git-visualizer README

The git visualizer is a vs code extension that visualizes git graphs to help you learn about git. The visualization style was inspired by the git-learning game Oh My Git, which I highly recommend. This extension makes use of the excellent force-graph library to produce the visualizations.

How to use the tool

1. Install the git-visualizer
2. Open a folder that is a git repo
3. Use cmd + shift + p or ctrl + shift + p to access the command palette.
4. Select the command Git Visualizer: Visualize Git Graph.
5. A visualization of the repo will be displayed in vscode!

Demo Video

This video shows the extension in action.

Learn git with the extension

This playlist teaches basic git commands with the extension.

Example: git graph visualization

Legend

• Circle - Commit
• Square - Reference
  • LB - Local Branch
  • T - Tag
  • RB - Remote Branch
  • S - Stash
  • H - HEAD
  • RH - Remote HEAD

Notes

• This tool is slow on repos with more ~20 commits.
• Right clicking on nodes saves the commit hash / reference name to your clipboard.
• Hovering over nodes reveals the commit message / reference name.
• Nodes can be grabbed and moved with your cursor.

Credits

This extension was developed by Pranav Jain.
