Voidwalker (v3.0.0)

A VS Code extension that automatically generates Google Test (GTest) test cases for your C functions using Boundary Value Analysis (BVA). Right-click any C function → get a full set of boundary tests instantly. No test-writing boilerplate.

✨ Features

• One-click test generation — Place your cursor inside any C function and press Ctrl+Shift+T (or right-click → Generate Tests for This Function)
• Boundary Value Analysis — Automatically generates test cases for INT_MIN, INT_MAX, 0, boundary ±1 values, float/double infinities, and more
• Supports all C primitive types — int, unsigned int, long, short, float, double, char, size_t, and their variants
• Pointer, array & struct support — Generates NULL / valid-pointer tests, single-element / typical array tests, and zero-initialized / extreme struct tests
• Header file support — Parse .h header files to extract function prototypes and generate tests directly from them
• Global variable awareness — Detects and tests global variables used by your function
• Test density control — Choose minimal, standard, or exhaustive via the voidwalker.testDensity setting
• Interactive expected values — Fill in expected results through a built-in webview UI, or skip and fill them manually later
• Custom Tests tab — Add your own test cases with custom parameter values; struct parameters get per-field inputs; remove any custom test with the ✖ button
• Preview tab — See the full generated C++ test code with syntax highlighting before saving
• Test checkboxes — Select/deselect individual test cases before saving; unchecked tests are commented out
• CMake integration — Automatically generates CMakeLists.txt alongside your tests
• Automatic main() handling — Source files with a main() function are automatically handled; the extension renames it at compile time so GoogleTest's entry point works correctly
• Build & Run — Build and execute tests directly from VS Code with one click
• VS Code Problems panel — Build errors from g++/cmake are parsed and shown with file/line info
• Output Channel logging — All extension activity appears in the "Voidwalker" output panel
• Cross-platform — Works on Windows, Linux, and WSL

🆕 What's New in v3.0.0

• Header file (.h) parsing support — The extension can now parse .h header files to extract function declarations/prototypes and generate tests from them, not just .c source files.
• Rebranded to Voidwalker — The extension has been renamed from "S5in C BVA Test Generator" to "Voidwalker" for a cleaner, more memorable identity.
• VS Code Marketplace publish pipeline — Added GitHub Actions CI/CD workflow for automated packaging and publishing via vsce.
• Polished metadata — Updated categories, keywords, and descriptions for better discoverability on the Marketplace.

🆕 What's New in v2.0.0

Goal 1 — Pointer, Array & Struct support

// All of these parameter types are now fully supported:
int func_with_ptr(int *ptr);              // pointer: NULL + valid-ptr tests
int func_with_arr(int arr[], int size);   // array: single-element + typical
int func_with_struct(struct Point p);     // struct: zero-init + extreme values

Goal 2 — Smarter Boundary Values

• float / double — now tests +∞, −∞, FLT_EPSILON, DBL_EPSILON
• char — adds '\0' (null terminator) and 'A' (printable) boundary classes
• size_t — boundaries 0, 1, 10, SIZE_MAX
• Correct assertion macros: EXPECT_FLOAT_EQ / EXPECT_DOUBLE_EQ for floating-point returns

Goal 3 — Test Density Configuration

Add to your VS Code settings.json or workspace settings:

{
  "voidwalker.testDensity": "standard"
}

Goal 4 — UI Improvements

• 3-tab webview — Boundary Tests, Custom Tests, and Preview tabs
• Preview tab in the webview with syntax-highlighted generated code
• Checkboxes to include/exclude individual tests before saving
• Stats bar — "Tests generated / Selected / Custom"

Goal 5 — Better Error Reporting

• Build errors appear in the Problems panel (clickable, with file + line)
• "Voidwalker" Output Channel for all log messages
• Clearer error: "Place your cursor inside a C function body and try again."

📋 Prerequisites

The extension itself installs with zero dependencies — just install and go. However, to build and run the generated tests, your system needs:

Required

Installation by OS

sudo apt update
sudo apt install -y build-essential cmake libgtest-dev
# Build and install GTest (required on Ubuntu)
cd /usr/src/gtest
sudo cmake .
sudo make
sudo cp lib/*.a /usr/lib/

brew install cmake googletest

✅ Verify your setup

Open a terminal and run:

g++ --version     # Should print version info
cmake --version   # Should print 3.14 or higher
ls /usr/lib/libgtest*.a 2>/dev/null || ls /usr/local/lib/libgtest*.a 2>/dev/null
                  # Should list libgtest.a and libgtest_main.a

If all three commands produce output, you're ready to go.

Tip: You can also verify everything from within VS Code — click the Prerequisites status bar item at the bottom, or open the Command Palette (Ctrl+Shift+P) and run "Voidwalker: Check Prerequisites". A dialog will show the status of each tool and install instructions if anything is missing.

🚀 Installation

From the VS Code Marketplace (Recommended)

1. Open VS Code
2. Go to the Extensions sidebar (Ctrl+Shift+X)
3. Search for "Voidwalker" in the search bar
4. Click Install on the extension by S5in
5. You're ready to go — no reload needed!

Tip: You can also open the Command Palette (Ctrl+Shift+P), type ext install S5in.voidwalker, and press Enter.

From the terminal

code --install-extension S5in.voidwalker

📖 How to Use

Step 1: Open a C file

Open any .c or .h file in VS Code.

Step 2: Generate tests

Place your cursor inside a function and do one of:

• Press Ctrl+Shift+T (Cmd+Shift+T on Mac)
• Right-click → "Generate Tests for This Function"
• Command Palette (Ctrl+Shift+P) → "Voidwalker: Generate Tests for This Function"

Step 3: The extension creates two files next to your .c file

your_project/
├── math.c                  ← your source file
├── add_test.cpp            ← generated test file (for function "add")
├── CMakeLists.txt          ← generated build configuration
└── build/                  ← created when you build
    └── add_tests           ← compiled test executable

Step 4: Fill expected values & customize tests

After generation, a popup offers three choices:

• Fill Expected Values — Opens the full webview panel (see below)
• Build & Run — Skips the webview and immediately builds and runs the tests
• View Tests — Opens the generated test file directly in the editor

Choosing Fill Expected Values opens a rich webview panel with three tabs:

• 🧪 Boundary Tests — All auto-generated test cases displayed as cards. Each card shows the test name, read-only input values, and an Expected result field. Use the checkbox on each card to include or exclude it, or toggle Select/Deselect All at the top.
  • Enter a numeric value (e.g., 42, -100, 0.5)
  • For float/double returns, use INFINITY, NAN, or exact values like 1.5f
  • Leave blank to keep the FAIL() placeholder and fill in manually later
• ➕ Custom Tests — Add your own test cases with custom parameter values and expected results. Struct parameters get per-field inputs. Remove any custom test with the ✖ button.
• 👁️ Preview — See the full generated C++ test file with syntax highlighting before saving.

A stats bar at the top tracks: Tests generated / Selected / Custom.

When you're ready, click one of three buttons: | Button | What it does | |--------|--------------| | 🚀 Save & Build & Run | Save all expected values and custom tests, then immediately build and run | | 💾 Save Only | Save changes without building | | ⏭️ Skip | Close the panel without saving (tests keep FAIL() placeholders) |

Step 5: Build & Run

Build and run can happen automatically (from the popup or webview), or you can trigger it manually at any time:

• Command Palette (Ctrl+Shift+P) → "Voidwalker: Build & Run Tests"

The "Voidwalker" output channel shows the full build log and test results. Any build errors are also surfaced in the VS Code Problems panel with clickable file + line info.

🧪 Example

Given this C function:

int add(int x, int y) {
    return x + y;
}

The extension generates tests like:

TEST(addTest, Baseline_AllZero) {
    // Arrange
    int x = 0;
    int y = 0;
    // Act
    int result = add(x, y);
    // Assert
    // TODO: Provide expected value
    FAIL() << "Expected value needed. Got: " << result;
}
TEST(addTest, Param_x_Min) {
    // Arrange
    int x = INT_MIN;
    int y = 0;
    // Act
    int result = add(x, y);
    // ...
}

Example with a pointer parameter:

// For: int deref(int *ptr)
TEST(derefTest, Param_ptr_NullPointer) {
    int *ptr = NULL;
    int result = deref(ptr);
    // ...
}
TEST(derefTest, Param_ptr_ValidPointer) {
    int ptr_val = 0;
    int *ptr = &ptr_val;
    int result = deref(ptr);
    // ...
}

⌨️ Commands

| Command | Shortcut | Description | |---------|----------|-------------| | Voidwalker: Generate Tests for This Function | Ctrl+Shift+T | Generate boundary tests for the function at cursor | | Voidwalker: Build & Run Tests | — | Build and execute the generated tests | | Voidwalker: Clean Build Directory | — | Remove the build/ directory | | Voidwalker: Check Prerequisites | — | Verify that g++, CMake ≥ 3.14, and GTest are installed; shows install instructions if anything is missing |

⚙️ Configuration

| Setting | Default | Options | Description | |---------|---------|---------|-------------| | voidwalker.testDensity | standard | minimal, standard, exhaustive | Controls how many boundary test cases are generated per function | | voidwalker.numberOfRandomValues | 5 | any number ≥ 0 | Number of additional random test values per parameter | | voidwalker.enableBoundaryNaN | true | true/false | Include NaN boundary values for float/double parameters | | voidwalker.enableBoundaryInfinity | true | true/false | Include ±Infinity boundary values for float/double parameters | | voidwalker.enableBoundaryZero | true | true/false | Include zero/near-zero boundary values | | voidwalker.outputFormat | googletest | googletest, plain | Output format for generated test files | | voidwalker.includeNegativeTests | true | true/false | Generate NULL pointer / negative-input test cases | | voidwalker.testFileNamingPattern | test_{filename} | any string | Pattern for generated test file name |

⚠️ Important Notes

• One function at a time — Place your cursor inside the function you want to test. The extension tests the function at the cursor position, not the entire file.
• C and header files — The extension activates for .c files and .h header files. It generates .cpp test files (Google Test is C++).
• CMakeLists.txt is overwritten — Each time you generate tests, the CMakeLists.txt in that directory is regenerated. If you've customized it, back it up first.
• Functions with 7+ parameters — The extension will warn you about large parameter counts (exponential test combinations). Consider refactoring to use structs.
• Files with main() — If your .c file has a main() function, the extension automatically handles the conflict with GoogleTest's entry point. No manual changes needed.

📦 Release Notes

3.0.0 — Iteration 3

• Header file (.h) parsing support — The extension can now parse .h header files to extract function declarations/prototypes and generate tests from them, not just .c source files.
• Rebranded to Voidwalker — The extension has been renamed from "S5in C BVA Test Generator" to "Voidwalker" for a cleaner, more memorable identity.
• VS Code Marketplace publish pipeline — Added GitHub Actions CI/CD workflow for automated packaging and publishing via vsce.
• Polished metadata — Updated categories, keywords, and descriptions for better discoverability on the Marketplace.

2.0.3 — Patch

• Output pointer parameters in void-return functions are now treated as output params in custom tests: the form no longer asks for an input value — it auto-declares the buffer and asserts its value after the call
• Status bar "Prerequisites" item now appears immediately on startup (activation event changed to onStartupFinished)
• Prerequisite detection now works when VS Code runs as a native Windows app with tools installed inside WSL (wsl.exe fallback added for g++, cmake, and GTest path checks)

2.0.2 — Patch

• Add Check Prerequisites command to verify g++, CMake ≥ 3.14, and GTest
• Fix command IDs to match publisher name (s5in-c-bva-test-generator.*)
• Fix WASM grammar loading to pass file path directly instead of a Buffer
• Silent prerequisite check on extension activation

2.0.1 — Patch

• Automatic main() conflict resolution: source files containing main() no longer conflict with GoogleTest's entry point

2.0.0 — Iteration 2

• Pointer, array & struct parameter support
• Smarter boundary values (size_t, char null/printable, float/double infinity, overflow)
• Test density configuration setting (minimal / standard / exhaustive)
• Custom Tests tab — add your own test cases with per-field struct inputs
• Preview tab with syntax highlighting in webview
• Checkboxes to include/exclude tests before saving
• 3-choice notification popup (Fill Expected Values / Build & Run / View Tests)
• VS Code Problems panel integration for build errors
• Output Channel logging
• Fixed assertion macros for float/double return types

1.0.0 — Iteration 1

• Initial release
• Boundary value analysis for all C primitive types
• Google Test code generation with CMakeLists.txt
• Interactive expected value webview
• Build & Run integration
• Windows, Linux, and WSL support

📝 License

University project — 3rd year.
