MCP Debug Hub

mcp-debug-hub is a VS Code extension that exposes VS Code's debugging capabilities through the Model Context Protocol (MCP). It enables AI coding assistants (such as Cline, Claude, Cursor, or Copilot) to control and inspect debugging sessions directly within VS Code, providing powerful debugging automation and inspection capabilities.

Key features

Debug session control: Launch, stop, and manage VS Code debug sessions programmatically
Multi-process debugging: Debug parent-child process hierarchies with full support for subprocesses, workers, and spawned processes
Breakpoint management: Set, remove, and list breakpoints with conditions, hit counts, and log messages
Code execution control: Step through code, continue execution, and pause at any point
Runtime inspection: Evaluate expressions, inspect variables, and examine call stacks
Session-aware operations: Target specific debug sessions in multi-process scenarios
Multi-language support: Works with any language supported by VS Code's debug adapters
Built-in status view: Monitor server status, active connections, and metrics from the activity bar. Includes quick actions for server control, URL copying, and autostart toggle

Requirements

VS Code version 1.99.0 or newer
Node.js v22.x or newer
A workspace with debug configurations (in launch.json or workspace.code-workspace)

Getting started

Installation

Install the extension from the VS Code Marketplace or build from source:

git clone https://github.com/R-D-menasheof/mcp-debug-hub.git
cd mcp-debug-hub
npm install
npm run vsix
code --install-extension dist/mcp-debug-hub.vsix

MCP Client configuration

Configure your MCP client according to which one you're using. Each client has a slightly different configuration format.

[!NOTE]
The default port is 37337. You can change this in VS Code settings under mcpDebugHub.ssePort.

MCP Client configuration examples

Cursor

Go to Cursor Settings -> MCP -> Edit Config (or directly edit ~/.cursor/mcp.json):

{
  "mcpServers": {
    "debug-mcp": {
      "url": "http://localhost:37337/mcp"
    }
  }
}

[!TIP] Note that Cursor uses the /mcp endpoint (not /sse) and a simpler configuration format.

Cline

Follow the [Cline MCP documentation](https://docs.cline.bot/mcp/configuring-mcp-servers) and add this configuration:

{
  "mcpServers": {
    "debug-mcp": {
      "command": "node",
      "args": [],
      "transport": {
        "type": "sse",
        "url": "http://localhost:37337/sse"
      }
    }
  }
}

Make sure to configure the SSE transport type correctly.

Continue

Add the configuration to your Continue config file (~/.continue/config.json):

{
  "mcpServers": {
    "debug-mcp": {
      "transport": {
        "type": "sse",
        "url": "http://localhost:37337/sse"
      }
    }
  }
}

Starting the server

The extension can start automatically when VS Code opens (configure mcpDebugHub.autostart in settings), or manually using:

Open the MCP Debug Hub view from the activity bar (layers icon)
Click the Start button or enable the Autostart toggle
Alternatively, use Command Palette: MCP Debug Hub: Start

Your first prompt

Make sure you have debug configurations in your workspace (.vscode/launch.json or workspace.code-workspace)
Enter the following prompt in your MCP Client:

Launch the debug configuration "Python: Current File" and set a breakpoint at line 10 of main.py

Your MCP client should launch the debug session and set the breakpoint.

Tools

Debug session management (7 tools)
Breakpoint management (5 tools)
Execution control (5 tools)
Runtime inspection (5 tools)

Tool reference

launch_debug

Launches a new debug session using a named configuration from workspace settings (launch.json or workspace.code-workspace).

Parameters:

configuration (string, required): Name of the debug configuration from workspace settings (e.g., "Python: Current File", "Node: Launch Program")

Example:

{
  "configuration": "Python: Current File"
}

launch_child_debug

Launches a new debug session as a child of an existing session. Useful for debugging subprocesses, workers, or spawned processes in multi-process applications.

Parameters:

parentSessionId (string, required): ID of the parent debug session
configuration (string, required): Name of the debug configuration from workspace settings
consoleMode (string, optional): Whether to use a separate console or merge with parent (default: "separate"). Options: "separate", "merged"
lifecycleManagedByParent (boolean, optional): Whether lifecycle (restart/stop) is managed by parent (default: false)

Example:

{
  "parentSessionId": "abc123",
  "configuration": "Python: Worker Process",
  "consoleMode": "merged",
  "lifecycleManagedByParent": true
}

stop_debug

Stops a debug session and terminates the debugged program. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID to stop. If not provided, stops the active session

Example:

{
  "sessionId": "worker-123"
}

get_debug_state

Gets detailed information about the currently active debug session including session ID, state, and configuration.

Parameters: None

list_debug_sessions

Lists all active debug sessions with their hierarchy information. Shows parent-child relationships for multi-process debugging scenarios.

Parameters: None

Example output:

{
  "sessions": [
    {
      "id": "main-123",
      "name": "Python: main.py",
      "type": "python",
      "state": "paused",
      "parent": null,
      "children": ["worker-456", "worker-789"]
    }
  ],
  "total": 3
}

get_session_hierarchy

Gets the debug session hierarchy as a tree structure. Useful for visualizing parent-child relationships in multi-process debugging.

Parameters: None

get_session_info

Gets detailed information about a specific debug session by ID. Includes parent, children, state, and session metadata.

Parameters:

sessionId (string, required): ID of the debug session to get info for

Example:

{
  "sessionId": "worker-456"
}

set_breakpoint

Sets a breakpoint at a specific line in a source file with optional conditions, hit counts, or log messages.

Parameters:

file (string, required): Absolute path to the source file (e.g., "/workspace/src/main.py")
line (number, required): Line number where the breakpoint should be set (1-based, first line is 1)
condition (string, optional): Optional condition expression - breakpoint only triggers when this evaluates to true (e.g., "x > 10")
hitCondition (string, optional): Optional hit count condition (e.g., ">5" means break after 5th hit, "==3" means break only on 3rd hit)
logMessage (string, optional): Optional log message to output instead of breaking (logpoint). Use {expression} for variable interpolation.

Example:

{
  "file": "/workspace/src/main.py",
  "line": 42,
  "condition": "x > 10"
}

set_breakpoints

Sets multiple breakpoints at once. Returns success/failure status for each breakpoint individually.

Parameters:

breakpoints (array, required): Array of breakpoints to set (minimum 1, maximum 50 per batch)

Example:

{
  "breakpoints": [
    {
      "file": "/workspace/src/main.py",
      "line": 10
    },
    {
      "file": "/workspace/src/utils.py",
      "line": 25,
      "condition": "count > 5"
    }
  ]
}

remove_breakpoint

Removes a breakpoint from a specific line in a source file.

Parameters:

file (string, required): Absolute path to the source file containing the breakpoint to remove
line (number, required): Line number of the breakpoint to remove (1-based)

list_breakpoints

Lists all breakpoints currently set in the workspace including their locations, conditions, and verification status.

Parameters: None

clear_all_breakpoints

Clears all breakpoints from all files in the workspace.

Parameters: None

continue_execution

Continues program execution until the next breakpoint is hit or the program terminates. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

pause_execution

Pauses the currently running program at its current execution point. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

step_over

Steps over the current line of code, executing it without entering any function calls. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

step_into

Steps into the function call on the current line to debug inside the called function. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

step_out

Steps out of the current function, continuing execution until it returns to the calling function. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

evaluate_expression

Evaluates an expression in the context of a paused debug session and returns its result. Can target a specific session in multi-process debugging.

Parameters:

expression (string, required): Expression to evaluate (e.g., "x + y", "user.name", "len(items)"). Uses the current stack frame context.
frameId (number, optional): Optional stack frame ID from get_stack_frames. If omitted, evaluates in the topmost (current) frame.
sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

Example:

{
  "expression": "user.name",
  "frameId": 0
}

list_threads

Lists all threads in the debug session with their IDs and names. Use this to see which threads are available before calling get_stack_frames with a specific threadId.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

Example output:

{
  "threads": [
    { "id": 1, "name": "MainThread" },
    { "id": 2, "name": "Worker-1" },
    { "id": 3, "name": "Worker-2" }
  ],
  "total": 3
}

get_stack_frames

Gets the current call stack frames including file locations, line numbers, and frame IDs. Can optionally specify which thread to get frames from for multi-threaded debugging.

Parameters:

threadId (number, optional): Optional thread ID. If omitted, returns stack frames from the first thread. Use list_threads to see all thread IDs
sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

Example:

{
  "threadId": 2,
  "sessionId": "worker-123"
}

get_variables

Gets all variables and their values in the current scope including locals, globals, and closure variables. Can target a specific session in multi-process debugging.

Parameters:

frameId (number, optional): Optional stack frame ID from get_stack_frames. If omitted, returns variables from the topmost (current) frame.
sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

get_current_location

Returns the exact file path, line number, and column where execution is currently paused in the debugger. Use this to understand the current execution context before inspecting variables or evaluating expressions. Can target a specific session in multi-process debugging.

Parameters:

sessionId (string, optional): Optional session ID. If not provided, operates on the active debug session

Configuration

The MCP Debug Hub extension supports the following configuration options in VS Code settings:

mcpDebugHub.ssePort Port number for the MCP SSE (Server-Sent Events) server. Used by AI clients like Cursor, Continue, and Cline to connect for debugging.
- Type: number
- Default: 37337
- Range: 1024-65535
mcpDebugHub.sseHost Host address where the MCP SSE server will listen. Use 'localhost' for local connections or '0.0.0.0' to allow remote connections.
- Type: string
- Default: "localhost"
mcpDebugHub.autostart Automatically start the MCP server when VS Code opens. When disabled, use 'MCP Debug Hub: Start Server' command to start manually. This setting can also be toggled directly from the MCP Debug Hub status view.
- Type: boolean
- Default: false
mcpDebugHub.logLevel Logging verbosity level. 'debug' shows all messages, 'error' shows only errors. View logs in the 'MCP Debug Hub' output channel.
- Type: string
- Choices: debug, info, warn, error
- Default: "info"

Changing the port

To use a different port, update your VS Code settings:

{
  "mcpDebugHub.ssePort": 8080
}

Then update your MCP client configuration to use the new port. The exact format depends on your client:

For Cursor:

{
  "mcpServers": {
    "debug-mcp": {
      "url": "http://localhost:8080/mcp"
    }
  }
}

For Cline:

{
  "mcpServers": {
    "debug-mcp": {
      "command": "node",
      "args": [],
      "transport": {
        "type": "sse",
        "url": "http://localhost:8080/sse"
      }
    }
  }
}

For Continue:

{
  "mcpServers": {
    "debug-mcp": {
      "transport": {
        "type": "sse",
        "url": "http://localhost:8080/sse"
      }
    }
  }
}

Concepts

Debug configurations

The extension uses VS Code's debug configurations from your workspace settings. Configurations can be stored in .vscode/launch.json (single-root workspaces) or workspace.code-workspace (multi-root workspaces). You must have at least one debug configuration set up for your project before using the MCP Debug Hub.

Example launch.json:

{
  "version": "0.2.0",
  "configurations": [
    {
      "name": "Python: Current File",
      "type": "python",
      "request": "launch",
      "program": "${file}",
      "console": "integratedTerminal"
    }
  ]
}

Breakpoint verification

When you set a breakpoint, it may be in a "pending" state until the debug session reaches code that can verify it. Verified breakpoints are guaranteed to be hit, while pending breakpoints may need adjustment.

Stack frames

Stack frames represent the call stack at a paused execution point. Frame ID 0 is the current (topmost) frame. Use frame IDs with evaluate_expression and get_variables to inspect different levels of the call stack.

Development

Building from source

git clone https://github.com/R-D-menasheof/mcp-debug-hub.git
cd mcp-debug-hub
npm install
npm run compile

Running in development

Open the project in VS Code
Press F5 to start debugging
A new VS Code window will open with the extension loaded
Configure your MCP client to connect to http://localhost:37337/sse

Running tests

npm test

Known limitations

The extension requires an active VS Code workspace with debug configurations
Some debug adapters may have limited support for certain features (e.g., conditional breakpoints)
The SSE transport requires the MCP client to support Server-Sent Events

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

License

See LICENSE file for details.
