rockDemo

A VS Code extension that turns Killercoda-style markdown scenarios into live, clickable demos. It scans fenced code blocks in any open markdown file and renders CodeLens buttons directly above each actionable block, so you can drive a live demo without copy-pasting commands by hand.

What it does

rockDemo parses fenced code blocks whose closing fence carries an annotation — {{exec}}, {{copy}}, or {{open}} — and adds buttons above the block:

As in Killercoda, bash / sh / shell blocks are runnable by default — they get the exec buttons even without an explicit {{exec}} annotation.

Two modes

• Edit mode — work on the raw markdown; CodeLens buttons sit above each actionable block (great while authoring a scenario).

• Demo / preview mode — click the ▶ Run demo button in the editor title bar (next to VS Code's own preview button, shown for any markdown file). This opens a dedicated Webview beside the editor that renders the markdown like a normal preview, hides the meta fences (```bash etc.), and replaces each actionable block with clickable buttons. The panel auto-refreshes as you edit or save the source file.

  rockDemo uses its own webview rather than VS Code's built-in markdown preview on purpose: the built-in preview renders content as untrusted, which disables command: links and offers no message channel back to the extension — so it can't run terminal commands. A self-owned webview can.

• ▶ Run in terminal reuses the active terminal if one exists, otherwise creates a terminal named rockDemo. The command is typed and executed (a trailing newline is sent).

• 📋 Copy writes the command to the system clipboard and shows a confirmation notification.

• 📂 Open file opens the referenced file in the editor. In a scenario, if the path is container-absolute (e.g. /var/killercoda/solution/first.txt) and falls under a mounted asset, rockDemo opens the host copy bind-mounted there — so what you edit is live inside the container. Otherwise the path is treated as relative to the scenario/step file's folder.

Scenario mode (JSON-driven, Docker-backed)

A full scenario is described by an index.json (Killercoda-style). Open it and click ▶ Run demo in the title bar to launch the scenario player:

1. An intro screen shows the scenario title and description with a START button at the bottom. If details.intro.text is set, that markdown file is rendered into the intro (via the demo player, so its {{exec}}/{{copy}}/{{open}} buttons work).
2. On open, rockDemo starts an interactive shell in a Docker container for each node — effectively docker run -it --rm <imageid> sh. Docker is a prerequisite. {{exec}} commands run inside the active node's container.
   • With a single backend.imageid, one terminal named rockDemo is opened.
   • With backendExtended.nodes, one terminal per node is opened, each named after its node key (e.g. node1, node2). backendExtended takes precedence over backend when present.
3. Clicking START walks through details.steps in order. Each step's markdown (text file) is rendered with the same demo player (hidden meta fences, clickable buttons), and gets navigation at the bottom:
   • PREV — except on the first step,
   • NEXT — on every step but the last,
   • FINISH — on the last step (instead of NEXT).
4. If details.finish.text is present, FINISH shows that final screen; otherwise it reports completion.
5. The finish screen has a RESTART button: it disposes all node container shells (their --rm containers are removed), relaunches every one from scratch, and jumps back to step 1 — a clean start. Closing the player also tears down all of its container shells.

The player auto-rebuilds when you save the index.json or any step markdown.

index.json shape

{
  "title": "Découverte de kubectl",
  "description": "Mes premiers pas avec kubectl",
  "details": {
    "steps": [
      { "title": "Premieres commandes", "text": "step1/step1.md" },
      { "title": "Création d'une ressource", "text": "step2/step2.md" }
    ],
    "assets": {
      "node1": [
        { "file": "solution*", "target": "/var/killercoda/solution", "chmod": "+w" }
      ]
    },
    "finish": { "text": "finish.md" }
  },
  "backend": { "imageid": "alpine" },
  "backendExtended": {
    "nodes": {
      "node1": { "imageid": "alpine" },
      "node2": { "imageid": "debian" }
    }
  }
}

• title / description — shown on the intro screen.
• details.steps[].title — step heading; details.steps[].text — markdown file (path relative to index.json) rendered as the step body.
• details.finish.text — optional closing screen.
• backend.imageid — Docker image for a single-container scenario.
• backendExtended.nodes — optional multi-container map; each key is a node name (used as the terminal name) with its own imageid. When present, this replaces backend.
• details.intro.background / details.steps[].background — optional. A shell command, or a script file (path relative to index.json, e.g. background.sh), run detached and hidden inside a node's container (via docker exec, so nothing shows in the terminal) when the screen is entered (intro on open; a step when you navigate to it — once per run). Requires docker on the extension host's PATH. stdout + stderr are captured to /var/log/rockdemo/<scenario>/<step>_background.log inside the container, where <scenario> is the scenario folder name and <step> is intro or the 1-based step number.
• details.intro.foreground / details.steps[].foreground — optional. A single-line command sent verbatim to the node's terminal (Killercoda-style — the value is not read as a file; it's the command the container shell runs). It runs from /scenario (see below), in the terminal, so its output is visible and it blocks the terminal until it finishes. Fires once per run when the screen is entered. Reference scripts relative to the scenario folder, e.g. ./foreground.sh or sh foreground.sh.

The scenario folder is bind-mounted read-only at /scenario in every container, so scenario scripts are available to run (and foreground commands cd /scenario first). Read-only keeps your host files safe.

• details.steps[].verify — optional. A command (resolved like foreground, from /scenario with . on PATH) that checks the step was completed. When present, the step shows a VERIFY button and hides NEXT/FINISH until the command exits 0. It runs hidden (via docker exec, nothing in the terminal); its output is captured to /var/log/rockdemo/<scenario>/<step_number>_verify.log inside the container. On failure the VERIFY button flashes red and a notification points to the log.

• host (sibling key on the intro/step) selects the target node by name for background, foreground, and verify; otherwise the first node is used (or the single backend).

• details.assets — optional. Each key is a node name (must match a node / backend host) and maps to a list of asset rules:

  • file — glob (relative to index.json; * supported in the last path segment) of host files/folders to stage.
  • target — destination path inside the container.
  • chmod — "+w" (read-write) or "+r" (read-only).

  Assets are live-editable. Rather than a one-shot docker cp, rockDemo copies the matched files into a per-run scratch dir (<scenario>/.rockdemo-run/<node>/…) and bind-mounts that copy into the container. So:

  • your original files are never touched (only the scratch copy is),
  • editing the staged files in VS Code is reflected live inside the container (and vice-versa for +w), and
  • +r is enforced as a read-only mount (:ro) — still editable from the host, just not writable by the container.

  The scratch dir is re-created fresh on every open/RESTART and deleted when the demo ends (stop/close). It's gitignored (.rockdemo-run/).

A working example lives in scenarios/simple/index.json.

Project layout

rockdemo/
├── package.json           # Extension manifest (commands, activation events)
├── src/extension.js       # All the logic: parser, CodeLens provider, commands
├── example/scenario.md    # A sample scenario to try the buttons on
├── .vscode/launch.json    # "Run rockDemo Extension" debug config (F5)
└── README.md

The implementation lives entirely in src/extension.js:

• parseScenario(document) — line-based parser that walks the markdown, tracking fence open/close and extracting { openLine, action, lang, content } for each actionable block.
• ScenarioCodeLensProvider — turns those blocks into vscode.CodeLens buttons positioned on the opening fence line.
• renderDemoBody() / demoHtml() — a small zero-dependency markdown→HTML renderer used for demo mode. It drops non-actionable fences, turns actionable blocks into <button>s, and serves the HTML inside a CSP-locked webview.
• openDemoPanel() — creates/reveals the demo webview beside the editor and relays button clicks back to the shared action handlers via postMessage.
• activate() — registers the CodeLens provider plus the commands rockdemo.exec, rockdemo.copy, rockdemo.open, and rockdemo.preview (the title-bar ▶ Run demo button).

Both modes call the same runExec / runCopy / runOpen handlers, so edit mode and demo mode can never drift apart.

Requirements

• VS Code ^1.75.0.
• No dependencies, no build step. The vscode module is provided by the host at runtime, so there is no npm install and nothing to compile — the extension runs straight from src/extension.js.

How to test it in VS Code

The extension is run via VS Code's built-in Extension Development Host — a second VS Code window that loads rockDemo from source.

1. Open the folder — File → Open Folder… and select the rockdemo folder (open the folder itself, not its parent).
2. Launch the dev host — press F5, or open the Run and Debug panel (Ctrl/Cmd+Shift+D) and choose "Run rockDemo Extension", then click the green ▶. This config is defined in .vscode/launch.json and starts a new window titled [Extension Development Host] with rockDemo active.
3. Open a scenario — in the new window, open example/scenario.md.
4. Edit mode — CodeLens links (▶ Run in terminal / 📋 Copy / 📂 Open file) appear above each code block. Click them and watch:
   • Step 1 (bash, no annotation) → runs in the terminal.
   • Step 2 ({{exec}}) → runs in the terminal.
   • Step 3 ({{copy}}) → copies only; check the clipboard.
   • Step 4 ({{open}}) → tries to open ../hello/main.py relative to the scenario (create that file, or change the path, to see it open).
5. Demo mode — click ▶ Run demo in the editor title bar (top-right, next to the built-in preview icon). A "Demo: scenario.md" panel opens beside the editor with the markdown rendered, the ```bash fences hidden, and a button under each command. Click a button → it runs/copies/opens just like edit mode. Edit or save the source and the demo panel updates live.
6. Scenario mode — open scenarios/simple/index.json and click ▶ Run demo. You'll see the intro (title + description + START), and a rockDemo terminal opens running docker run -it --rm alpine sh (needs Docker installed and running). Click START to step through the scenario with PREV / NEXT / FINISH; the {{exec}} buttons send their commands into the container shell.

Iterating on changes

After editing src/extension.js, reload the Extension Development Host to pick up the change: focus that window and run Developer: Reload Window (Ctrl/Cmd+R), or stop and re-launch with F5. If CodeLens buttons don't appear, confirm:

• the file language is Markdown (bottom-right status bar),
• CodeLens is enabled ("editor.codeLens": true in settings),
• the block has a recognised annotation or is a bash/sh/shell block, and
• the block body is non-empty (empty blocks are skipped).

Scenario format

The annotation goes on the closing fence:

```bash
echo "runs in the terminal by default"
```

```sh
explicit exec — gets ▶ Run + 📋 Copy
```{{exec}}

```bash
copy-only command (e.g. destructive/interactive)
```{{copy}}

```text
../path/to/file.py
```{{open}}

Notes:

• The lang after the opening fence only matters for the bash/sh/shell default-exec behaviour; any language works with an explicit annotation.
• {{open}} paths are resolved relative to the scenario file's directory.

Roadmap / MVP scope

This is step 1: parse a scenario .md and put working buttons over the actionable blocks. Planned next steps:

1. A Webview "presenter panel" with step-through navigation.
2. Simulated editor-typing for a more polished live-demo feel.
