JSON Studio

A Swiss Army knife for JSON in VS Code. View, edit, repair, query, reshape, convert and compare JSON without leaving the editor.

Open it

• Click the split-view icon in the editor title bar of any .json file (Open JSON Studio to the Side).
• Or right-click a file in the Explorer and choose Open in JSON Studio, or use Reopen Editor With… → JSON Studio.
• To make it the default for JSON, add "workbench.editorAssociations": { "*.json": "jsonStudio.editor" } to your settings.

JSON Studio edits the real file. Every change from the tree or table is a normal text edit, so undo/redo, dirty state, save, git and your comments all keep working. Keep the text editor open beside it and the two stay in sync: selecting a node highlights its text, and moving the cursor selects the node.

Features

View and beautify

• Virtualized tree that handles large files. Collapse to depth 1/2/3 or expand everything (Alt+click a node to expand or collapse its whole subtree).
• Collapsed nodes show a one-line preview of their contents.
• Breadcrumbs and node/depth/size statistics.
• Beautify (keeps comments), Minify and Sort keys (recursive). The indent is set by jsonStudio.indent.
• The status bar shows the JSONPath under the cursor; click it to copy the path as JSONPath, JavaScript, jq, JMESPath or JSON Pointer.

Repair broken JSON

Fixes trailing commas, single quotes, unquoted keys, comments, missing commas or brackets, Python True/None, NDJSON, JSONP wrappers and Markdown code fences. You always see a diff preview before anything changes. Repair is available from the toolbar, the command palette, and as a quick fix (💡) on any syntax error. While a file is broken, JSON Studio shows a read-only preview of the repaired data.

Search, query and filter

One query bar with four languages:

| Mode | Example | |---|---| | Text / regex | isbn (match case, whole word, regex; keys, values or both) | | JSONPath | $..book[?(@.price < 10 && @.tags)].title | | JMESPath | store.book[?price > \10`].{title: title, by: author}| | jq |.store.book[] | select(.price < 10) | {title, author}` |

• Results update as you type. Press Enter to also save the query to history.
• Filter tree shows only the matches and their parents (Text and JSONPath).
• From selected node runs the query against the selected subtree only.
• Use selected path fills the query with the selected node's path.
• The ? button lists examples, ⏱ shows recent queries and ☆ saves the current one.

Table view and editing

• Opens any array of objects, or an object of objects, as a grid. The first array found is chosen automatically, or use "Open as table" on any node.
• Sort by clicking a column header. Filter per column (text contains, or >10, <=3, =x, !=x) or across all columns.
• Resize and drag-reorder columns, and hide them.
• Flatten nested shows nested objects as a.b.c columns. Nested arrays of objects open as their own table (↳).
• Double-click or press Enter to edit a cell; values keep their type. Add, insert, duplicate and delete rows. Add, rename and delete columns, which applies to every row.
• Keyboard: arrow keys and Tab move between cells, Enter edits, Delete sets a cell to null, Cmd/Ctrl+C copies a cell.
• Export ▾ copies as TSV (paste straight into Excel or Sheets), or exports JSON, CSV or YAML to a new tab or a file.

Save query results

From the results panel:

• Open in new tab: an untitled JSON document.
• Save / Export: to a JSON, CSV or YAML file, or open as CSV or YAML.
• Copy the result.
• Replace document with result (can be undone).

Results can also be viewed as a table.

Transform toolkit

Flatten/unflatten, remove nulls, remove empty values, dedupe arrays, sort an array by key (use -key for descending), sort keys, escape to a string or unescape a string, and decode embedded JSON (string values that contain JSON). Every transform runs on the selected node or the whole document.

Convert and generate

• Convert JSON to YAML, CSV, TSV, XML or TOML, and YAML/CSV/XML/TOML back to JSON. CSV columns like a.b become nested objects.
• Generate types from sample data: TypeScript, TypeScript + Zod, Go, Python, Rust, Java, C#, Kotlin, Swift or Dart.
• Infer a JSON Schema from sample data.

Validate and diff

• Validate against a JSON Schema (draft-07, 2019-09 or 2020-12) from the document's $schema, the jsonStudio.schema.path setting, a file or a URL. Problems appear in the Problems panel on the exact keys and values, and update as you type.
• Semantic diff with another file or the clipboard. Key order is ignored, and array items are matched by jsonStudio.diff.arrayIdKey (default id). It shows a side-by-side diff of the normalized documents, a list of changes, and an RFC 6902 JSON Patch export.

Settings

Development

npm install
npm run build          # extension (esbuild) + webview (Vite)
npm test               # unit tests (vitest)
npm run test:integration   # smoke tests inside VS Code
npm run package        # build a .vsix

Press F5 to launch an Extension Development Host with test/fixtures open. Run node test/fixtures/generate-large.mjs to create a 5,000-row file for testing the table.

Layout: src/core holds the pure, unit-tested logic (parse, edit, query, transform, convert, schema, diff). src/extension is the VS Code host. webview/ is the React UI.
