WinCC OA Test Explorer

✨ Features

🔍 Test Discovery

• Automatic discovery of WinCC OA test files in workspace
• Support for both WinCC OA 3.19 and 3.20 test formats
  • 3.19: getAllTestCaseIds() with switch/case structure
  • 3.20: public int test*() methods
• Auto-refresh on file changes
• Workspace folder hierarchy

🚀 Test Execution

• Run individual test files or entire folders
• Click-to-navigate for all test states (passed, failed, aborted)
• Accurate error locations with StackTrace parsing
• Individual test messages per assertion
• Test execution queue to prevent conflicts

📊 Test Results

• Visual test status indicators in Test Explorer sidebar
• Detailed error messages with file and line references
• Test duration tracking
• Structured logging with configurable log levels

🎨 IDE Integration

• Native VS Code Test Explorer UI
• Recursive folder execution
• Multi-workspace support

🚀 Getting Started

Prerequisites

• Visual Studio Code ^1.106.2
• WinCC OA installation (3.19 or higher)
• WinCC OA Script Actions extension (required for test execution)

Installation

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X)
3. Search for "WinCC OA Test Explorer"
4. Click Install
5. Install the required WinCC OA Script Actions extension

⚙️ Configuration

Configure the extension in your VS Code settings.json:

{
  "winccoaTests.testFilesPattern": "scripts/tests/**/*.ctl",
  "winccoaTests.logLevel": "INFO"
}

Settings Reference

📋 Usage

Discovering Tests

1. Open a WinCC OA project workspace in VS Code
2. The extension will automatically scan for test files
3. View discovered tests in the Test Explorer sidebar (beaker icon)

Running Tests

Via Test Explorer:

• Click the ▶️ icon next to a test file or folder
• Use the Run All Tests button in the toolbar

Via Command Palette:

• WinCC OA Tests: Run All Tests - Run all discovered tests
• WinCC OA Tests: Refresh Tests - Manually refresh test discovery

Test File Formats

WinCC OA 3.19 Format:

main() {
    getAllTestCaseIds();
}

getAllTestCaseIds() {
    dyn_string ids;
    ids[1] = "tc_01_example";
    return ids;
}

test(string id) {
    switch(id) {
        case "tc_01_example":
            // Arrange
            int expected = 5;
            // Act
            int actual = 2 + 3;
            // Assert
            oaTest_assert(expected == actual);
            break;
    }
}

WinCC OA 3.20 Format:

public int test_example() {
    // Arrange
    int expected = 5;
    // Act
    int actual = 2 + 3;
    // Assert
    oaTest_assert(expected == actual);
    return 0;
}

🛠️ Requirements

• Visual Studio Code 1.106.2 or higher
• WinCC OA installation with test framework
• WinCC OA Script Actions extension for test execution
• Valid WinCC OA project with test files

⚠️ Known Limitations

• Individual test case execution not yet supported (runs entire file)
• Test debugging support not yet implemented

🤝 Contributing

Contributions are welcome! Please read CONTRIBUTING.md for details.

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

👥 Authors

winccoa-tools-pack

• GitHub: @winccoa-tools-pack

⚠️ Disclaimer

WinCC OA and Siemens are trademarks of Siemens AG. This project is not affiliated with, endorsed by, or sponsored by Siemens AG. This is a community-driven open source project created to enhance the development experience for WinCC OA developers.
