canopyAI VS Code Extension

AI-powered codebase visualization and editing tool powered by IBM Bob.

Features

• Interactive Visual Graph — See your entire codebase as an interactive SVG graph with pan, zoom, and click-to-select
• AI File Explanations — Bob explains every file in 2 sentences when you click it
• Chat with Bob — Full conversational interface to ask about or modify any file
• Apply Changes — Bob can propose code changes and apply them directly to files
• File Tree Sidebar — Navigate your codebase with a familiar tree view
• Right-Click Context Menu — Explain, chat, view, or rename files from the graph
• Dark Theme — Matches VS Code's dark theme with JetBrains Mono font

Requirements

• IBM Bob CLI must be installed and authenticated on your machine
• Bob must be available in your PATH
• Node.js 18+ (for development)

Installation

From VSIX

1. Download the .vsix file
2. Open VS Code
3. Go to Extensions view (Cmd+Shift+X / Ctrl+Shift+X)
4. Click the "..." menu → "Install from VSIX..."
5. Select the downloaded .vsix file

From Source

# Install extension dependencies
cd extension
npm install
npm run compile

# Install webview dependencies and build
cd ../webview
npm install
npm run build

# Package the extension
cd ../extension
npm run package

This creates a .vsix file you can install in VS Code.

Usage

1. Open a workspace/folder in VS Code
2. Open Command Palette (Cmd+Shift+P / Ctrl+Shift+P)
3. Run command: "canopyAI: Open Panel"
4. The canopyAI panel will open showing your codebase graph
5. Click on files to get AI explanations
6. Switch to "Chat with Bob" tab to have conversations about files
7. Right-click nodes for more options

IBM Bob Setup

canopyAI requires IBM Bob CLI to be installed:

# Install Bob (follow IBM Bob documentation)
# Authenticate Bob
bob auth login

# Verify Bob is working
bob --version

Architecture

canopyai-vscode/
├── extension/          # VS Code extension (TypeScript)
│   ├── src/
│   │   ├── extension.ts          # Main entry point
│   │   ├── webviewProvider.ts    # Manages webview
│   │   ├── fileSystemService.ts  # Reads workspace files
│   │   ├── bobService.ts         # Bob CLI integration
│   │   └── types.ts              # Shared types
│   └── package.json
└── webview/           # React UI (TypeScript + React)
    ├── src/
    │   ├── App.tsx    # Main React app
    │   └── main.tsx   # Entry point
    └── package.json

Development

Watch Mode

Terminal 1 - Extension:

cd extension
npm run watch

Terminal 2 - Webview:

cd webview
npm run dev

Terminal 3 - VS Code:

• Press F5 to launch Extension Development Host
• Run "canopyAI: Open Panel" command

Building

# Build webview
cd webview
npm run build

# Compile extension
cd ../extension
npm run compile

# Package extension
npm run package

Features in Detail

Graph View

• Visual representation of your codebase structure
• Color-coded by file type
• Pan and zoom with mouse
• Click files to get AI explanations
• Modified files highlighted in green

Chat with Bob

• Ask questions about any file
• Request code changes
• Bob provides complete updated file content
• One-click apply changes to files

Context Menu

• Right-click any node in the graph
• Options: Explain, Chat, View Content, Rename

File Operations

• Read files from workspace
• Write changes back to workspace
• Rename files and folders
• Changes immediately reflected in VS Code

Troubleshooting

"Bob CLI not found"

• Ensure Bob is installed and in your PATH
• Run which bob (Mac/Linux) or where bob (Windows)
• Restart VS Code after installing Bob

"No workspace folder open"

• canopyAI requires an open workspace
• Use File → Open Folder to open a project

Webview not loading

• Check VS Code Developer Tools (Help → Toggle Developer Tools)
• Look for errors in the console
• Ensure webview assets were built (cd webview && npm run build)

License

MIT

Credits

Built for the IBM Bob Hackathon by Team PRIMATES.
