Agent Development Kit Extension

A Visual Studio Code extension for Agent Development Kit projects. Visualize ADK flow directories as interactive graphs, edit flow steps, functions, and transitions with an intuitive visual interface.

Prerequisites

You must have access to a workspace in PolyAI Agent Studio before using this extension. Access is provided by your PolyAI contact. To request access to the PolyAI platform, reach out to platform-support@poly-ai.com.

Installation

From Marketplace (Recommended)

1. Open VS Code or Cursor
2. Go to the Extensions view (Ctrl+Shift+X / Cmd+Shift+X)
3. Search for "Agent Development Kit"
4. Click Install

Or install from the command line:

# VS Code
code --install-extension PolyAI.adk-extension

# Cursor
cursor --install-extension PolyAI.adk-extension

Manual Installation (VSIX)

Download the latest adk-extension-*.vsix file from the GitHub Releases page.

VS Code:

1. Go to the Extensions view (Ctrl+Shift+X / Cmd+Shift+X)
2. Click the ... menu and select "Install from VSIX..."
3. Select the downloaded .vsix file
4. Reload the editor when prompted

Cursor:

1. Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P)
2. Type "Install from VSIX" and select Extensions: Install from VSIX...
3. Select the downloaded .vsix file
4. Reload the editor when prompted

Command line:

# VS Code
code --install-extension adk-extension-*.vsix

# Cursor
cursor --install-extension adk-extension-*.vsix

Features

Interactive Flow Visualization

• Graph-based visualization - View your flow as an interactive graph with nodes representing steps, functions, and endpoints
• Visual navigation - Click nodes to view details, drag to reposition, and zoom/pan to explore large flows
• Connection mapping - See how steps connect through functions and transitions

In-Place Editing

• Edit prompts - Double-click any step's prompt to edit it directly in the viewer
• ASR Biasing configuration - Configure Automatic Speech Recognition biasing settings
• DTMF configuration - Set up Dual-Tone Multi-Frequency settings including timeouts, max digits, and end keys
• Function integration - Add function references ({{fn:functionName}} or {{ft:functionName}}) using the function picker

Change Management

• Modified nodes sidebar - Track all nodes with unsaved changes in a collapsible sidebar
• Save All / Discard All - Bulk operations to save or discard all changes at once
• Visual indicators - Modified nodes are highlighted and tracked in the sidebar

Python Language Features

• Go to Definition - Click on conv.functions.functionName or flow.functions.functionName to jump to the function definition
• Find All References - Find all places where a function is called across your workspace
• Hover Information - See function descriptions, parameters, and file paths in tooltips

ADK Linter

• Real-time diagnostics - Get instant feedback on coding standards as you type
• Python rules - Validates function structure, decorators, imports, and common anti-patterns
• YAML rules - Checks flow configs, steps, and topics for required fields and best practices
• Configurable - Disable specific rules per-project using a .adkrc config file
• CI/CD CLI - Run adk-lint from the command line to enforce standards in your build pipeline

See Linter Documentation for full rule reference and CLI usage.

Usage

Opening a Flow

ADK: View Flow    # From command palette (Ctrl+Shift+P / Cmd+Shift+P)

Or right-click on a flow directory in the Explorer and select "View Flow".

Creating a Flow

ADK: Create New Flow    # From command palette (Ctrl+Shift+P / Cmd+Shift+P)

Or right-click on a folder in the Explorer (e.g. your flows directory) and select "ADK: Create New Flow". Enter a name for the flow; the extension creates a new flow directory with flow_config.yaml and an initial step, then opens the flow viewer.

Commands

Keyboard Shortcuts

Project Structure

The extension expects the following directory structure for ADK projects:

flow-directory/
├── flow_config.yaml      # Flow configuration
├── steps/                # Step definitions
│   ├── step1.yaml
│   ├── step2.yaml
│   └── ...
└── functions/            # Flow-specific functions (optional)
    ├── function1.py
    └── ...

Development Setup

Prerequisites

• Node.js 16 or higher
• Yarn package manager
• VS Code or Cursor

Getting Started

git clone https://github.com/polyai/adk-extension.git
cd adk-extension
yarn install
yarn compile

Press F5 in VS Code to launch the Extension Development Host for testing.

Project Structure

src/
├── extension.ts              # Main extension entry point
├── cli.ts                    # CLI entry point for adk-lint
├── flowParser.ts             # Flow parsing logic
├── flowViewer.html           # Webview UI
├── pythonFunctionResolver.ts # Python function resolution
├── pythonLanguageFeatures.ts # Language feature providers
├── linter/                   # Linter implementation
│   ├── index.ts
│   ├── config.ts
│   └── rules/
├── utils/                    # Utility functions
└── webview/                  # Webview handlers

Bugs & Feature Requests

Please report bugs or request features via the GitHub Issues page.

Contributing

Contributions are welcome! Please follow these guidelines:

1. Fork and clone the repository
2. Install dependencies: yarn install
3. Create a branch for your feature or fix
4. Test thoroughly in the Extension Development Host (F5)

Commit Convention

This project uses Conventional Commits for automatic versioning with semantic-release.

PR Title Format: <type>(<optional scope>): <description>

Examples:

• feat: add entity management → Minor release (1.0.0 → 1.1.0)
• fix: resolve flow parsing error → Patch release (1.0.0 → 1.0.1)
• feat!: redesign step editor API → Major release (1.0.0 → 2.0.0)

Release Process

When commits are pushed to main, semantic-release automatically:

1. Analyzes commit messages to determine the release type
2. Updates the version in package.json
3. Generates/updates CHANGELOG.md
4. Creates a GitHub release with the VSIX file
5. Publishes the extension to the VS Code Marketplace

License

This project is licensed under the Apache License 2.0. See the LICENSE file for details.
