LibJuno VSCode Extension

Vtable-aware Go to Definition for LibJuno embedded C projects.

User Guide

Overview
Installation
How It Works
Supported Patterns
Using Go to Definition
Re-indexing
Vtable Resolution Trace View
MCP Server for AI Agents
Configuration
Troubleshooting

Developer Guide

Prerequisites
Getting Started
Project Structure
Building
Running and Debugging
Testing
Mutation Testing
Packaging
Extension Configuration
Architecture Overview

Overview

LibJuno uses vtable-based dependency injection (DI) — function calls dispatched through ptApi->Foo(...) — that standard IDE tooling cannot resolve to concrete implementations. This extension bridges that gap by:

Building a workspace-wide navigation index from a Chevrotain-based C parser.
Wiring that index into VSCode's native Go to Definition system (F12 / Ctrl+Click).
Providing failure-handler navigation (_pfcnFailureHandler / JUNO_FAILURE_HANDLER assignments).
Exposing an embedded MCP (Model Context Protocol) HTTP server so AI agents (GitHub Copilot, Claude, etc.) can query the same resolution data.

Entry in package.json

Field	Value
Name	`libjuno`
Display name	LibJuno
Version	0.1.7
VSCode engine	^1.85.0
Activation	`onLanguage:c`, `onLanguage:cpp`

Installation

Install the packaged .vsix file from the command line:

code --install-extension libjuno-<version>.vsix

Or via the Extensions panel: open Extensions (Ctrl+Shift+X), click the ··· overflow menu, select Install from VSIX…, and choose the .vsix file.

The extension activates automatically the first time any C or C++ file is opened in the workspace. No restart is required.

How It Works

LibJuno uses vtable-based dependency injection. Function calls look like:

ptModule->ptApi->Method(ptModule, arg);

Standard IDE "Go to Definition" (F12) cannot resolve these because the function pointer is assigned at runtime through a vtable struct — the IDE sees only a pointer dereference, not a concrete symbol.

This extension solves that by:

Parsing every C/C++ file in the workspace with a Chevrotain-based C parser.
Building an in-memory index of vtable struct assignments and function definitions.
At navigation time, tracing the vtable assignment chain from the call site to the concrete function implementation and returning the source location to VSCode.

On first activation the extension indexes all .c, .h, .cpp, .hpp, .hh, and .cc files in the workspace. A persistent cache written to .libjuno/navigation-cache.json in the workspace root speeds up subsequent activations so that only changed files need to be re-parsed.

Supported Patterns

The extension resolves the following call patterns when F12 / Ctrl+Click is used. Place the cursor on the function name (the word after the last ->) and then invoke Go to Definition.

// 1. Indirect API pointer — place cursor on "RegisterSubscriber"
ptEngineApp->ptBroker->ptApi->RegisterSubscriber(ptBroker, &pipe);

// 2. Direct API pointer — place cursor on "LogInfo"
const JUNO_LOG_API_T *ptLoggerApi = ptLogger->ptApi;
ptLoggerApi->LogInfo(ptLogger, "message");

// 3. Dot-accessed API — place cursor on "Copy"
tResult.ptApi->Copy(ptSrc, ptDst);

// 4. Named API member — place cursor on "Compare"
ptHeap->ptHeapPointerApi->Compare(ptA, ptB);

// 5. Failure handler — place cursor on the handler function name
ptModule->tRoot._pfcnFailureHandler = MyFailureHandler;
ptModule->tRoot.JUNO_FAILURE_HANDLER = MyFailureHandler;

// 6. FAIL macro call sites — place cursor on the handler variable name
//    (the second argument)
JUNO_FAIL(tStatus, ptModule->tRoot._pfcnFailureHandler, NULL, "msg");
JUNO_FAIL_MODULE(tStatus, ptMod, NULL, "msg");
JUNO_FAIL_ROOT(tStatus, ptRoot, NULL, "msg");
JUNO_ASSERT_EXISTS_MODULE(ptMod, NULL, "msg");

FAIL macro call sites (JUNO_FAIL, JUNO_FAIL_MODULE, JUNO_FAIL_ROOT, JUNO_ASSERT_EXISTS_MODULE) — place the cursor anywhere on the macro call line and press F12 to navigate to the registered failure handler.

The extension does not resolve:

Direct function calls such as EngineApp_Init(...) — VSCode's built-in C/C++ tooling (e.g., the C/C++ extension or clangd) already handles these.
Macro calls such as JUNO_ASSERT_SUCCESS(...) — macro expansion is out of scope.
Functions defined outside the workspace.

Using Go to Definition

Open any C/C++ file in a LibJuno project.
Place the cursor on a vtable-dispatched function name (e.g., LogInfo in ptLoggerApi->LogInfo(...)).
Press F12 or Ctrl+Click (Cmd+Click on macOS).
If one implementation is found, VSCode navigates directly to it.
If multiple implementations exist, a picker appears — select the desired one.

Alternatively, use the Command Palette:

Ctrl+Shift+P → LibJuno: Go to Implementation

Re-indexing

The extension watches for file changes and re-indexes modified files automatically. After bulk operations (renaming directories, adding many new source files) a manual re-index may be needed:

Ctrl+Shift+P → LibJuno: Re-index Workspace

The status bar shows LibJuno: Indexed X files once the index is current. If the count looks wrong, run a manual re-index.

Vtable Resolution Trace View

The Trace View shows the full resolution chain for a vtable call: the call site node, the composition root (where the vtable was assigned), and the concrete implementation. Each node is clickable — selecting it navigates the editor to that source location.

Opening the Trace View

Method	Action
Keyboard	Press Ctrl+Shift+T while the cursor is in a C or C++ source file
Command Palette	`Ctrl+Shift+P` → LibJuno: Show Vtable Resolution Trace
Context Menu	Right-click in a C/C++ editor → LibJuno: Show Vtable Resolution Trace

The trace view opens in a panel beside the editor. If no vtable call is found at the cursor location, a brief error message appears in the status bar.

Trace Node Structure

Each resolved call displays three nodes:

Node	Label	Navigates to
Call Site	The expression at the cursor	The line where F12 was pressed
Composition Root	The file and line where the vtable was assigned	The vtable assignment statement
Implementation	The concrete function name and signature	The function definition

For calls with multiple implementations (e.g. an array of modules all sharing the same vtable slot), the trace panel shows one subtree per implementation.

MCP Server for AI Agents

The extension runs an embedded MCP (Model Context Protocol) HTTP server, which allows AI agents (GitHub Copilot, Claude, etc.) to query vtable and failure handler resolution programmatically.

Item	Detail
Default port	`6543`
Discovery file	`.libjuno/mcp.json` in the workspace root
Disable	Set `libjuno.mcpServerPort` to `0`

Configure the port in VS Code settings:

"libjuno.mcpServerPort": 6543

Connecting AI Agents

After the extension activates, a discovery file is written to .libjuno/mcp.json in the workspace root. The file contains the server URL that MCP-compatible agents need:

{
  "mcpServers": {
    "libjuno": {
      "url": "http://127.0.0.1:6543/mcp"
    }
  }
}

Claude Code (project-level)

Add the server to .claude/settings.json in your workspace root:

{
  "mcpServers": {
    "libjuno": {
      "type": "http",
      "url": "http://127.0.0.1:6543/mcp"
    }
  }
}

Reload the Claude Code session. The resolve_vtable_call and resolve_failure_handler tools will appear in Claude's tool list.

Claude Desktop

Merge the contents of .libjuno/mcp.json into your Claude Desktop configuration file (claude_desktop_config.json), then restart Claude Desktop.

GitHub Copilot / other MCP clients

Point your MCP client at http://127.0.0.1:6543/mcp. The server implements the MCP Streamable HTTP transport (JSON-RPC 2.0) — standard initialize, tools/list, and tools/call methods are supported.

Available MCP Tools

Tool	Description
`resolve_vtable_call`	Given a file path, line, column, and line text, resolves a vtable API call to its concrete implementation function(s)
`resolve_failure_handler`	Given a file path, line, column, and line text, resolves a failure handler assignment or FAIL macro call to the registered handler function

Configuration

Setting	Default	Description
`libjuno.excludedDirectories`	`["build", "deps", ".libjuno"]`	Directories skipped during indexing. Add `vendor`, `third_party`, or similar as needed.
`libjuno.mcpServerPort`	`6543`	Port for the embedded MCP server. Set to `0` to disable.

Troubleshooting

F12 / Ctrl+Click doesn't navigate to the implementation

1. Is the cursor on a vtable-dispatched call? The extension only resolves calls through vtable function pointers such as ptApi->Method(...). Direct function calls like EngineApp_Init(...) are handled by VSCode's built-in C/C++ tooling, not this extension. See Supported Patterns for the full list of resolvable forms.

2. Is the workspace indexed? Check the status bar — it should show LibJuno: Indexed X files. If it is missing or shows 0, run LibJuno: Re-index Workspace from the Command Palette.

3. Is the implementation file in the workspace? The extension can only resolve to functions defined in files within the workspace root. Functions in external libraries or outside the workspace root will not be found.

4. Is the vtable assignment visible? The extension needs to find where the vtable struct is populated — for example:

static const JUNO_APP_API_T tApi = { .OnStart = OnStart, .OnStop = OnStop };

If this assignment is in a file that has not been indexed (e.g., it was added after the last indexing run), resolution will fail. Run a manual re-index.

5. Check the Output panel. Open the Output panel (Ctrl+Shift+U), select LibJuno from the channel dropdown, and look for error messages or indexing diagnostics.

6. Is the file type supported? The extension indexes .c, .h, .cpp, .hpp, .hh, and .cc files. Other file types are ignored.

Prerequisites

Tool	Minimum version	Notes
Node.js	18+	Bundled inside VSCode; required on the host for development
npm	9+	Comes with Node.js
TypeScript	^5.3.0	Installed as a dev dependency — no global install needed
VS Code	^1.85.0	Required to run or debug the extension

Optional, for packaging:

npm install -g @vscode/vsce

Getting Started

# 1. Navigate to the extension directory
cd vscode-extension

# 2. Install all dependencies
npm install

# 3. Compile TypeScript to the out/ directory
npm run compile

After compilation the extension can be launched from the Run and Debug panel (see Running and Debugging).

Project Structure

vscode-extension/
├── src/
│   ├── extension.ts                  — Extension entry point (activate / deactivate)
│   ├── cache/
│   │   └── cacheManager.ts           — JSON navigation cache persistence
│   ├── indexer/
│   │   ├── navigationIndex.ts        — In-memory Map-based navigation data store
│   │   └── workspaceIndexer.ts       — Workspace scanning, hashing, parse coordination
│   ├── mcp/
│   │   └── mcpServer.ts              — Embedded HTTP MCP server for AI agents
│   ├── parser/
│   │   ├── lexer.ts                  — Chevrotain lexer (C token definitions)
│   │   ├── parser.ts                 — Chevrotain CstParser (C grammar rules)
│   │   ├── types.ts                  — TypeScript types for parsed records
│   │   ├── visitor.ts                — CST visitor that extracts index data
│   │   └── __tests__/                — Parser unit tests
│   ├── providers/
│   │   ├── junoDefinitionProvider.ts — VSCode DefinitionProvider integration
│   │   ├── quickPickHelper.ts        — Multi-implementation picker UI
│   │   ├── vtableTraceProvider.ts        — Vtable resolution trace view (WebviewPanel)
│   │   └── statusBarHelper.ts        — Status bar indexing progress
│   └── resolver/
│       ├── vtableResolver.ts         — Vtable call → concrete impl resolution
│       ├── failureHandlerResolver.ts — Failure handler assignment resolution
│       └── resolverUtils.ts          — Shared resolution utilities
├── jest-esm-to-cjs.cjs               — Custom Jest transformer for Chevrotain ESM bundle
├── jest.config.js                    — Jest configuration
├── stryker.config.json               — Stryker mutation testing configuration
├── tsconfig.json                     — TypeScript compiler options
├── package.json                      — npm scripts, dependencies, VS Code manifest
├── .vscodeignore                     — Files excluded from the packaged .vsix
└── .gitignore                        — Files excluded from version control

Generated at build time:

out/          — Compiled JavaScript (CommonJS, ES2020 target); excluded from git
coverage/     — Jest coverage reports; excluded from git
reports/      — Stryker HTML mutation reports; excluded from git
.stryker-tmp/ — Stryker working directory; excluded from git
*.vsix        — Packaged extension archive; excluded from git

Building

All build commands are run from the vscode-extension/ directory.

One-shot compile

npm run compile

Invokes tsc with the options in tsconfig.json:

Target: ES2020
Module system: CommonJS
Output directory: out/
Source maps: included alongside each .js file (sourceMap: true)
Strict mode: enabled

Watch mode

npm run watch

Runs tsc -w and recompiles automatically on every file save. Use this during active development, especially alongside the extension host debugger.

Running and Debugging

The recommended way to run the extension during development is through the VS Code Extension Development Host:

Open the libjuno workspace root in VS Code.
Press F5 (or open the Run and Debug panel and select Run Extension).
A new VS Code window opens with the extension loaded from out/extension.js.
Open a folder that contains LibJuno C source files.

Tip: Keep npm run watch running in a terminal while debugging so that TypeScript changes are compiled automatically without needing to restart the task.

Breakpoints set in .ts source files work because source maps are emitted to out/.

Logging

The extension writes diagnostic messages to the Output panel under the channel LibJuno. Look there for indexing progress, parse errors, and MCP server startup messages.

Testing

Tests are written with Jest and ts-jest and live in src/**/__tests__/ directories, matched by the **/*.test.ts glob.

Run all tests

npm test

Chevrotain ESM workaround

Chevrotain v11+ ships as an ESM-only package. Jest runs in CommonJS mode by default, so a direct import 'chevrotain' would fail at test time.

Two mechanisms work together to solve this:

moduleNameMapper in jest.config.js redirects chevrotain imports to the self-contained bundle at node_modules/chevrotain/lib/chevrotain.mjs.
jest-esm-to-cjs.cjs — a minimal custom Jest transformer that strips the trailing export { ... }; block from the bundle and replaces it with exports.Name = Name; assignments, making it loadable as CommonJS at test time.

The transform section of jest.config.js applies ts-jest to .ts/.tsx files and jest-esm-to-cjs.cjs to .mjs files. The transformIgnorePatterns entry allows the chevrotain package directory to pass through the transformer pipeline (Jest's default is to ignore all of node_modules).

These settings are opaque; do not modify them unless you are upgrading Chevrotain or Jest.

Test environment notes

testEnvironment: 'node' — tests run in a pure Node.js environment, not jsdom.
VS Code API types (@types/vscode) are available but the VS Code runtime is not available in tests. Components that call VS Code APIs must be isolated behind the providers layer and excluded from unit test scope.

Mutation Testing

Stryker Mutator is configured to measure the effectiveness of the parser test suite by introducing deliberate code mutations and checking whether tests catch them.

Run mutation tests

npm run test:mutation

What gets mutated

Only the core parsing components are mutated (see stryker.config.json):

File	Reason
`src/parser/lexer.ts`	Token definitions — incorrect token boundaries would be caught by parser tests
`src/parser/parser.ts`	Grammar rules — structural changes to the C grammar
`src/parser/visitor.ts`	CST-to-index extraction — incorrect field extraction or skipped nodes

Thresholds

Level	Score
High	≥ 80%
Low	≥ 75%
Break (CI failure)	< 75%

Scores below 75% cause stryker run to exit with a non-zero code.

Reports

Stryker writes an HTML report to the reports/ directory and a summary to stdout. Open reports/mutation/mutation.html in a browser to inspect which mutants survived.

Stryker configuration highlights

Checker: typescript — type-invalid mutants are filtered out before test runs, keeping the feedback loop fast.
Concurrency: 8 workers.
ignoreStatic: true — mutations to static (module-level) initialisation are skipped; they are difficult to test in isolation and rarely hide bugs.
Timeout: 60 000 ms per test run.

Packaging

The extension is packaged into a .vsix archive using @vscode/vsce.

Install `vsce` (once)

npm install -g @vscode/vsce

Package

npm run package

This runs vsce package in the vscode-extension/ directory and produces a libjuno-<version>.vsix file.

What is included in the package

The .vscodeignore file excludes the following from the .vsix:

Excluded	Reason
`src/**`	TypeScript sources — only compiled JS is shipped
`out/*/.map`	Source maps — not needed by end users
`node_modules/**`	Dependencies are bundled by vsce if needed, or excluded
`.vscode/**`	Editor settings
`tsconfig.json`, `jest.config.js`	Developer tooling
`*/.test.ts`, `*/.test.js`	Test files

Install locally

code --install-extension libjuno-0.1.7.vsix

Extension Configuration

The extension contributes the following VS Code settings under the libjuno namespace:

Setting	Type	Default	Description
`libjuno.excludedDirectories`	`string[]`	`["build", "deps", ".libjuno"]`	Directories to exclude from workspace indexing. Add `vendor`, `third_party`, or similar as needed.
`libjuno.mcpServerPort`	`number`	`6543`	Port the embedded MCP HTTP server listens on. Change if there is a conflict with another local service.

Contributed commands

Command ID	Title	Typical invocation
`libjuno.goToImplementation`	LibJuno: Go to Implementation	Command Palette or keybinding
`libjuno.reindexWorkspace`	LibJuno: Re-index Workspace	Command Palette after adding new source files
`libjuno.showVtableTrace`	LibJuno: Show Vtable Resolution Trace	Ctrl+Shift+T or Command Palette

Cache location

The navigation cache is written to .libjuno/navigation-cache.json in the workspace root. This directory is listed under libjuno.excludedDirectories by default so that the cache file itself is not re-indexed.

Architecture Overview

The extension has eight components arranged in a bottom-up dependency stack:

┌──────────────────────────────────────────────────────────┐
│  Extension Activation (extension.ts)                     │
│  ├── WorkspaceIndexer ──► CacheManager                   │
│  │      └── parseFileWithDefs() ──► Chevrotain Parser    │
│  │             ├── Lexer (lexer.ts)                      │
│  │             ├── CParser (parser.ts)                   │
│  │             └── IndexBuildingVisitor (visitor.ts)     │
│  │                    └──► NavigationIndex (CRUD)        │
│  ├── VtableResolver ◄── NavigationIndex ──► FHResolver   │
│  ├── JunoDefinitionProvider ◄── Resolvers                │
│  │      ├── StatusBarHelper                              │
│  │      └── QuickPickHelper                              │
│  ├── VtableTraceProvider ◄── VtableResolver              │
│  └── McpServer ◄── Resolvers                             │
└──────────────────────────────────────────────────────────┘

Component responsibilities

#	Component	Files	Responsibility
1	C Parser	`parser/lexer.ts`, `parser/parser.ts`, `parser/visitor.ts`	Tokenises C source, builds a CST, and walks it to extract structured records (struct definitions, vtable assignments, function definitions, failure handler assignments).
2	Navigation Index	`indexer/navigationIndex.ts`	In-memory `Map`-based store for all parsed records. Provides CRUD operations used by the indexer and resolvers.
3	Workspace Indexer	`indexer/workspaceIndexer.ts`	Scans the workspace for C/H files, computes content hashes to detect changes, coordinates parse calls, and manages incremental updates via VS Code `FileSystemWatcher`.
4	Cache Manager	`cache/cacheManager.ts`	Serialises the navigation index to JSON and writes it atomically to `.libjuno/navigation-cache.json`. Deserialises on startup to avoid a full re-scan.
5	Resolvers	`resolver/vtableResolver.ts`, `resolver/failureHandlerResolver.ts`, `resolver/resolverUtils.ts`	Traverse the vtable assignment chain from a call site to locate the concrete function implementation. Shared utilities live in `resolverUtils.ts`.
6	VSCode Integration	`providers/junoDefinitionProvider.ts`, `providers/quickPickHelper.ts`, `providers/statusBarHelper.ts`	Implements `vscode.DefinitionProvider`, presents a QuickPick when multiple implementations exist, and shows indexing progress in the status bar.
7	MCP Server	`mcp/mcpServer.ts`	Runs a vanilla Node.js HTTP server on `libjuno.mcpServerPort` (default 6543). Exposes vtable and failure-handler resolution as JSON-RPC-style MCP tools consumable by GitHub Copilot, Claude, and other MCP-compatible AI agents.
8	VtableTraceProvider	`providers/vtableTraceProvider.ts`	Presents a WebviewPanel showing the call-site → composition-root → implementation resolution chain. Invoked via `Ctrl+Shift+T` or the Command Palette.

Data flow: Go to Definition (F12)

User presses F12 on a call site
  → JunoDefinitionProvider.provideDefinition()
  → VtableResolver.resolve(document, position)
      → NavigationIndex.lookup(...)
  → Single result   → return Location directly
  → Multiple results → QuickPickHelper shows picker → user selects → navigate
  → No result       → show informative error message (non-intrusive)

Activation sequence

Extension activates on the first C or C++ file opened (onLanguage:c / onLanguage:cpp).
Reads libjuno.excludedDirectories and libjuno.mcpServerPort from workspace settings.
Displays a progress notification while loading the cache (CacheManager) or running a full index (WorkspaceIndexer).
Shows the indexed file count in the status bar.
Registers JunoDefinitionProvider and the two contributed commands.
Starts the MCP server.

LibJuno

Robin Onsay
