PRUVALEX PruvaGraph

Turn your codebase into a knowledge graph. Save 70–82% on LLM tokens. Keep code private.

PruvaGraph builds a compact knowledge graph of your codebase and exposes it to AI agents (Claude Code, Cursor, VS Code Copilot) via the Model Context Protocol (MCP). Instead of feeding entire files to the LLM, agents query the graph — answering the same questions with 70–82% fewer tokens and zero code leaving your machine.

Quick Start

1 — Install the VS Code Extension

From VSIX (v1.9.0):

code --install-extension pruvalex-pruvagraph-1.9.0.vsix

Or search "PRUVALEX PruvaGraph" in the VS Code Extensions marketplace.

2 — Build a Graph

Open any Python project in VS Code, then open a terminal:

pip install pruvalex-pruvagraph   # or: pip install -e ./python
pruvagraph .                      # builds graph.json in pruvagraph-out/

3 — Wire to Your AI Agent

pruvagraph install --vscode        # writes .vscode/mcp.json (VS Code / Copilot)
pruvagraph install --claude        # writes CLAUDE.md + .mcp.json (Claude Code)
pruvagraph install --cursor        # writes .cursor/mcp.json

Reload your IDE. Your agent now has 23 MCP tools to query the graph.

Benchmark — Real Numbers

These numbers come from the reproducible benchmark harness (pruvagraph benchmark-suite). No hardcoded values. Run it yourself: pruvagraph benchmark-suite --root .

Both runs use --backend none (no LLM API calls billed). Savings come from graph traversal, deterministic routing, and exact-match caching — not from approximation.

Known limitation — banner numbers are point-in-time snapshots. The 70.5%–81.5% figures shown in the CLI banner (LOGO in cli.py:60) and in this README tagline are hardcoded strings from the v1.9.0 benchmark run. They follow the same pattern as the stale 31.6% bug fixed in v1.9.0 (see CHANGELOG §Fixed — 31.6% Stale Hardcoded Savings Claim). After any future benchmark rerun that produces meaningfully different numbers, these two locations must be updated manually:

1. python/pruvagraph/cli.py — the LOGO constant (line ~60) and the UnicodeEncodeError fallback echo string (line ~129)
2. README.md — the tagline and the Benchmark table header Run pruvagraph benchmark-suite --root . to get fresh numbers.

Reproduce on your repo:

pruvagraph benchmark-suite --root /path/to/your/project
# → pruvagraph-out/benchmark_results.jsonl

Features

Core: Knowledge Graph Engine

• Parses Python codebases with Tree-sitter (no LSP, no internet)
• Builds a directed graph: modules → functions → imports → calls
• 23 MCP tools for graph queries (dependencies, callers, summaries, communities)
• Incremental updates: pruvagraph . --update (only changed files)
• Graph export: JSON, GEXF, GraphML, interactive HTML

5 Integrated Modules (toggleable)

Toggle any module off in VS Code Settings → pruvagraph.modules.* → the MCP server automatically removes its tools from the client's tool list on next startup.

Analytics Dashboard (VS Code)

Open with Ctrl+Shift+P → PruvaGraph: Open Analytics Dashboard:

Configuration

Add to your settings.json (or configure via VS Code Settings UI):

{
  "pruvagraph.modules.driftguard.enabled": true,
  "pruvagraph.modules.contextlens.enabled": true,
  "pruvagraph.modules.taskweaver.enabled": true,
  "pruvagraph.modules.budgetgovernor.enabled": true,
  "pruvagraph.modules.rulesforge.enabled": true
}

When a module is toggled off, the extension automatically rewrites .vscode/mcp.json with PRUVAGRAPH_DISABLED_MODULES=<list>. The next MCP server startup hides those tools from the agent — no silent no-ops.

MCP Tools Reference

Exactly 23 tools — confirmed from mcp_server.py TOOLS list.

Core — Graph Queries (always active):
  query_graph          Natural-language codebase Q&A
  get_dependencies     Direct import/call deps for a module
  find_callers         Who calls a given function?
  get_summary          Module-level docstring summary
  list_communities     Semantic clusters in the graph
  list_packages        All top-level packages in the graph
  cost_report          Token savings from the last build
  analyze_impact       Blast radius of changing a symbol
  get_graph_diff       What changed since last build? (nodes/edges)

DriftGuard — Import Validation:
  validate_import      Does this import actually exist in the graph?
  scan_suggestion      Pre-validate a code suggestion before applying

GhostMemory — Context Persistence:
  remember             Store a fact/snippet in the context store
  recall               Retrieve stored facts by key

ContextLens — Context Tracking:
  get_active_context   What's been injected into agent context?
  measure_token_usage  Token count of current context window
  trace_last_tool_calls Recent tool call trace

TaskWeaver — Agent Checkpoints:
  create_checkpoint    Save agent progress with git SHA
  get_task_progress    Checkpoint DAG for a task
  rollback_to_checkpoint Revert to a previous checkpoint state
  list_checkpoints     All checkpoints for a task

BudgetGovernor — Token Budget:
  check_budget         Current session token spend vs cap

RulesForge — Coding Rules:
  get_applicable_rules Coding rules for the open file (AST-detected layer)
  learn_from_accept    Record an accepted suggestion as a learned rule

Test Coverage

Project Structure

├── extension.js              # Lean entry point (~130 lines, imports from src/)
├── src/
│   ├── utils.js              # Logging, nonce, escapeHtml, workspace helpers
│   ├── cli-runner.js         # spawnCLI, runCLI, cost report, status bar
│   ├── commands.js           # All 15 command handlers
│   ├── driftguard.js         # On-save Python import validation (Diagnostics)
│   ├── sidebar-provider.js   # WebviewViewProvider for sidebar panel
│   ├── sidebar-html.js       # Full sidebar HTML/CSS/JS template
│   ├── dashboard.js          # 4-tab Analytics dashboard (WebviewPanel)
│   └── telemetry.js          # Opt-in local telemetry (see Telemetry section)
├── build.js                  # esbuild bundler (npm run build → dist/extension.js 70KB)
├── dist/
│   └── extension.js          # Production bundle (minified, 70KB)
├── jsconfig.json             # TypeScript-lite: @ts-check + JSDoc type checking
├── package.json              # Extension manifest (19 commands, 6 settings)
├── python/
│   ├── pruvagraph/
│   │   ├── mcp_server.py     # 23-tool MCP server (stdio transport)
│   │   ├── cli.py            # CLI entry point (pruvagraph .)
│   │   ├── installer.py      # MCP config writer (.vscode/mcp.json etc.)
│   │   ├── benchmark_harness.py  # Truth Machine — 84 questions
│   │   ├── driftguard.py     # Import/type validation
│   │   ├── context_lens.py   # Context tracking
│   │   ├── task_weaver.py    # Checkpoint DAG
│   │   ├── budget_governor.py # Token budget
│   │   └── rules_forge.py   # Coding rules
│   └── tests/                # 460 Python tests
├── tests/
│   ├── extension/
│   │   └── commands.test.js  # 10 Extension Host integration tests (T1–T10)
│   ├── test_extension_driftguard.js   # 8 JS unit tests
│   └── test_dashboard_html.js         # 30 dashboard HTML tests
└── scripts/                  # Dev utilities (patch scripts, etc.)

Privacy

• No code sent externally when using --backend none (default)
• Graph JSON stays in pruvagraph-out/ on your machine
• LLM backends (gemini, claude, etc.) only receive docstrings/summaries you explicitly extract with --backend <name>
• MCP server runs as a local subprocess — no network ports opened

Telemetry

PruvaGraph collects minimal, opt-in, local-only telemetry:

• No user data, file paths, code content, or arguments are ever recorded.
• Telemetry respects VS Code's global telemetry.telemetryLevel setting — set it to "off" to disable completely.
• All counters stay in your local VS Code storage. Zero network calls. Zero external endpoints.
• You can inspect all stored counters via the getTelemetrySummary() API in src/telemetry.js.

License

MIT — © 2026 PRUVALEX Systems
