A5:ER Tools for VS Code

A powerful Visual Studio Code extension for working with A5:ER (Entity Relationship) database design files. This extension provides preview capabilities and seamless conversion between A5:ER format and JSON format, making it easier to work with AI/LLM tools for database design assistance.

Features

🔍 A5:ER File Preview

  • Visual preview of A5:ER files directly in VS Code
  • Entity-Relationship diagram visualization
  • Table structure display with fields, types, and constraints
  • Real-time preview updates as you edit

🔄 Format Conversion

  • A5:ER to JSON: Convert A5:ER files to structured JSON format for easy processing by AI/LLM tools
  • JSON to A5:ER: Convert JSON back to A5:ER format to maintain compatibility with A5:SQL tools
  • Preserves all metadata including:
    • Entity names (logical and physical)
    • Field definitions with data types
    • Primary key and foreign key relationships
    • Default values and comments
    • Entity positioning information
    • Relationship mappings

🤖 AI/LLM Integration Ready

The JSON format is specifically designed to be easily readable and processable by Large Language Models, enabling:

  • Database schema analysis
  • Automated documentation generation
  • Schema optimization suggestions
  • Code generation from database design

Installation

From VS Code Marketplace

  1. Open VS Code
  2. Go to Extensions (Ctrl+Shift+X)
  3. Search for "pengent-a5er-tools"
  4. Click Install

From VSIX File

  1. Download the .vsix file from releases
  2. Open VS Code
  3. Press Ctrl+Shift+P to open Command Palette
  4. Type "Extensions: Install from VSIX..."
  5. Select the downloaded .vsix file

Usage

Preview A5:ER Files

  1. Open any .a5er file in VS Code
  2. Right-click in the editor and select "Preview A5er File"
    • Or press Ctrl+Shift+P and type "Preview A5er File"
  3. A preview panel will open showing the entity-relationship diagram

Convert A5:ER to JSON

  1. Open a .a5er file in VS Code
  2. Right-click and select "Convert A5:ER to A5ER.JSON"
    • Or use Command Palette: Ctrl+Shift+P → "Convert A5:ER to A5ER.JSON"
  3. A new .a5er.json file will be created and opened alongside your original file

Convert JSON back to A5:ER

  1. Open a .a5er.json file in VS Code
  2. Right-click and select "Convert A5ER.JSON to A5:ER"
    • Or use Command Palette: Ctrl+Shift+P → "Convert A5ER.JSON to A5:ER"
  3. A new .a5er file will be generated

JSON Format Structure

The converted JSON follows this structure:

{
  "project": {
    "name": "Project Name",
    "author": "Author Name",
    "rdbms": "Database Type"
  },
  "entities": [
    {
      "name": "table_name",
      "logical_name": "テーブル名",
      "fields": [
        {
          "name": "field_name",
          "logical_name": "フィールド名",
          "type": "VARCHAR(50)",
          "not_null": true,
          "pk": false,
          "default": "default_value",
          "comment": "Field description"
        }
      ],
      "position": {
        "page": "Main",
        "left": 100,
        "top": 200
      }
    }
  ],
  "relations": [
    {
      "from": "parent_table",
      "to": "child_table",
      "from_field": "id",
      "to_field": "parent_id",
      "type": "1:N"
    }
  ]
}

Supported A5:ER Features

✅ Fully Supported:

  • Entity definitions (logical and physical names)
  • Field definitions with all data types
  • Primary key constraints
  • Foreign key relationships
  • Default values
  • Field comments
  • Entity positioning
  • Project metadata

⚠️ Partially Supported:

  • Complex relationship types (converted to standard 1:N, N:1 format)
  • Advanced A5:ER formatting options

Use Cases

Database Documentation

Convert your A5:ER files to JSON and use AI tools to generate comprehensive documentation:

# Example workflow
1. Convert schema.a5er → schema.a5er.json
2. Process with AI/LLM for documentation
3. Generate markdown/HTML documentation

Schema Analysis

Use the JSON format for automated analysis:

  • Identify naming convention violations
  • Find missing foreign key relationships
  • Detect potential performance issues
  • Generate test data schemas

Code Generation

Convert database designs to application code:

  • Generate ORM models
  • Create API endpoints
  • Build database migration scripts
  • Generate CRUD operations

Requirements

  • Visual Studio Code 1.101.0 or higher
  • A5:ER files created with A5:SQL Mk-2 or compatible tools

Extension Settings

This extension contributes the following settings:

Currently no configurable settings. Settings will be added in future versions based on user feedback.

Known Issues

  • Large A5:ER files (>1000 entities) may experience slower preview rendering
  • Complex nested relationships might not display perfectly in preview mode
  • Unicode characters in Japanese field names display correctly in JSON but may have encoding issues in some environments

Release Notes

0.0.1

  • Initial release
  • A5:ER file preview functionality
  • Bidirectional A5:ER ↔ JSON conversion
  • Context menu integration
  • Command palette support

Contributing

We welcome contributions! Please see our Contributing Guidelines for details.

Development Setup

  1. Clone the repository
  2. Run npm install to install dependencies
  3. Press F5 to open a new Extension Development Host window
  4. Test your changes

License

This project is licensed under the MIT License - see the LICENSE file for details.

Support

  • 🐛 Bug Reports: GitHub Issues
  • 💡 Feature Requests: GitHub Discussions
  • 📧 Email: support@your-domain.com

Acknowledgments

  • A5:SQL Mk-2 by m.matsubara for the original A5:ER format specification
  • VS Code team for the excellent extension API
  • The open-source community for inspiration and feedback

Made with ❤️ for database designers and developers
