BFTools — Brainfuck Language Tools for VS Code

Full-featured Brainfuck development environment: syntax highlighting, auto-formatting, lint diagnostics, interactive debugging, JIT execution, test runner, and native AOT compilation.

Features

Installation

From VS Code Marketplace

Search for "Brainfuck" by Ponderance in the Extensions panel, or:

ext install Ponderance.brainfuck-vscode

Build from Source

Requirements: Rust ≥ 1.82, Node ≥ 18, npm

git clone https://github.com/AnmolS1/BFTools
cd BFTools

# Build all Rust binaries
cargo build --workspace --release

# Build the extension
npm install
npm run compile

# Package and install locally
npx vsce package
code --install-extension brainfuck-vscode-*.vsix

Usage

Syntax Highlighting

Open any .bf file — colorization is applied automatically. BF operators (+, -, <, >, ., ,, [, ]) are highlighted as keyword/operator tokens. // line comments and /* */ block comments receive comment styling.

Formatting

Open any .bf file and press Shift+Alt+F, or run Brainfuck: Format Document from the Command Palette. Enable editor.formatOnSave to format automatically on every save.

The formatter applies 7 canonical rules: instruction grouping, inline loops (≤ 80 chars), block loop indentation (tabs), comment placement, and a single trailing newline. Formatting is idempotent. See docs/FORMATTING.md for the complete rule reference.

Linting

Diagnostics appear automatically in the Problems panel as you type.

Running Programs

Open a .bf file and use the Command Palette:

Each command opens a VS Code terminal. Standard input/output is connected to the terminal.

CLI equivalents:

bf-interpreter hello_world.bf
bf-interpreter --jit hello_world.bf
bf-interpreter --auto-jit hello_world.bf
bf-interpreter --no-jit hello_world.bf   # force interpreter even if jit feature built

Note: JIT and auto-JIT require building bf-interpreter with --features jit. The default release binary includes this feature.

Debugging

Press F5 with a .bf file open. VS Code will use the default launch configuration. To customize:

{
  "version": "0.2.0",
  "configurations": [
    {
      "type": "brainfuck",
      "request": "launch",
      "name": "Debug Brainfuck",
      "program": "${file}"
    }
  ]
}

Breakpoints: Click the gutter next to a line number. Breakpoints resolve to the first BF instruction on that line. Lines with only comments are marked unverified.

Stepping:

Variables panel shows two scopes when stopped:

• Current Cell — pointer (tape index) and value (decimal, hex, printable char)
• Memory — cells [0] through [N] where N is the last non-zero cell (minimum 10)

See docs/DEBUGGING.md for testDebug mode (debugging a specific test case failure).

Testing

Create a .bft TOML test file:

[[test]]
name = "Hello World"
program = "hello_world.bf"
expected_output = "Hello World!\n"

[[test]]
name = "Echo A"
program = "cat.bf"
input = "A"
expected_output = "A"

Run Brainfuck: Run Test File from the Command Palette. A file picker opens for *.bft files. Results stream to the Brainfuck Tests output channel:

PASS  Hello World              (hello_world.bf)
FAIL  Echo A                   (cat.bf)
      Expected : A
      Actual   : B
      First diff at byte 0: expected 'A' (0x41), got 'B' (0x42)

When a test fails, click "Debug this failure" to launch a testDebug session that pauses the program at the exact byte where output diverges. See docs/TESTING.md for the full .bft format reference.

CLI usage:

bf-testrunner tests.bft
# exit 0 = all pass, 1 = any fail

Precompiling

Run Brainfuck: Precompile to Executable from the Command Palette. A save dialog opens — choose the output file name. The extension compiles via Cranelift AOT and links with the system C compiler (cc on macOS/Linux, link.exe on Windows).

CLI usage:

bf-precompiler --features aot hello_world.bf -o hello
./hello

Requirements: AOT compilation requires building bf-precompiler with --features aot and a system C compiler in PATH. The default release binary includes this feature.

VS Code Commands

Configuration

All settings are under brainfuck.* in VS Code settings (Ctrl+,):

When a path is empty, the extension looks for the binary in target/debug/ relative to the workspace root — convenient when working from source.

.bft Test Format Quick Reference

[[test]]
name = "Human-readable name"          # required
program = "relative/path.bf"          # required; relative to the .bft file
input = "optional stdin bytes"        # optional; default ""
expected_output = "expected stdout"   # required; trailing \n stripped before compare

TOML string escapes: \n, \t, \\, \", \uXXXX (4-digit hex, e.g. \u0005 for byte 5). The \x escape is not valid in TOML.

Architecture

crates/
  bf-core/         Lexer, parser, AST, validator, .bft test file parser (serde + toml)
  bf-formatter/    7-rule canonical formatter (lib + CLI)
  bf-lsp/          Language server: formatting + diagnostics (tower-lsp, tokio)
  bf-interpreter/  Tree-walking interpreter + Cranelift JIT + adaptive auto-JIT
  bf-precompiler/  Optimizer IR (constant folding, pattern recognition) + Cranelift AOT
  bf-dap/          Debug Adapter Protocol server (DAP over stdio, serde_json)
  bf-testrunner/   .bft test runner (lib + CLI)
src/               VS Code extension (TypeScript, vscode-languageclient)
syntaxes/          TextMate grammar (.tmLanguage.json)
test-fixtures/     Sample .bf and .bft files
docs/              Detailed reference documentation

Documentation

• docs/USER_GUIDE.md — Complete user guide for all extension features
• docs/FORMATTING.md — All 7 formatting rules with examples
• docs/DEBUGGING.md — Debugger setup, stepping, testDebug mode
• docs/TESTING.md — .bft format reference, test runner CLI
• docs/TECHNOLOGY.md — Tools and technologies used

Contributing

1. Fork and clone: git clone https://github.com/AnmolS1/BFTools
2. Build: cargo build --workspace && npm install && npm run compile
3. Test: cargo test --workspace — all 101 tests must pass
4. Submit a pull request against main

License

MIT
