PostgreSQL mTLS Explorer — VS Code Extension

A Visual Studio Code extension for connecting to PostgreSQL databases using Mutual TLS (mTLS) authentication, designed for environments that use Teleport / Infrastructure Access Control with short-lived X.509 certificates.

Features

• Teleport Integration — Import connections directly from Teleport with a single service name
• mTLS Authentication — Connect using CA certificate, client certificate, and client key (no passwords)
• Multiple Connections — Manage multiple database connections with read-only / read-write user roles
• Database Object Browser — Explore schemas, tables, views, functions, columns, and indexes in a tree view
• SQL Query Editor — Write and execute queries in .psql files with rich PostgreSQL syntax highlighting
• IntelliSense — Autocomplete for table names, column names, functions, and SQL keywords based on the connected database
• Per-File Connections — Each .psql file remembers which database connection it uses
• Results Panel — View query results in the bottom panel with sortable columns, copy-to-clipboard, and CSV export
• Rich Syntax Highlighting — PostgreSQL-specific highlighting for keywords, data types, functions, JSON operators, dollar-quoted strings, and more

Quick Start

Prerequisites

• Visual Studio Code v1.85 or later
• Teleport CLI (tsh) installed and logged in
• Active Teleport session (tsh login)

1. Install the Extension

code --install-extension postgres-mtls-explorer-0.1.0.vsix

Or in VS Code: Extensions > ... menu > Install from VSIX...

2. Add a Connection from Teleport (Recommended)

1. Click the database icon in the Activity Bar (left sidebar) to open the PostgreSQL Explorer
2. In the Connections panel, click the cloud icon (Add from Teleport)
3. A searchable list of all available PostgreSQL databases from Teleport is displayed — pick one
4. Select the database user role:
   • teleport_readonly — Read-only access
   • teleport_admin — Read-write access
   • Or enter a custom user
5. The extension automatically:
   • Derives the database name (e.g. weather-service → weather_service)
   • Runs tsh db login --db-user <user> --db-name <db_name> <service> to generate certificates
   • Runs tsh db config --format=cmd <service> to extract connection settings
   • Creates the connection (e.g. weather-service (rw))

3. Connect and Query

1. Click the plug icon next to your connection to connect
2. Create a new .psql file or use the new file icon in the Database Objects panel
3. Write your SQL and press Cmd+Enter (Mac) / Ctrl+Enter (Windows/Linux) to execute
4. Results appear in the PG Results tab in the bottom panel

Usage Guide

Adding Connections

From Teleport (recommended): Click the cloud icon or run Cmd+Shift+P > "PostgreSQL mTLS: Add from Teleport". The extension fetches all available PostgreSQL databases from Teleport via tsh db ls, lets you pick one from a searchable list, choose a user role, and automatically configures the connection — no manual input of hosts, ports, or certificate paths needed.

If tsh db ls fails (e.g. network issues), it falls back to a manual input box where you can type the service name directly.

Manual configuration: Click the + icon or run Cmd+Shift+P > "PostgreSQL mTLS: Add Connection (Manual)". Fill in the connection form with:

Note: Teleport issues short-lived certificates. Run tsh db login <db-name> to refresh expired certificates.

Managing Connections

• Connect — Click the plug icon next to a connection, or it auto-connects when you run a query
• Disconnect — Click the disconnect icon
• Edit / Delete — Right-click a connection
• Multiple connections can be active simultaneously

Writing and Running Queries

1. Create a .psql file (the extension owns this file type — .sql files are left to other extensions like Snowflake)
2. Write your SQL query
3. Run the full file: Press Cmd+Enter
4. Run a selection: Select specific SQL text, then press Cmd+Enter
5. Results appear in the PG Results tab in the bottom panel

Per-File Connection Binding

Each .psql file is bound to a specific database connection. You can see and change the connection in three ways:

• CodeLens (line 1) — Clickable text above your first line showing the connection name, database, and status
• Status bar (bottom right) — Shows connection name, database, and schema
• Right-click > "Change DB Connection" in the editor context menu

When you run a query on a file with no connection assigned, you'll be prompted to pick one.

Browsing Database Objects

The Database Objects panel shows all connected databases as top-level nodes, each expandable to reveal:

• Schemas (e.g. public, analytics)
  • Tables — with columns (type, nullability, primary key indicators) and indexes
  • Views
  • Functions — with return type annotations

Right-click a table for:

• View Table Data (Top 100) — quick preview of table contents
• View Table Structure — column definitions

IntelliSense / Autocomplete

When connected, the extension provides context-aware autocomplete in .psql files:

• After FROM / JOIN — table and view names (prioritized)
• After table. or alias. — columns for that table
• After schema. — tables, views, and functions in that schema
• In SELECT, WHERE, etc. — columns from referenced tables, plus SQL keywords
• Functions — with parentheses auto-inserted

Trigger with Ctrl+Space or type naturally.

Query Results

Results appear in the PG Results tab in the bottom panel:

• Status bar — command type, row count, execution time
• Sortable columns — click any column header to sort
• Copy cell — hover over any cell to reveal a copy icon
• Export CSV — click the Export CSV button
• Timestamps — displayed as raw database values (no JavaScript formatting)

Keyboard Shortcuts

License

Proprietary. See LICENSE for details.
