GitLineDiff

A Visual Studio Code extension that makes single-line files diffable.

Many repositories store data files — especially JSON — as a single, minified line. Git diffs of those files are nearly useless: any change marks the entire line as modified, so you can't see what actually changed.

GitLineDiff adds a custom Source Control view that lets you open a diff in which both sides are pretty-printed in memory before being compared. The files on disk are never modified — all transformations happen in virtual documents.

Source Control view

Features

Custom Source Control view (GitLineDiff) listing changed files.
JSON pretty-printing out of the box (JSON.stringify(JSON.parse(x), null, 2)).
YAML pretty-printing for standalone .yaml/.yml files, including minified single-line YAML.
Cross-format comparison — JSON and YAML files with the same structured content are rendered as canonical pretty JSON so diffs focus on data, not syntax. Each side shows an origin badge (JSON or YAML) at the top.
Embedded-JSON expansion — pretty-prints single-line JSON stored inside another file, such as a YAML value attributeValue: '{"a":1,...}'.
Configurable — control file types, and which keys/patterns to expand, through VS Code settings (see Configuration).
In-memory only — uses VS Code virtual documents; originals are untouched.
Extensible formatter registry — add XML, YAML, TOML, or custom formats with a few lines of code.
Right-click anywhere — "Open Changes with GitLineDiff" from the Source Control changes list, the Explorer, or an editor tab (HEAD vs working tree).
Commit graph — a full-width visual history graph that opens in the editor area (via a status-bar button or the view toolbar); click a commit to expand its details and changed files, then open any file as a pretty diff.
Auto-refresh — the views and open diffs update when the repo or the settings change.

The view lists all changed files in the working tree. Files with a matching formatter are annotated (e.g. config.yaml · embedded-json) and open as a pretty diff; files without one open as an ordinary diff.

Ways to open a pretty diff

GitLineDiff view — click a changed file (working tree vs HEAD).
Right-click → "Open Changes with GitLineDiff" — from the built-in Source Control changes list, the Explorer, or the editor tab context menu.
Commit graph — open it with the GitLineDiff Graph status-bar button, the graph icon in the GitLineDiff view toolbar, or "GitLineDiff: Open Commit Graph" from the Command Palette. Click any commit to expand an inline detail panel (commit metadata + changed files), then click a file to open its pretty diff vs the parent revision. (You can also run "GitLineDiff: Open Commit Diff" to pick a commit from a list and open all its files at once.)

The commit graph

The graph opens as a full-width panel in the editor area (like Git Graph), rendering your commit history with branch/merge lanes. It's our own webview — not VS Code's built-in graph — because the built-in graph's context menu is gated behind a proposed API that installed extensions can't use. Owning the panel lets us put the pretty diff one click away from any commit. Diffs are commit-vs-first-parent (the root commit is compared against the empty tree).

The panel is laid out as a table with resizable and reorderable columns:

Column	Contents
Graph	Branch/merge lanes with a node per commit.
Description	Branch/remote/tag badges (current branch highlighted) + commit subject.
Date	Author date and time.
Author	Author name.
Commit	Short commit hash.

Drag a column's right edge to resize it, or drag a column header onto another to reorder columns. Your layout is remembered across sessions.

A toolbar above the table gives you a full git view:

Branches dropdown — choose Show All to see every branch's history in a single unified graph, or pick one branch to focus on just its commits.
Show Remote Branches — toggle whether remote-tracking branches appear in both the graph (as badges and history) and the Branches dropdown.
Double-click a branch badge — check out that branch (local branches directly; remote-tracking branches check out an existing local branch or create one tracking the remote).
Search — filter commits by message, author, hash, branch/tag name, or date. Use Ctrl+F / Cmd+F to focus the search box; Escape clears it.

Works in Cursor too. Cursor is a fork of VS Code and ships the same built-in Git extension (vscode.git) and extension API, so GitLineDiff runs there unchanged — press F5 to debug or install the .vsix directly. The only difference is publishing: Cursor uses the Open VSX registry rather than the Microsoft Marketplace.

Installation

From source (recommended during development)

git clone <this-repo>
cd vscode-git-line-diff
npm install
npm run compile

Then press F5 in VS Code to launch an Extension Development Host with GitLineDiff loaded.

Packaging a `.vsix`

npm install -g @vscode/vsce
vsce package
code --install-extension gitlinediff-0.1.0.vsix
# In Cursor:
cursor --install-extension gitlinediff-0.1.0.vsix

Development setup

Command	Description
`npm install`	Install dependencies.
`npm run compile`	Type-check and build to `out/`.
`npm run watch`	Rebuild on change.
`npm run lint`	Run ESLint over `src/`.
F5	Launch the Extension Development Host.

Requirements: Node.js 18+, VS Code 1.85+. The built-in Git extension (vscode.git) must be enabled — it is declared as an extension dependency.

Configuration

All settings live under the gitlinediff.* namespace and update the view and any open diffs live.

Setting	Default	Description
`gitlinediff.json.fileExtensions`	`["json"]`	Extensions treated as standalone JSON and pretty-printed.
`gitlinediff.yaml.fileExtensions`	`["yaml", "yml"]`	Extensions treated as standalone YAML and pretty-printed.
`gitlinediff.structuredData.canonicalizeToJson`	`true`	Render both JSON and YAML as canonical pretty JSON for cross-format comparison. Origin badges still show the on-disk format.
`gitlinediff.embeddedJson.enabled`	`true`	Expand single-line JSON strings embedded inside other files.
`gitlinediff.embeddedJson.fileExtensions`	`["yaml", "yml"]`	Extensions scanned for embedded JSON values.
`gitlinediff.embeddedJson.autoDetect`	`true`	When no `keys`/`keyPattern` are set, expand any value that parses as a JSON object/array.
`gitlinediff.embeddedJson.keys`	`[]`	Restrict expansion to these exact key names.
`gitlinediff.embeddedJson.keyPattern`	`""`	Optional regex matched against key names.

Eligibility rule for embedded JSON: a value is expanded only if it parses as a JSON object/array and its key is eligible. A key is eligible if keys contains it or keyPattern matches it; if neither is configured, autoDetect makes every key eligible.

Example

Given this YAML in the working tree (a real, single-line value):

metadata:
  name: demo
  attributeValue: '{"a":1,"b":{"c":2},"d":[1,2]}'

GitLineDiff renders the diff side as:

metadata:
  name: demo
  attributeValue: |-
    {
      "a": 1,
      "b": {
        "c": 2
      },
      "d": [
        1,
        2
      ]
    }

Only the matched value line is rewritten (as a YAML block scalar); every other line is preserved exactly, so the diff stays focused on what actually changed. To expand only specific keys, set:

"gitlinediff.embeddedJson.keys": ["attributeValue"]

Escaped JSON string helper

Some tracked config files store JSON as a single escaped line (double quotes escaped, line breaks as \r\n). The helper script scripts/json_to_escaped_string.py converts a normal .json file into that format:

python scripts/json_to_escaped_string.py input.json output.txt

The script validates the JSON, pretty-prints it with 2-space indentation, applies the escapes, wraps the result in outer double quotes, and writes a single line to the output file. Example output:

"{\r\n  \"openapi\": \"3.0.0\",\r\n  \"info\": {\r\n    \"title\": \"Example\"\r\n  }\r\n}"

Requires Python 3.9+ (stdlib only). Clear errors are printed for missing files or invalid JSON.

How it works

Git integration (src/gitApi.ts) Acquires the built-in Git extension API (vscode.git, version 1), lists working-tree changes, and reads file content from both the working tree and HEAD (via Repository.show('HEAD', path)).
Source Control view (src/treeView.ts) A TreeDataProvider populates the gitLineDiffView view with the working tree's changed files, annotating each with the formatter that applies (if any). Selecting an item runs the gitlinediff.openDiff command.
Virtual documents (src/extension.ts) A TextDocumentContentProvider registered for the custom gitlinediff scheme produces pretty-printed content on demand and in memory. Each virtual URI encodes the original file path and which revision it represents (head or working):
```
gitlinediff:/abs/path/to/file.json?ref=head&src=/abs/path/to/file.json
```
Keeping the original path as the URI path means VS Code infers the correct language for syntax highlighting.
Diff command (gitlinediff.openDiff) Builds two virtual URIs (HEAD on the left, working tree on the right) and opens them with:
```
vscode.commands.executeCommand('vscode.diff', leftUri, rightUri, `GitLineDiff: ${fileName}`);
```
Both sides are transformed through the formatter registry first, so the diff compares readable, multi-line representations.

Architecture overview

src/
├── extension.ts          Activation, virtual-document provider, commands, config wiring
├── config.ts             Typed reader for gitlinediff.* settings
├── gitApi.ts             Typed wrapper around the built-in Git extension (changes, refs, commits)
├── git.d.ts              Vendored, minimal type declarations for vscode.git
├── treeView.ts           Source Control TreeDataProvider + formatter annotation
├── graphLayout.ts        Pure commit-graph lane/line layout algorithm
├── graphView.ts          Commit-graph webview panel (renders the layout, opens commit diffs)
└── formatterRegistry.ts  Pluggable formatters (JSON, YAML, embedded-JSON), built from config

Origin badges

Structured JSON and YAML files get a one-line banner at the top of each diff side so you can see the on-disk format even when both sides are rendered as canonical JSON:

// GitLineDiff · origin: JSON
{
  "openapi": "3.0.0"
}

# GitLineDiff · origin: YAML
{
  "openapi": "3.0.0"
}

Set gitlinediff.structuredData.canonicalizeToJson to false to pretty-print YAML in native YAML syntax instead (JSON files are always rendered as JSON).

Ref-aware virtual documents

A virtual URI encodes the file path plus a ref: working (read from disk) or any git ref (HEAD, a commit hash, a parent). This single mechanism powers both the working-tree diff (HEAD vs working) and commit diffs (parent vs commit) — and a commit's multi-file diff is opened via _workbench.openMultiDiffEditor, falling back to individual diff tabs if that command is unavailable.

Design principles:

Separation of concerns — Git access, UI, and content transformation are independent modules.
Strict typing — strict TypeScript, no any; the Git API is fully typed.
Read-only & non-destructive — transformations live only in virtual docs.
Extensible — formats are added through a registry, not by editing core logic.

Adding a formatter

Formatters are pure functions that turn raw content into a pretty-printed string, falling back to the original content on failure. Register them in createDefaultRegistry() (in src/formatterRegistry.ts) or anywhere you have the registry instance.

XML

registry.register({
  id: 'xml',
  extensions: ['xml', 'svg'],
  format: (content) => prettifyXml(content), // your formatter of choice
});

YAML

YAML support is built in. Standalone .yaml/.yml files are parsed as YAML, pretty-printed, and annotated with an origin badge. When gitlinediff.structuredData.canonicalizeToJson is enabled (default), YAML is rendered as canonical JSON so it compares cleanly with .json files carrying the same data. Embedded JSON strings and YAML block scalars inside YAML config files are expanded automatically (see Configuration).

To customise extensions or disable cross-format canonicalisation, adjust gitlinediff.yaml.fileExtensions and gitlinediff.structuredData.canonicalizeToJson in settings.

For a custom formatter on other extensions, register one explicitly:

import * as yaml from 'yaml';

registry.register({
  id: 'yaml',
  extensions: ['yaml', 'yml'],
  format: (content) => {
    try {
      return yaml.stringify(yaml.parse(content));
    } catch {
      return content; // never throw — fall back to raw content
    }
  },
});

TOML

import * as toml from '@iarna/toml';

registry.register({
  id: 'toml',
  extensions: ['toml'],
  format: (content) => {
    try {
      return toml.stringify(toml.parse(content));
    } catch {
      return content;
    }
  },
});

To also show the new file type in the view, widen the filter in src/treeView.ts (replace jsonOnlyFilter), e.g.:

const allowed = new Set(['json', 'xml', 'yaml', 'yml', 'toml']);
export const supportedFilter: FileFilter = (file) =>
  allowed.has(file.fileName.split('.').pop()?.toLowerCase() ?? '');

License

MIT
