LogSense

AI-Powered Error Analysis — right inside VS Code

---

Table of Contents

• Project Overview
• Key Features
• Core Tech Stack
• File Architecture
• Installation & Setup
• Environment Variables
• API Reference
• Usage & Workflow
• Extension Commands
• Architecture Diagram
• Data Sanitization

---

Project Overview

LogSense is a VS Code extension backed by a Node.js API server that uses Google Gemini AI to instantly explain error logs and suggest fixes. Developers can:

1. Paste an error log into the extension panel, or
2. Select text in the editor → right-click → "Analyze Error with LogSense" (or press Ctrl+Shift+L)
3. Apply the AI-suggested fix directly into the editor with a single click

The extension sends the log to the backend, which queries the user's chosen Gemini model (defaults to Gemini 2.5 Flash), parses the AI's response into an Explanation and a Suggested Fix, persists the analysis in MongoDB, and returns it to the extension UI — complete with syntax-highlighted code blocks and one-click apply.

---

Key Features

• 🔍 Instant AI Analysis — Paste a log or select text in the editor to get a clear explanation and actionable fix in seconds.
• 🤖 Model Selector — Choose from 5 Gemini models (2.5 Flash, 2.5 Pro, 2.5 Flash-Lite, 3 Flash, 3.1 Pro) directly in the settings panel. Your choice persists across sessions.
• 🔑 Bring Your Own Key (BYOK) — Use your personal Gemini API key stored securely in your OS keychain via VS Code's SecretStorage. Falls back to the server-side key if none is configured.
• ⚡ One-Click Apply Fix — Apply the AI-suggested code fix directly into your editor. Replaces the current selection or inserts at the cursor position.
• 🛡️ Data Sanitization — A built-in middleware automatically redacts API keys, tokens, passwords, and local file paths before any log reaches the AI.
• 📜 Analysis History — Every analysis is persisted in MongoDB with paginated retrieval per user.
• 🎨 Premium Dark UI — Glassmorphism surfaces, gradient accents, shimmer loading skeletons, and smooth micro-animations.
• 🌐 14 Languages & 15 Frameworks — Context-aware analysis with dropdown selectors for language and framework.

---

Core Tech Stack

Layer	Technology	Version	Purpose
Extension Host	TypeScript + VS Code API	5.9 / 1.85+	Registers commands, manages webview lifecycle, SecretStorage for API keys, globalState for model selection, bridges editor ↔ webview
Webview UI	React + Vite + TailwindCSS	19 / 8 / 4	Glassmorphism dark-theme UI rendered inside VS Code
Syntax Highlighting	react-syntax-highlighter (Prism)	16.x	Renders code blocks in AI responses with language-aware coloring
Backend Server	Express.js	5.2	REST API with CORS, JSON parsing, route management
AI Engine	Google Gemini AI (@google/generative-ai)	0.24	Supports multiple models: gemini-2.5-flash (default), gemini-2.5-pro, gemini-2.5-flash-lite, gemini-3-flash, gemini-3.1-pro
Database	MongoDB via Mongoose	9.3	Persists analysis history per user
Middleware	Custom sanitizer	—	Regex-based redaction of secrets and file paths

---

File Architecture

LogSense/
├── backend/                          # Express.js API Server
│   ├── .env                          # Local environment variables (git-ignored)
│   ├── .env.example                  # Template for required env vars
│   ├── .gitignore                    # Ignores node_modules/ and .env
│   ├── package.json                  # Backend dependencies & scripts
│   └── src/
│       ├── server.js                 # App entry — Express + MongoDB bootstrap
│       ├── routes/
│       │   └── api.js                # Route definitions (POST /analyze, GET /history)
│       ├── controllers/
│       │   ├── analyzeController.js  # Gemini AI integration + BYOK + model selection + retry
│       │   └── historyController.js  # Paginated history retrieval
│       ├── middlewares/
│       │   └── sanitizer.js          # Secret & path redaction middleware
│       └── models/
│           └── LogHistory.js         # Mongoose schema for analysis records
│
└── extension/                        # VS Code Extension
    ├── package.json                  # Extension manifest (commands, menus, keybindings)
    ├── tsconfig.json                 # TypeScript config for the extension host
    ├── src/
    │   └── extension.ts              # Extension entry — commands, BYOK, model selection, Apply Fix
    └── webview-ui/                   # React Frontend (embedded in VS Code webview)
        ├── index.html                # Vite HTML entry point
        ├── vite.config.ts            # Vite build config (single-bundle, no code splitting)
        ├── tsconfig.json             # Root TS config for the React app
        ├── tsconfig.app.json         # App-specific TS config
        ├── tsconfig.node.json        # Node/Vite TS config
        ├── eslint.config.js          # ESLint config for the React app
        ├── package.json              # Webview dependencies (React, syntax highlighter)
        ├── public/
        │   ├── favicon.svg           # LogSense icon
        │   └── icons.svg             # Additional SVG icons
        └── src/
            ├── main.tsx              # React entry — renders <App /> into #root
            ├── App.tsx               # Root component — state, BYOK settings, model selection, API calls
            ├── index.css             # Global CSS — design tokens, glassmorphism, animations
            ├── hooks/
            │   └── useVscode.ts      # VS Code ↔ Webview messaging bridge
            ├── components/
            │   ├── LogInputArea.tsx   # Textarea for error log input
            │   ├── ContextSelectors.tsx # Language & framework dropdowns
            │   └── ResultPanel.tsx    # AI response renderer with code blocks + Apply Fix
            └── assets/
                ├── hero.png          # Hero image asset
                └── vite.svg          # Vite logo asset

Detailed File Reference

Backend (backend/)

File	Role
src/server.js	Application entry point. Loads environment variables via dotenv, initializes Express with CORS and JSON parsing (1MB limit), mounts API routes at /api/v1, provides a /health endpoint, connects to MongoDB via Mongoose, and starts the HTTP server on the configured port.
src/routes/api.js	Route definitions. Maps POST /api/v1/analyze (with sanitizer middleware) to the analyze controller and GET /api/v1/history/:userId to the history controller.
src/controllers/analyzeController.js	Core analysis logic. Supports BYOK (Bring Your Own Key) — if the request includes a user-provided API key, a per-request Gemini instance is created; otherwise a cached server-side instance is used. Supports model selection — the client sends a model field in the request body (defaults to gemini-2.5-flash); model instances are cached per model name in a Map. Constructs a structured prompt forcing two-section responses (Explanation + Suggested Fix), implements retry with exponential backoff (5 attempts, 3s/6s/12s/24s delays) for 429 rate-limit errors, parses the AI response with regex, persists results to MongoDB, and returns actionable error messages for quota/model/key failures.
src/controllers/historyController.js	History retrieval. Returns paginated analysis records for a given userId, sorted newest-first. Accepts ?page= and ?limit= query params (limit capped at 50). Uses Promise.all for concurrent count + fetch.
src/middlewares/sanitizer.js	Data sanitization. Runs before the analyze controller. Applies regex patterns to redact: generic API keys (sk-...), AWS keys (AKIA...), token/password/apikey assignments, and user-identifying file paths (Windows C:\Users\, macOS /Users/, Linux /home/). Replaces with [REDACTED_*] tokens.
src/models/LogHistory.js	Mongoose schema. Defines the LogHistory collection with fields: userId (indexed), rawLog (max 5000 chars with setter truncation), languageContext, aiExplanation, aiSuggestedFix, and createdAt timestamp.
.env.example	Environment template. Documents the three required variables: MONGODB_URI, GEMINI_API_KEY, PORT.

Extension (extension/)

File	Role
package.json	Extension manifest. Declares four commands (logsense.start, logsense.analyzeSelection, logsense.setApiKey, logsense.removeApiKey), a context menu entry (visible when text is selected), and a keybinding (Ctrl+Shift+L / Cmd+Shift+L). Published by Rishabh-Sharma. Targets VS Code ≥ 1.85.
src/extension.ts	Extension host entry point. On activation, registers all four commands and tracks the last active text editor (to support Apply Fix even when the webview has focus). logsense.start opens the webview panel. logsense.analyzeSelection captures the editor selection, opens the panel, and sends the text to the webview via postMessage. logsense.setApiKey prompts for a Gemini API key via a secure input dialog and stores it in VS Code's SecretStorage (OS keychain). logsense.removeApiKey deletes the stored key. Persists the selected Gemini model in globalState and syncs it to the webview via modelStatus/setModel messages. Implements a ready handshake: the webview sends "webviewReady" on mount, and the extension responds with API key status, model selection, and any pending log text. Handles applyFix messages by replacing the editor selection (or inserting at cursor) with the AI-suggested code. Generates the webview HTML with a strict Content Security Policy (CSP) including nonce-based script loading. Resets state on panel disposal.
tsconfig.json	TypeScript configuration. Targets ES2020, outputs CommonJS modules to out/, enables strict mode, excludes node_modules and webview-ui.

Webview UI (extension/webview-ui/)

File	Role
src/main.tsx	React entry point. Renders <App /> inside <StrictMode> into the #root DOM node.
src/App.tsx	Root application component. Manages all state (log text, language, framework, loading, results, error, API key status, selected model). The settings panel (gear icon with green/yellow status dot) contains two sections: API Key Configuration (BYOK) and Model Selection (dropdown of 5 Gemini models: 2.5 Flash, 2.5 Pro, 2.5 Flash-Lite, 3 Flash, 3.1 Pro). On mount, sends "webviewReady" to the extension host. Listens for "setLog", "apiKeyStatus", "apiKeyValue", and "modelStatus" messages. Before each analysis call, asynchronously requests the stored API key and includes both the key and selected model in the POST body. Renders the ambient glow background, header with settings button, input area, context selectors, action buttons, status bar, error banner, and result panel.
src/index.css	Global design system. Defines CSS custom properties for the entire dark theme (deep space palette, glassmorphism surfaces, semantic colors, gradient system, shadows). Contains utility classes: .glass-card, .ls-input, .ls-select, .ls-btn-primary, .ls-btn-ghost, .ls-label. Defines all animations: fadeInUp, fadeIn, slideDown, dotPulse, shimmer, pulseGlow, gradientShift, spin. Includes ambient glow background, custom scrollbar, code block wrapper, and Apply Fix button styles with hover reveal and applied state.
src/hooks/useVscode.ts	VS Code messaging bridge. Caches the singleton acquireVsCodeApi() instance (can only be called once per session). Exports getVsCodeApi() and postMessageToExtension() for sending commands to the extension host.
src/components/LogInputArea.tsx	Log input component. Renders a monospace textarea with placeholder text, a terminal-style section label, and a floating Ctrl+Shift+L keyboard shortcut hint overlay. Applies glass-card input styling with focus ring.
src/components/ContextSelectors.tsx	Context dropdowns. Renders two <select> elements for Language (14 options: TypeScript, JavaScript, Python, Java, C#, C++, Go, Rust, Ruby, PHP, Swift, Kotlin, Dart, Shell) and Framework (15 options: None, React, Next.js, Angular, Vue.js, Express.js, Spring Boot, Django, Flask, Rails, Laravel, ASP.NET, Flutter, NestJS, FastAPI). Uses custom-styled selects with SVG chevron arrows.
src/components/ResultPanel.tsx	AI response renderer. Parses markdown code blocks from the AI response using a flexible regex (parseBlocks) that handles both multi-line and single-line fenced code blocks, splitting into text and code segments. Renders code blocks with react-syntax-highlighter (Prism, oneDark theme) with line numbers. Displays two sections with colored left accent borders: blue for Explanation, green for Suggested Fix. Code blocks in the Suggested Fix section include an Apply Fix button that appears on hover — clicking it sends an applyFix message to the extension host, which replaces the editor selection with the code. Includes a LoadingSkeleton component with shimmer effect and dot-pulse animation during analysis.
vite.config.ts	Build configuration. Uses @vitejs/plugin-react and @tailwindcss/vite. Outputs a single bundle (no code splitting) to dist/assets/ with deterministic filenames — required for webview injection where the extension reads built file names from disk.

---

Installation & Setup

Prerequisites

• Node.js ≥ 18.x
• npm ≥ 9.x
• VS Code ≥ 1.85.0
• A MongoDB instance (local or MongoDB Atlas)
• A Google Gemini API key (Get one free)

1. Clone the Repository

git clone https://github.com/rishabhsharmaa/LogSense.git
cd LogSense

2. Set Up the Backend

cd backend
npm install

Create the environment file:

cp .env.example .env

Edit .env with your actual values (see Environment Variables).

Start the server:

# Production
npm start

# Development (auto-reloads on file changes)
npm run dev

The backend will connect to MongoDB and start on http://localhost:3001.

3. Build the Extension

cd ../extension

# Install extension host dependencies
npm install

# Install webview UI dependencies
cd webview-ui
npm install

# Build the React webview
npm run build

# Compile the extension TypeScript
cd ..
npm run compile

4. Run in VS Code

1. Open the extension/ folder in VS Code
2. Press F5 to launch the Extension Development Host
3. In the new window, press Ctrl+Shift+P → type "LogSense: Open Panel"

---

Environment Variables

All variables are configured in backend/.env:

Variable	Required	Default	Description
MONGODB_URI	✅	mongodb://localhost:27017/logsense	MongoDB connection string. Supports both local instances and Atlas SRV URIs (mongodb+srv://...).
GEMINI_API_KEY	❌	—	Server-side fallback Gemini API key. Not required if all users provide their own key via BYOK. Get one from AI Studio.
PORT	❌	3001	Port for the Express server. The extension webview hardcodes localhost:3001 in its fetch calls — if you change this, update API_BASE in App.tsx accordingly.

Note: With BYOK support, the GEMINI_API_KEY environment variable is now optional. Users can configure their personal API key directly in VS Code via LogSense: Set Gemini API Key. The key is stored securely in the OS keychain and sent with each analysis request.

---

API Reference

Base URL: http://localhost:3001/api/v1

POST /analyze

Analyzes an error log using Gemini AI.

Middleware: Sanitizer (redacts secrets and file paths from the log before processing)

Request Body:

{
  "log": "Error: Main method not found in the file...",
  "language": "Java",
  "context": "Spring Boot",
  "userId": "vscode-user",
  "model": "gemini-2.5-flash",
  "apiKey": "user-provided-gemini-api-key"
}

Field	Type	Required	Description
log	string	✅	The error log or stack trace to analyze. Truncated to 5,000 characters before storage.
language	string	✅	Programming language for context (e.g., "TypeScript", "Python", "Java").
context	string	❌	Framework or environment context (e.g., "React", "Django"). Passed as empty string if omitted.
userId	string	❌	User identifier for history tracking. Defaults to "anonymous".
model	string	❌	Gemini model identifier. Defaults to "gemini-2.5-flash". Supported: gemini-2.5-flash, gemini-2.5-pro, gemini-2.5-flash-lite, gemini-3-flash, gemini-3.1-pro.
apiKey	string	❌	User-provided Gemini API key (BYOK). If supplied, a per-request Gemini instance is created. If omitted, the server-side GEMINI_API_KEY from .env is used.

Success Response 200 OK:

{
  "id": "6745a1b2c3d4e5f6a7b8c9d0",
  "explanation": "This error indicates that the JVM could not find the required entry point...",
  "suggestedFix": "Ensure your class contains a `main` method with the signature...\n\n```java\npublic static void main(String[] args) {\n    System.out.println(\"Hello\");\n}\n```"
}

Error Responses:

Status	Error Message	Cause
400	Missing required fields: 'log' and 'language' are required.	Request body missing log or language.
401	Gemini API key is missing or invalid. Please configure your API key in LogSense settings.	No API key provided (neither BYOK nor server-side), or the key was rejected by Google.
429	AI API quota exceeded. Please wait a minute and try again, or check your Gemini API billing.	Gemini rate limit hit after 5 retry attempts with exponential backoff.
500	AI model not available. Please contact the extension maintainer.	The configured model name is invalid or deprecated.
500	Failed to analyze the log. Please try again.	Generic server/database error.

---

GET /history/:userId

Retrieves paginated analysis history for a user.

Query Parameters:

Param	Type	Default	Description
page	number	1	Page number (minimum 1).
limit	number	10	Records per page (minimum 1, maximum 50).

Example: GET /api/v1/history/vscode-user?page=1&limit=5

Success Response 200 OK:

{
  "page": 1,
  "limit": 5,
  "total": 12,
  "totalPages": 3,
  "data": [
    {
      "_id": "6745a1b2c3d4e5f6a7b8c9d0",
      "userId": "vscode-user",
      "rawLog": "Error: Main method not found...",
      "languageContext": "Java / Spring Boot",
      "aiExplanation": "This error indicates...",
      "aiSuggestedFix": "Add a main method...",
      "createdAt": "2026-04-03T19:50:58.000Z"
    }
  ]
}

---

GET /health

Health check endpoint (mounted at root, not under /api/v1).

Example: GET http://localhost:3001/health

Response:

{
  "status": "ok",
  "uptime": 1234.567
}

---

Usage & Workflow

Method 1: Open the Panel Manually

1. Press Ctrl+Shift+P (or Cmd+Shift+P on macOS)
2. Type "LogSense: Open Panel" and select it
3. Paste your error log into the textarea
4. Select the Language and optionally a Framework
5. Click Analyze

Method 2: Analyze from the Editor (Recommended)

1. Select the error text in any editor tab
2. Right-click → Choose "Analyze Error with LogSense"
   • Or press Ctrl+Shift+L (Cmd+Shift+L on macOS)
3. The LogSense panel opens automatically with the selected text pre-filled
4. Click Analyze

Method 3: Apply the Fix

1. After analysis, hover over any code block in the Suggested Fix section
2. Click the Apply Fix button that appears
3. The code replaces your current editor selection (or inserts at cursor if nothing is selected)

Configure Your Own API Key (BYOK)

1. Click the ⚙ gear icon in the LogSense panel header, or
2. Run Ctrl+Shift+P → "LogSense: Set Gemini API Key"
3. Enter your Gemini API key in the secure input dialog
4. The key is stored in your OS keychain and never leaves your machine
5. A green status dot on the gear icon confirms the key is active

Choose a Gemini Model

1. Click the ⚙ gear icon in the LogSense panel header
2. Scroll to the Model Selection section (below API Key Configuration)
3. Select from the dropdown:
   • Gemini 2.5 Flash — Fast & balanced (default)
   • Gemini 2.5 Pro — Best reasoning & coding
   • Gemini 2.5 Flash-Lite — Fastest, most cost-efficient
   • Gemini 3 Flash — Next-gen balanced
   • Gemini 3.1 Pro — Most advanced
4. Your selection persists across sessions and is sent with every analysis request

Common CLI Commands

# ─── Backend ─────────────────────────────────────────────────
cd backend
npm start              # Start the production server
npm run dev            # Start with auto-reload (--watch)

# ─── Extension ───────────────────────────────────────────────
cd extension
npm run compile        # Compile extension TypeScript → out/
npm run watch          # Watch mode for development

# ─── Webview UI ───────────────────────────────────────────────
cd extension/webview-ui
npm run dev            # Start Vite dev server (for standalone preview)
npm run build          # Production build → dist/
npm run lint           # Run ESLint

---

Extension Commands

Command	Keybinding	Context Menu	Description
LogSense: Open Panel	—	—	Opens the LogSense webview panel beside the editor.
Analyze Error with LogSense	Ctrl+Shift+L / Cmd+Shift+L	✅ (when text is selected)	Captures the selected text, opens the panel, and auto-fills the input for analysis.
LogSense: Set Gemini API Key	—	—	Opens a secure input dialog to store your personal Gemini API key in the OS keychain. Submit an empty value to remove the key.
LogSense: Remove API Key	—	—	Removes the stored Gemini API key from the OS keychain and reverts to the server-side default.

---

Architecture Diagram

sequenceDiagram
    participant Editor as VS Code Editor
    participant Ext as Extension Host
    participant KS as OS Keychain
    participant GS as globalState
    participant WV as Webview (React)
    participant API as Express Backend
    participant San as Sanitizer
    participant AI as Gemini AI
    participant DB as MongoDB

    Note over Ext,GS: Settings (persisted)
    Ext->>KS: Store API key via SecretStorage
    Ext->>GS: Store selected model via globalState

    Editor->>Ext: User selects text + triggers command
    Ext->>WV: postMessage({ command: "setLog", text })
    Note over Ext,WV: Handshake: waits for "webviewReady" if panel is new

    WV->>Ext: postMessage({ command: "getApiKey" })
    Ext->>KS: Retrieve stored key
    KS-->>Ext: API key (or empty)
    Ext-->>WV: postMessage({ command: "apiKeyValue", apiKey })

    WV->>API: POST /api/v1/analyze { log, language, context, model, apiKey }
    API->>San: sanitizerMiddleware (redact secrets/paths)
    San-->>API: Sanitized log
    API->>AI: generateContent(prompt) [selected model + BYOK/server key]
    Note over API,AI: Retry up to 5× with exponential backoff on 429
    AI-->>API: Markdown response (## Explanation + ## Suggested Fix)
    API->>API: Parse response with regex
    API->>DB: LogHistory.create({ ... })
    API-->>WV: { explanation, suggestedFix }
    WV->>WV: parseBlocks() → render with syntax highlighting

    Note over WV,Editor: Apply Fix Flow
    WV->>Ext: postMessage({ command: "applyFix", text: code })
    Ext->>Editor: editor.edit() → replace selection or insert at cursor
    Ext->>Editor: showInformationMessage("Fix applied ✓")

---

Data Sanitization

Before any log reaches the AI, the sanitizer middleware automatically redacts:

Pattern	Example Input	Redacted Output
API Keys (sk-...)	sk-abc123def456ghi789jkl012mno345pqr	[REDACTED_API_KEY]
AWS Keys (AKIA...)	AKIA1234567890ABCDEF	[REDACTED_AWS_KEY]
Tokens/Passwords	password=MyS3cretP@ss!	password=[REDACTED]
Windows Paths	C:\Users\john\project\	[REDACTED_PATH]\
macOS Paths	/Users/john/project/	/[REDACTED_PATH]/
Linux Paths	/home/john/project/	/[REDACTED_PATH]/

---

License

ISC

---

_{Built with ❤️ by Rishabh Sharma using Gemini AI, Express, React, and VS Code}
