TypedMind DSL VS Code Extension

VS Code language support for TypedMind Domain Specific Language (.tmd files).

About TypedMind

TypedMind is a domain-specific language (DSL) for describing program architecture. It helps developers:

• Document complex system architectures clearly
• Visualize component relationships and dependencies
• Validate architectural constraints
• Generate interactive documentation

Learn more about TypedMind →

Commands

This extension provides the following commands accessible via the Command Palette (Cmd/Ctrl+Shift+P):

• TypedMind: Validate Current File - Check the current .tmd file for errors
• TypedMind: Preview - Render and visualize the TypedMind architecture (opens in browser)
• TypedMind: Toggle Syntax Format - Toggle between shortform and longform syntax (Ctrl+Shift+Alt+F)
• TypedMind: Show Entity Graph - Visualize the program architecture (opens in browser)
• TypedMind: Format Document - Format the TypedMind file (coming soon)
• TypedMind: Generate Documentation - Create documentation from .tmd files (coming soon)

Features

Language Support

• Syntax highlighting for TypedMind entities
• Real-time validation and diagnostics via Language Server Protocol
• IntelliSense for entity names and operators
• Hover information showing entity details and relationships
• Go to definition for entity references (Cmd/Ctrl+Click)
• Find all references across your codebase (Right-click → Find All References)
• Semantic highlighting for consistent entity coloring
• Quick fixes for common validation errors

Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions view (Ctrl+Shift+X)
3. Search for "TypedMind DSL"
4. Click Install

Or install directly from the VS Code Marketplace.

From Command Line

code --install-extension Sammons.typed-mind

Manual Installation (VSIX)

For Cursor IDE or other VS Code-compatible editors that may not have marketplace access:

1. Download the latest VSIX file:

   • Latest Release - Download the typed-mind-<version>.vsix asset
   • Or browse all releases: GitHub Releases

2. Install in VS Code/Cursor:

   • Press Ctrl+Shift+P (or Cmd+Shift+P on Mac)
   • Type "Install from VSIX"
   • Select "Extensions: Install from VSIX..."
   • Choose the downloaded .vsix file

3. Alternative method:

   • Open Extensions sidebar
   • Click "..." menu → "Install from VSIX..."
   • Select the downloaded file

Manual Installation (Development)

1. Build: pnpm build
2. Package: pnpm package
3. Install: code --install-extension typed-mind-*.vsix
4. Extension will activate automatically for .tmd files

Usage

The extension activates automatically for .tmd files.

Quick Start

1. Create a new file with .tmd extension
2. Start typing your TypedMind architecture
3. Use IntelliSense (Ctrl+Space) for suggestions
4. Run validation with Cmd/Ctrl+Shift+P → "TypedMind: Validate Current File"

Theme Selection

The extension works with any VS Code theme.

Common Workflows

• Navigate code: Cmd/Ctrl+Click on entity names to jump to definitions
• Find usages: Right-click → Find All References
• View errors: Problems panel shows all validation errors
• Quick fixes: Hover over errors and click the lightbulb for fixes

Build

This package builds with tsup (esbuild), unlike the other typed-mind-lang packages, which build with tsc --build. vsce package --no-dependencies ships the extension with no node_modules, so the extension host artifact must be a self-contained bundle with its dependencies inlined — that is the one job tsc --build cannot do, and the reason this package retains tsup.

Development

• pnpm dev - Watch mode
• pnpm build - Build extension
• pnpm package - Create .vsix

Dependencies

All three runtime dependencies — @sammons/typed-mind, @sammons/typed-mind-lsp, and @sammons/typed-mind-renderer — are workspace:*. typed-mind and typed-mind-lsp flipped in RFC-TM-5 §3 (knowledge/projects/typedmind/rfc-tm-5-diamond.md) Q3. typed-mind-renderer stayed pinned at the last-published ^0.2.1 through Q3 because RFC-TM-6 was still migrating the renderer off the legacy bridge; flipping early would have pulled TM-6's in-flight renderer into the extension (the DAG's ordering constraint). RFC-TM-6 merged, so Q4 flips the renderer to workspace:* and migrates the preview command (src/extension.ts) onto TypedMind.create() + the renderer's setGraph/setValidationResult entry point — the DSLChecker require and setProgramGraph call are gone.

Example Syntax

# Define your application
TodoApp -> AppEntry "Todo list application" v1.0.0

# Entry point
AppEntry @ src/index.ts:
  <- [express, TodoController]
  -> [startServer]

# Use ClassFile fusion for controllers
TodoController #: src/controllers/todo.controller.ts
  <- [TodoService]
  => [createTodo, getTodos, updateTodo, deleteTodo]

# Service layer
TodoService #: src/services/todo.service.ts
  => [create, findAll, update, delete]

# Runtime configuration
DATABASE_URL $env "PostgreSQL connection" (required)
PORT $env "Server port"
  = "3000"

# Dependencies
express ^ "Web framework" v4.18.0

License

MIT
