tsvg-preview

Preview SVG inside TypeScript and JavaScript template literals. Mark a template with /*svg*/ before the opening backtick to get a live preview in a side tab—with optional inputs for variables and sensible default values.

Features

• Live SVG preview – Mark any template literal with /*svg*/ (or /* svg */) immediately before the backtick. A Preview SVG code lens and a gutter icon appear on that line. Click either to open the SVG in a side preview tab.
• Variable inputs – If the template uses interpolations like ${width} or ${color}, the preview tab shows a text input for each. Edit values to see the SVG update in real time.
• Smart defaults – Defaults are inferred from how variables are used (e.g. in width, fill, stroke). Numbers get values like 100 or 50; colors get #3366cc; coordinates and radius get sensible defaults.

How to use

1. In a .ts, .tsx, .js, or .jsx file, add /*svg*/ right before the opening backtick of a template literal that contains SVG.
2. Use the Preview SVG code lens above the line or the eye icon in the gutter to open the preview.
3. Or run Preview SVG from the Command Palette (Ctrl+Shift+P / Cmd+Shift+P) with the cursor on a line that has a /*svg*/ template.

Example

// Simple SVG
const icon = /*svg*/ `
  <svg xmlns="http://www.w3.org/2000/svg" width="100" height="100" viewBox="0 0 100 100">
    <circle cx="50" cy="50" r="40" fill="steelblue"/>
  </svg>
`;

// With variables – preview shows inputs with inferred defaults
const badge = /*svg*/ `
  <svg width="${width}" height="${height}" viewBox="0 0 200 100">
    <rect x="10" y="10" width="${boxWidth}" height="80" fill="${color}" stroke="${stroke}" stroke-width="2"/>
  </svg>
`;

Supported languages

TypeScript, JavaScript, TSX, and JSX.

Requirements

• VS Code ^1.105.0

Publishing

Add a .env file in the project root (see .env.example) with:

• ACCESS_TOKEN_VSC – VS Code Marketplace PAT from Azure DevOps (Marketplace → Manage scope).
• ACCESS_TOKEN_OPEN_VSX – Token from Open VSX user settings.

Then:

yarn publish:all      # publish to both marketplaces
yarn publish:vscode   # VS Code Marketplace only
yarn publish:openvsx  # Open VSX only

Release Notes

0.0.1

Initial release:

• Preview SVG from /*svg*/-marked template literals
• Code lens and gutter icon to open preview
• Variable inputs in preview with inferred default values (numbers, colors, coordinates, etc.)
