DAG Editor Extension

DAG Editor is a VS Code custom editor for *.dag.json documents used by ETL programs such as Flink jobs.

Features

Create, edit, rename, disable, and delete DAG nodes.
Create and remove edges, or insert a node into an existing edge.
Edit typed node properties.
Create, edit, disable, delete, nest, and reorder UDFs.
Switch between left-to-right and top-to-bottom Dagre layouts.
Report malformed references, duplicate names, and cycles in the Problems panel.
Reject stale writes when the same document changes in another editor.

Edges are represented by the target node's preNodes array. The editor preserves the existing JSON document model:

{
  "nodes": [
    {
      "name": "source",
      "className": "example.Source"
    },
    {
      "name": "sink",
      "className": "example.Sink",
      "preNodes": ["source"]
    }
  ]
}

Usage

Open the command palette and run DAG Editor: New DAG, or open an existing *.dag.json file.

Use the context menu on nodes, edges, and the canvas for graph operations. Double-click a node to open its UDF list, and double-click a UDF to manage nested UDFs.

Mouse and keyboard interactions follow common file-manager behavior:

Click a node or UDF to select it.
Use Ctrl + click (Cmd + click on macOS) to select multiple nodes or UDFs.
Drag UDFs in the UDF list to reorder them.
Hover nodes, edges, and UDFs to emphasize their border or line.
Press Escape to return from the node or UDF editor to its parent view.

Field changes are synchronized in the background without disabling the active input. Press Ctrl+S (Cmd+S on macOS) to flush pending field changes and save the remote document immediately.

DAG document format

DAG Editor keeps the document model as plain JSON. Nodes are stored in a top-level nodes array. Edges are represented by each target node's preNodes array. UDFs can be nested under nodes or other UDFs through the udfs array.

Minimal example:

{
  "nodes": [
    {
      "name": "source",
      "className": "example.Source"
    },
    {
      "name": "transform",
      "className": "example.Transform",
      "preNodes": ["source"],
      "udfs": [
        {
          "name": "normalize",
          "className": "example.udf.Normalize"
        }
      ]
    },
    {
      "name": "sink",
      "className": "example.Sink",
      "preNodes": ["transform"]
    }
  ]
}

Validation

The editor reports semantic problems in the VS Code Problems panel, including:

malformed node references;
duplicate node or UDF names;
self-referencing or cyclic edges.

Development

npm.cmd install
npm.cmd run check

Press F5 in VS Code to compile the extension in watch mode and launch an Extension Development Host.

Available scripts:

npm run compile: create a development bundle with source maps.
npm run watch: rebuild development bundles after source changes.
npm run package: create minified production bundles.
npm run test: run the core unit tests.
npm run test:integration: launch an isolated Extension Host and verify activation, custom editor loading, JSON preservation, and diagnostics.
npm run typecheck: strictly type-check extension and Webview code.
npm run lint: run ESLint with zero warnings allowed.
npm run check: run formatting, type checking, linting, unit tests, and a development build.
