Relay

VS Code Marketplace Quick Start

1. Install the Relay extension from the VS Code Marketplace.
2. Open your repository in VS Code.
3. Run Relay: Link Workspace from the Command Palette.
4. Paste a pair code generated in the Relay dashboard.
5. Sign in with GitHub from the Relay sidebar to load tasks.

Relay is a Slack-to-IDE workflow system:

• VS Code extension for developers
• Hosted API + Postgres system of record
• Dashboard for PM setup and task operations

Compatibility note:

• Preferred repo config: .relay/config.json
• Legacy configs still supported: .contexthud/config.json, .contexthud/users.json

1) API Server Setup

Create .env from .env.example.

Required for API:

• DATABASE_URL
• APP_BASE_URL
• GITHUB_CLIENT_ID
• GITHUB_CLIENT_SECRET
• SESSION_SECRET
• SLACK_SIGNING_SECRET
• SLACK_BOT_TOKEN
• ADMIN_API_KEY

Optional:

• ADMIN_GITHUB_LOGINS (comma-separated GitHub logins with platform admin rights)

Run:

npm install
npm run db:migrate
npm run server:start

Health:

curl -i http://localhost:8787/health/live
curl -i http://localhost:8787/health

2) VS Code Extension Setup

Build and run:

npm run build

Press F5 in VS Code to launch Extension Development Host.

Link workspace from command palette:

• Relay: Link Workspace

This uses a pair code from dashboard and writes .relay/config.json automatically.

Manual fallback still exists:

• Relay: Initialize Project Config

3) Dashboard Setup (Phase 4A)

Dashboard lives in dashboard/ (Next.js App Router).

Install/run:

npm run dashboard:install
npm run dashboard:dev

By default dashboard runs at http://localhost:3001.

Dashboard env vars (see dashboard/.env.example):

• RELAY_API_BASE_URL (API root, e.g. http://localhost:8787)
• NEXT_PUBLIC_API_BASE_URL (same value; used in snippets/UI)
• DASHBOARD_BASE_URL (e.g. http://localhost:3001)
• DASHBOARD_SESSION_SECRET (required for httpOnly session cookies)
• DASHBOARD_ADMIN_API_KEY (recommended if project creation is admin-only on API)
• RELAY_ADMIN_API_KEY or ADMIN_API_KEY (legacy fallbacks)

4) PM Onboarding Flow (Frictionless)

Dashboard goal flow:

1. Create workspace
2. Connect Slack
3. Generate pair code for developer
4. Developer runs Relay: Link Workspace in VS Code
5. Share invite link with teammates

No manual JSON config copy required.

5) API Endpoints

Auth

• POST /auth/vscode/start
• GET /auth/github/login
• GET /auth/github/callback
• GET /auth/github/token?loginId=...
• GET /me

Admin key endpoints

• POST /admin/projects
• POST /admin/projects/:projectId/members
• POST /admin/projects/:projectId/map/slack-user
• GET /admin/projects/:projectId/debug-assignment

Authenticated dashboard endpoints

• GET /projects
• POST /projects (platform admin required)
• GET /projects/:projectId/members
• POST /projects/:projectId/members (owner/admin)
• GET /projects/:projectId/slack/status
• GET /projects/:projectId/slack/users
• POST /projects/:projectId/slack/map-user (owner/admin)
• GET /projects/:projectId/tasks?assigned=me|all&view=list|kanban
• POST /projects/:projectId/tasks
• GET /projects/:projectId/tasks/:taskId
• PATCH /projects/:projectId/tasks/:taskId
• POST /projects/:projectId/tasks/:taskId/commits

Slack ingest endpoints

• POST /ingest/slack (global, preferred)
• POST /ingest/slack/:projectId
• POST /ingest/slack-nudge/:projectId
• POST /slack/nudge?projectId=<projectId>

/nudge input format

• Use explicit file prefix to avoid ambiguity: %path/to/file.ts
• If no prefixed file is provided, full text after assignee is treated as task description
• Examples:
  • /nudge @mayank %src/extension.ts Fix refresh bug
  • /nudge @mayank Build xyz

Onboarding endpoints

• POST /projects/:projectId/slack/connect
• POST /projects/:projectId/pair-codes
• POST /pair/verify
• POST /projects/:projectId/invites
• POST /invites/:token/accept
• GET /projects/:projectId/onboarding

6) Dashboard Pages

• /login
  • GitHub sign-in start + completion
• /projects
  • List/create workspaces
  • Onboarding checklist
  • Connect Slack button
  • Pair code generation
  • Invite link generation
• /projects/[projectId]/integrations/slack
  • Connection status + last event
  • Auto-linking visibility for Slack users
• /projects/[projectId]/tasks
  • Task list (status + assignee)
  • Create task
  • Update status/assignee
• /join/[token]
  • Join-by-link workspace invite flow

7) Deployment Notes (Railway)

API service:

• Start command: npm run railway:start
• Set all required API env vars listed above

Dashboard service (separate Railway service recommended):

• Root directory: dashboard
• Build command: npm run build
• Start command: npm run start
• Set dashboard env vars from section 3

8) Manual Test Checklist

1. Start API + run migrations.
2. Sign into dashboard at /login.
3. Create project in /projects.
4. Add yourself as member/owner.
5. Configure Slack request URLs for that projectId.
6. Map Slack user to GitHub login in Slack integration page.
7. Create task from Slack; confirm it appears in dashboard tasks.
8. Create/update task from dashboard; confirm persisted state.
9. Open VS Code extension, point to same API/project, verify same tasks load.

9) Public Slack App Readiness

Before enabling Slack public distribution, ensure these repo and platform settings are in place.

Repo hygiene

• Keep secrets only in env vars.
• Do not commit local runtime config files:
  • .relay/config.json
  • .relay/users.json
  • .contexthud/config.json
  • .contexthud/users.json
  • .vscode/settings.json
• Use templates instead:
  • .relay/config.example.json
  • .contexthud/config.example.json
  • .contexthud/users.example.json
  • .vscode/settings.example.json

Slack app settings (single official Relay app)

• OAuth Redirect URL: https://<API_DOMAIN>/auth/slack/callback
• Event Request URL: https://<API_DOMAIN>/ingest/slack
• Slash Command URL: https://<API_DOMAIN>/slack/nudge
• Required bot scopes currently used by API:
  • commands
  • chat:write
  • app_mentions:read
  • channels:history
  • users:read
  • im:write

GitHub OAuth settings

• In your GitHub OAuth app, set callback URL to:
  • https://<API_DOMAIN>/auth/github/callback

Railway (API service) env vars

Set at minimum:

• DATABASE_URL
• APP_BASE_URL
• GITHUB_CLIENT_ID
• GITHUB_CLIENT_SECRET
• SESSION_SECRET
• SLACK_CLIENT_ID
• SLACK_CLIENT_SECRET
• SLACK_SIGNING_SECRET
• SLACK_BOT_TOKEN
• ADMIN_API_KEY

Optional but recommended:

• SLACK_REDIRECT_URI = https://<API_DOMAIN>/auth/slack/callback
• GITHUB_WEBHOOK_SECRET (for PR-merge auto-close webhook)
• ADMIN_GITHUB_LOGINS

Vercel (Dashboard) env vars

• RELAY_API_BASE_URL = https://<API_DOMAIN>
• NEXT_PUBLIC_API_BASE_URL = https://<API_DOMAIN>
• DASHBOARD_BASE_URL = https://<DASHBOARD_DOMAIN>
• DASHBOARD_SESSION_SECRET
• DASHBOARD_ADMIN_API_KEY (if project creation is admin-guarded)

After any env update, redeploy both services.

10) Relay-Native Task Migration (Expand -> Dual-write -> Switch-read -> Contract)

This repo now supports phased migration from Slack-centric task identity to Relay-native task identity.

Feature flags

• TASKS_DUAL_WRITE (default false):
  • When true, Slack task ingestion/webhooks also upsert into:
    • task_links_slack
    • task_links_github
    • task_events_v2
• TASKS_READ_V2 (default false):
  • When true, task list/detail reads use V2 link overlays while keeping existing response shape.

Migrations

Applied by npm run db:migrate via initSchema():

1. server/sql/init.sql
2. server/sql/migrations/*.sql (sorted)
3. Compatibility migrations in server/lib/db.js

Backfill

One-time idempotent backfill script:

node server/scripts/backfill-relay-native-tasks.js --dry-run
node server/scripts/backfill-relay-native-tasks.js

Options:

• --workspace=<projectId>
• --limit=<n>

Rollout sequence

1. Deploy with TASKS_DUAL_WRITE=false, TASKS_READ_V2=false.
2. Run migrations.
3. Enable TASKS_DUAL_WRITE=true.
4. Run backfill dry-run, then backfill.
5. Validate parity in dashboard + extension.
6. Enable TASKS_READ_V2=true for pilot traffic.
7. Roll to full traffic once stable.

Rollback

1. Set TASKS_READ_V2=false.
2. Set TASKS_DUAL_WRITE=false.
3. Redeploy API.

No table drops are required for rollback; all migrations are additive.
