Query Cost Estimator

A VS Code extension that predicts SQL query execution cost before running them. Catch expensive queries at write-time with static analysis.

Features

• CodeLens Integration: See estimated cost above each SQL query
• Real-time Diagnostics: Get warnings for expensive operations
• Detailed Hover Info: View cost breakdown by hovering over queries
• Static Analysis: No database connection required
• Custom Cost Model: Uses Adaptive Query Cost Model (AQCM) algorithm

What It Analyzes

• Table scans and index usage
• JOIN complexity and cardinality
• Subquery and CTE costs
• Window functions
• Aggregations and sorting
• Memory usage estimates
• Execution time predictions

Installation

1. Install the extension from the VS Code Marketplace
2. Open any .sql file
3. (Optional) Configure schema path in settings for accurate estimates

Configuration

{
  "queryCostEstimator.enginePath": "",  // Auto-detected by default
  "queryCostEstimator.schemaPath": "/path/to/schema.json"  // Optional
}

Schema Format

Create a schema.json file with your database statistics:

{
  "tables": [
    {
      "name": "users",
      "row_count": 100000,
      "avg_row_size_bytes": 256,
      "columns": {
        "id": { "name": "id", "cardinality": 100000, "avg_width": 8 }
      },
      "indexes": [
        { "name": "users_pkey", "columns": ["id"], "primary": true, "unique": true }
      ]
    }
  ]
}

Usage

Basic Usage

1. Open any .sql file in VS Code

2. CodeLens appears automatically above each query showing:

   • Total estimated cost
   • Estimated execution time
   • Complexity level (low/medium/high/critical)

3. Hover over a query to see detailed breakdown:

   • Scan cost
   • Join cost
   • Sort cost
   • Filter cost
   • Aggregate cost
   • Memory usage
   • Warnings and suggestions

Advanced Usage

Custom Schema Configuration

For more accurate estimates, provide a schema file:

1. Create a schema.json file with your database statistics (see Schema Format above)
2. Open VS Code Settings (Cmd/Ctrl + ,)
3. Search for "Query Cost Estimator"
4. Set the "Schema Path" to your schema.json file
5. Reload or refresh estimates with the command palette

Working with Complex Queries

The extension analyzes:

• Nested subqueries: Each subquery is analyzed independently
• CTEs (Common Table Expressions): Materialization costs are estimated
• Window functions: Partition and ordering costs included
• Multiple JOINs: Cost compounds based on join order and type
• UNION/INTERSECT/EXCEPT: Set operation costs calculated

Interpreting Results

The cost estimator provides several metrics:

• Total Cost: Overall query complexity score (0-1,000,000+)
• Execution Time: Predicted runtime based on cost model
• Rows Estimated: Expected result set size
• Memory Usage: Approximate memory footprint

Warning Indicators:

• Yellow warning: Medium-high cost query
• Red error: Critical cost query that may cause performance issues

Cost Levels

• Low (< 1000): Simple queries with index usage
• Medium (1000-10000): Moderate complexity, small joins
• High (10000-100000): Large scans or complex joins
• Critical (> 100000): Extremely expensive queries (e.g., cross joins)

Examples

Example 1: Simple Index Lookup

SELECT * FROM users WHERE id = 1;

CodeLens: 💰 Cost: 322 | ⏱️ ~32ms | Complexity: low

Hover Details:

Total Cost: 322.07
Execution Time: ~32ms
Rows Estimated: 10
Memory: 1KB

Breakdown:
- Scan Cost: 122.07
- Filter Cost: 100
- Join Cost: 100

Example 2: Complex JOIN Query

SELECT u.name, o.total, p.product_name
FROM users u
JOIN orders o ON u.id = o.user_id
JOIN order_items oi ON o.id = oi.order_id
JOIN products p ON oi.product_id = p.id
WHERE u.created_at > '2024-01-01'
  AND o.status = 'completed';

CodeLens: 💰 Cost: 45,823 | ⏱️ ~4.5s | Complexity: high

Diagnostics: ⚠️ Warning: High cost query detected - Consider adding indexes on join columns

Example 3: Expensive Aggregation

SELECT
  category,
  COUNT(*) as total,
  AVG(price) as avg_price,
  PERCENTILE_CONT(0.95) WITHIN GROUP (ORDER BY price) as p95_price
FROM products
GROUP BY category
HAVING COUNT(*) > 100;

CodeLens: 💰 Cost: 12,450 | ⏱️ ~1.2s | Complexity: medium

Hover Details:

Total Cost: 12,450
Execution Time: ~1.2s
Rows Estimated: 50
Memory: 256KB

Breakdown:
- Scan Cost: 8,200
- Filter Cost: 1,250
- Aggregate Cost: 2,000
- Sort Cost: 1,000

Warnings:
- Large aggregation without index
- PERCENTILE function is expensive on large datasets

Example 4: Dangerous Cross Join

SELECT * FROM users, orders WHERE users.status = 'active';

CodeLens: 💰 Cost: 1,250,000 | ⏱️ ~125s | Complexity: CRITICAL

Diagnostics: ❌ Error: Cartesian product detected - Missing JOIN condition

Demo in Action

When you open a SQL file, you'll see:

1. CodeLens above each query - Shows cost at a glance
2. Inline diagnostics - Yellow/red squiggles for expensive queries
3. Rich hover tooltips - Detailed cost breakdown and suggestions
4. Problems panel - All warnings/errors listed for quick navigation

Commands

• Query Cost: Refresh Estimates - Manually refresh all cost estimates

Requirements

• VS Code 1.85.0 or higher
• Works offline - no database connection needed

Known Limitations

Estimation Accuracy

• Static analysis only: Estimates are based on query structure, not actual database execution plans
• No runtime stats: Cannot account for database cache state, concurrent queries, or I/O performance
• Cardinality estimation: Without actual table statistics, row count predictions may be inaccurate
• Hardware variability: Actual execution time depends on CPU, memory, disk speed, and database configuration

SQL Feature Support

Current limitations on SQL features:

• Stored procedures: Not analyzed (only raw SQL queries)
• Triggers: Side effects not included in cost
• Database-specific syntax: Optimized for standard SQL, may not recognize vendor extensions
• Dynamic SQL: Cannot analyze queries built at runtime
• Views: Treated as simple selects, materialization cost may be underestimated

Cost Model Assumptions

• Index selectivity: Assumes standard B-tree index structures
• Join algorithms: Uses nested loop cost model (actual DB may use hash/merge join)
• Parallelization: Does not account for parallel query execution
• Buffer pool: Assumes cold start (no warm cache benefit)

Known Issues

• Very large queries (>10KB) may have slower analysis
• Complex recursive CTEs may have estimation errors
• Cross-database queries not supported
• Temporary tables require schema definition for accurate estimates

Best Practices

For most accurate results:

1. Provide a schema.json file with actual table row counts
2. Include index definitions in schema
3. Update schema periodically as data grows
4. Use estimates as relative comparisons, not absolute predictions
5. Validate critical queries with EXPLAIN ANALYZE on actual database

What This Tool Is NOT

• Not a query optimizer: Does not rewrite or suggest alternative queries
• Not a profiler: Does not measure actual execution performance
• Not database-connected: Does not validate query correctness or schema existence
• Not a replacement for testing: Always benchmark critical queries on production-like data

License

MIT

Issues & Feedback

Report issues at: https://github.com/Prakhar998/query-cost/issues
