origin vscode-v0.1.0

Or Actions → vscode-vsix → Run workflow (optional Publish if VSCE_PAT is set).

Matrix builds natively on windows-latest, ubuntu-latest, macos-latest (arm64 + x64 cross), merges into bin/, packages .vsix, uploads artifact orchestra-vsix.

Publish checklist

1. Publisher — create publisher on Marketplace; publisher in package.json must match.
2. Version — bump version in package.json (semver).
3. Assets — icon images/icon.png (from repo logo.png), README, LICENSE, repo URL.
4. Fat VSIX — run vscode-vsix workflow (native matrix build); do not rely on bundle:core:all from a single dev machine.
5. Token — repo secret VSCE_PAT (Personal Access Token with Marketplace publish scope).
6. Publish — tag vscode-v0.1.0, or workflow_dispatch with Publish checked; or download .vsix artifact and upload manually.
7. LLM config — bundled core ≠ LLM: users still configure provider/API in Orchestra Settings (LM Studio, OpenAI-compatible, etc.).

CI: TypeScript compile on every push (.github/workflows/ci.yml); full multi-platform VSIX on tag / workflow_dispatch (.github/workflows/vscode-vsix.yml).

Layout

ui/vscode/
  media/chat.css|js       # chat webview
  media/settings.css|js   # settings webview
  src/extension.ts
  src/coreSession.ts
  src/chat/panel.ts
  src/chat/settings.ts
  src/protocol/events.ts
  src/rpc/

Still TODO (extension)

• Rich expandable tool blocks + inline diff (full TUI parity)
• Reasoning/thinking block UI
• Plugins install UI; hooks/git/browser settings editors
• Optional: bundle orchestra binary inside the VSIX for zero-setup install
