VS Mind
English | 中文
A VS Code extension that provides a visual mind map editor. Edit .mmf files directly in the editor with drag-and-drop nodes, themes, and styling — powered by MindElixir.

Features
- Visual editing — Create, edit, and rearrange mind map nodes with drag-and-drop
- Right-side property panel — Two tabs: Node (font, color, notes, AI notes) and Global (colors, layout, line style, background pattern)
- 8 preset themes — 4 light + 4 dark color schemes
- Layout & lines — Left / right / bilateral layout; five curated styles: smooth curve, clean straight, rounded elbow, stepped polyline, and classic underline
- Rainbow branches — Choose Global → Line colors → Rainbow branches for seven branch colors that adapt to light/dark themes; descendants inherit their branch color
- Background patterns — None, dots, grid, or cross-dot with adjustable color and opacity
- Node images — Paste images from clipboard with original-quality display. Click to select, double-click to edit text, or click an already selected image to preview full size. Empty titles take no space. Drag the selected image's bottom-right handle to resize proportionally (Esc cancels, undo/redo supported).
- Export options — Export to MMF, PNG, plaintext, or Markdown
- AI-readable context — Markdown export includes node notes and AI notes; the bundled
mmf-format skill converts MMF before an agent reads it
- Resizable panel — Drag the left edge of the side panel to adjust width (180–520 px)
- Plain JSON storage — Mind map data is saved as readable JSON; easy to version-control with Git
| Extension |
Description |
.mmf |
Mind Map Format document containing MindElixir JSON |
Getting Started
Install from Marketplace
Search for VS Mind in the VS Code Extensions view and install.
Install from Source
git clone https://github.com/Rainlin007/vs-mind.git
cd vs-mind
npm install
npm run compile
Press F5 in VS Code to launch the Extension Development Host, then open or create a .mmf file.
Usage
- Open a
.mmf file — VS Code opens it with the mind map editor automatically.
- Use the top toolbar to fold/unfold a branch, add child/sibling nodes, undo/redo, add relationships or summaries, and export. Buttons use icons with English tooltips; hover to see the action and any keyboard shortcut. Fit to view, Focus branch, and zoom controls are at the bottom-right. Fit to view scales and centers the visible map to fit the available canvas.
- Open the property panel via the sidebar icon in the editor title bar (top-right).
- In the Node tab, select a node to edit its style, note, and optional AI note.
- In the Global tab, change color scheme, layout direction, line style, and background pattern. Enable Rounded images to round all node image corners; this is saved with the map and included in PNG exports.
- Drag the left edge of the property panel to resize it.
- Changes are saved automatically to the file every 5 seconds. You can disable this in the Global tab or with the
vscode-mm.autoSave setting.
Read-only AI workflow
The bundled mmf-format skill requires agents to convert an MMF file with scripts/mmf-to-markdown.mjs and read only the generated Markdown. The source .mmf and companion image file remain user-owned and unchanged.
node skills/mmf-format/scripts/mmf-to-markdown.mjs plan.mmf --output context.md
Keyboard & Interaction
- Tab — Add a child node (when a node is selected)
- Enter — Add a sibling node
- Delete — Remove selected node(s)
- Double-click — Edit node text
- Shift + Enter — Insert a line break while editing (Enter finishes editing)
- Ctrl/Cmd + C — Copy selected nodes and their descendants
- Ctrl/Cmd + V — Paste copied nodes under the selected node, or paste an image into it
- Ctrl/Cmd + Z / Ctrl/Cmd + Shift + Z — Undo / redo (shared with the toolbar buttons)
- Relationship — Select two nodes and click the toolbar button, or select one node, click the button, then click the target. Press Esc to cancel target selection.
- Summary — Select a node or consecutive siblings on the same branch, then click the toolbar button and enter the summary text.
- Focus branch — Next to Fit to view in the bottom-right toolbar. Show the selected branch while retaining the complete document. Exit focus returns to the previous canvas position.
Development
Prerequisites
- Node.js 18+
- VS Code 1.74+
Scripts
| Command |
Description |
npm run compile |
Vendor MindElixir, compile TypeScript, bundle webview |
npm run watch |
Watch TypeScript compilation |
npm run watch:webview |
Watch webview bundle (esbuild) |
npm run test:unit |
Unit tests |
npm run test:webview |
Webview logic tests (Mocha) |
npm run test:browser |
Browser smoke test (Puppeteer) |
npm run test |
VS Code integration tests |
npm run test:all |
Run all test suites |
npm run package |
Package .vsix extension |
npm run build |
Compile + package |
Debug
- Run the Run Extension launch configuration (F5).
- In the Extension Development Host, open a
.mmf file.
- For standalone webview debugging, open
debug/webview.html in a browser or run npm run test:browser.
Project Structure
src/
├── domain/ # Core types (MindMap, ImageRepository)
├── usecases/ # Business logic (MindMapService)
├── adapters/ # Data transformation
├── frameworks/
│ ├── vscode/ # Extension host (editor provider, image storage)
│ └── webview/ # Editor UI (MindElixir, panels, themes)
└── test/ # Unit, webview, and integration tests
media/ # Bundled CSS/JS (MindElixir + main)
debug/ # Standalone webview test page
MMF documents store the raw MindElixir data structure as UTF-8 JSON. Example fields:
{
"nodeData": { "id": "root", "topic": "Central Topic", "root": true, "ai_note": "AI-only note", "children": [] },
"arrows": [],
"themeTemplate": "clayLight",
"backgroundPattern": "grid",
"bgPatternColor": "#808080",
"bgPatternOpacity": 5,
"direction": 1,
"lineStyle": "curve",
"rainbowLines": false,
"roundedImages": false
}
| Field |
Description |
themeTemplate |
Preset theme ID (auroraLight, mintLight, clayLight, …) |
direction |
Layout: 0 left, 1 right, 2 bilateral |
lineStyle |
curve | straight | elbow | step | branch |
roundedImages |
true for rounded node image corners; defaults to false. |
rainbowLines |
true for rainbow branch colors; defaults to false (theme colors). Explicit node branchColor overrides are preserved. |
backgroundPattern |
none | dots | grid | crossDot |
Nodes may include an optional ai_note string. It is stored in the MMF file for AI consumers and is not rendered on the canvas.
License
MIT
Links
中文
一款在 VS Code 中直接编辑思维导图的扩展。支持 .mmf 文件的可视化编辑、主题配色与节点样式,底层基于 MindElixir。
English | 中文
功能特性
- 可视化编辑 — 拖拽节点,增删改思维导图结构
- 右侧属性面板 — 分 节点(字号、颜色、注释、AI 备注)和 全局(配色、布局、线条、背景花纹)两个 Tab
- 8 套预设主题 — 4 款亮色 + 4 款暗色
- 彩虹线条 — 在 全局 → 线条配色 → 彩虹分支 中开启;七种分支颜色适配亮暗主题,子分支沿用所属分支颜色
- 布局与线条 — 向左 / 向右 / 双侧布局;流畅曲线、简洁直线、圆角折线、阶梯折线、经典下划线
- 背景花纹 — 无 / 点阵 / 网格 / 十字点,可调颜色与透明度
- 节点图片 — 从剪贴板粘贴图片,以原图清晰度显示;单击选中,双击编辑文字,选中后单击图片可预览原图;文字为空时自动收起占位。选中节点后拖动图片右下角可等比例调整大小,悬停或拖动时显示尺寸,支持 Esc 取消和撤销重做
- 导出选项 — 支持导出 MMF、PNG、纯文本或 Markdown
- AI 可读上下文 — Markdown 导出包含节点注释和 AI 备注;内置
mmf-format skill 会先转换 MMF,再交给 Agent 读取
- 面板可调宽 — 拖动属性面板左边缘调整宽度(180–520 px)
- 纯 JSON 存储 — 文件内容为可读 JSON,方便 Git 版本管理
支持的文件格式
| 扩展名 |
说明 |
.mmf |
Mind Map Format 文档,内容为 MindElixir JSON |
快速开始
从扩展市场安装
在 VS Code 扩展视图中搜索 VS Mind 并安装。
从源码安装
git clone https://github.com/Rainlin007/vs-mind.git
cd vs-mind
npm install
npm run compile
在 VS Code 中按 F5 启动扩展开发宿主,然后打开或新建 .mmf 文件。
使用说明
- 打开
.mmf 文件,VS Code 会自动用思维导图编辑器打开。
- 使用画布顶部工具栏折叠/展开分支、添加子节点/兄弟节点、撤销/重做、添加关系或概要,以及导出。右下角工具栏提供适应视图、聚焦分支和缩放操作。
- 点击编辑器标题栏右上角的侧栏图标打开/关闭属性面板。
- 在 节点 Tab 中选中节点,可编辑样式、注释和可选的 AI 备注。
- 在 全局 Tab 中可切换配色、布局方向、线条样式和背景花纹。勾选 Rounded images 可统一开启节点图片圆角,设置随导图保存,导出 PNG 也保留圆角。
- 拖动属性面板左边缘可调整面板宽度。
- 修改会每 5 秒自动保存到文件。可在 全局 Tab 中关闭,或修改全局设置
vscode-mm.autoSave。
AI 只读工作流
内置的 mmf-format skill 强制 Agent 先通过 scripts/mmf-to-markdown.mjs 将 MMF 转成 Markdown,然后只读取生成结果。源 .mmf 与图片伴生文件始终由用户维护,不会被 AI 修改。
node skills/mmf-format/scripts/mmf-to-markdown.mjs plan.mmf --output context.md
快捷键与交互
- Tab — 为选中节点添加子节点
- Enter — 添加兄弟节点
- Delete — 删除选中节点
- 双击 — 编辑节点文字
- Shift + Enter — 编辑时插入换行(Enter 完成编辑)
- Ctrl/Cmd + C — 复制选中节点及其子节点
- Ctrl/Cmd + V — 将复制的节点粘贴为选中节点的子节点,或粘贴图片
- 聚焦分支 — 位于右下角工具栏,与 Fit to view 并列。仅显示选中分支,保留完整文档;再次点击可退出聚焦并恢复原来的画布位置。
开发
环境要求
- Node.js 18+
- VS Code 1.74+
常用命令
| 命令 |
说明 |
npm run compile |
打包 MindElixir、编译 TypeScript、构建 webview |
npm run watch |
监听 TypeScript 编译 |
npm run watch:webview |
监听 webview 打包(esbuild) |
npm run test:unit |
单元测试 |
npm run test:webview |
Webview 逻辑测试 |
npm run test:browser |
浏览器冒烟测试(Puppeteer) |
npm run test |
VS Code 集成测试 |
npm run test:all |
运行全部测试 |
npm run package |
打包 .vsix 扩展 |
npm run build |
编译并打包 |
调试
- 使用 Run Extension 启动配置(F5)。
- 在扩展开发宿主中打开
.mmf 文件。
- 也可在浏览器中打开
debug/webview.html,或运行 npm run test:browser 进行独立 webview 测试。
项目结构
src/
├── domain/ # 核心类型
├── usecases/ # 业务逻辑
├── adapters/ # 数据转换
├── frameworks/
│ ├── vscode/ # 扩展宿主(编辑器、图片存储)
│ └── webview/ # 编辑器 UI(MindElixir、面板、主题)
└── test/ # 单元 / webview / 集成测试
media/ # 打包后的 CSS/JS
debug/ # 独立 webview 测试页
MMF 文件格式
MMF 文档直接以 UTF-8 JSON 保存 MindElixir 数据结构,示例:
{
"nodeData": { "id": "root", "topic": "中心主题", "root": true, "ai_note": "仅供 AI 使用的备注", "children": [] },
"arrows": [],
"themeTemplate": "clayLight",
"backgroundPattern": "grid",
"bgPatternColor": "#808080",
"bgPatternOpacity": 5,
"direction": 1,
"lineStyle": "curve",
"rainbowLines": false,
"roundedImages": false
}
| 字段 |
说明 |
themeTemplate |
预设主题 ID(如 auroraLight、clayLight 等) |
direction |
布局:0 向左,1 向右,2 双侧 |
lineStyle |
curve 流畅曲线 | straight 简洁直线 | elbow 圆角折线 | step 阶梯折线 | branch 经典下划线 |
roundedImages |
true 开启节点图片圆角;默认 false。 |
rainbowLines |
true 开启彩虹分支;默认 false 跟随主题。节点自定义的 branchColor 优先。 |
backgroundPattern |
none 无 | dots 点阵 | grid 网格 | crossDot 十字点 |
节点可包含可选的 ai_note 字符串,用于向 AI 提供备注,不会渲染在画布上。
预设主题一览
| 亮色 |
暗色 |
微光紫 auroraLight |
午夜紫 auroraDark |
薄荷绿 mintLight |
深海青 oceanDark |
暖阳橙 clayLight |
曜石粉 obsidianDark |
石墨灰 graphiteLight |
琥珀夜 amberDark |
许可证
MIT
