Application Performance Monitoring service Plugin for Visual Studio Code

Use the OCI Application Performance Monitoring plugin to manage APM Availability Monitoring scripts, monitors under APM domains within VS Code.

Checkout the wiki for more information about the APM service.

Installation

The plugin requires basic configuration information, like user credentials and tenancy OCID. This information should be present in a configuration file located at ~/.oci/config

There are two ways to get the config file

1. Manually generate a file and save in ~/.oci folder:

   Details on the generating the configuration file can be found here : https://docs.oracle.com/en-us/iaas/Content/API/Concepts/apisigningkey.htm#apisigningkey_topic_How_to_Generate_an_API_Signing_Key_Console

2. Auto generate file using Sign In Button:

   On successfull login, a config file will be generated and saved in ~/.oci folder



Inital View

The Application Performance Monitoring plugin when loaded has a tree view in the side panel, the data is loaded based on the configuration information, like user credentials, region, tenancy OCID, etc in the configuration file

Hierarchy of tree view: the tree view has tenancy at the top level followed by compartments, each compartment has APM domains associated with the compartment. Each APM domain lists the Availability monitors, scripts.

Create Script

The plugin provides the ability to create new Availability scripts. Scripts can be created in below 3 ways:

Create Script from APM plugin

• Expand APM Domains, select required domain

• Right click on the Scripts option and click on Create



• Choose script type between Selenium SIDE script or Playwright typescript



• Add script name, and select script file. Refer https://docs.oracle.com/en-us/iaas/application-performance-monitoring/doc/create-script.html for script inputs.

Create Script from right click menu in File Explorer

• In the file browser on the left side, right click on the script file for which you want to create Script resource and click on Create APM Availability Script.

• Verify the APM Domain displayed at the top for which Script resource would be created. In case when no APM Domain is selected then you need to select an APM domain from the tree view of APM extension

• Choose script type between Selenium SIDE script or Playwright typescript



• Add script name, and select script file. Refer https://docs.oracle.com/en-us/iaas/application-performance-monitoring/doc/create-script.html for script inputs.

Create Script from right click menu in Editor

• In the file browser on the left side, right click on the script file for which you want to create Script resource and click on Create APM Availability Script.

• Verify the APM Domain displayed at the top for which Script resource would be created. In case when no APM Domain is selected then you need to select an APM domain from the tree view of APM extension

• Choose script type between Selenium SIDE script or Playwright typescript



• Add script name, and select script file. Refer https://docs.oracle.com/en-us/iaas/application-performance-monitoring/doc/create-script.html for script inputs.

View Script Details

• Right click on script to view its details and click on Get details



View Script in Browser

• Right click on script to be viewed in browser and click on View in browser...

Download Script

• Right click on script to be downloaded and click on Download script



Edit Script

• Right click on script to be edited, either update values in file editor or upload updated script and click on Edit

Copy Script OCID

• Right click on script and click on Copy OCID

Delete Script

The plugin provides an option to delete Availability scripts. Below are the steps:

• Right click on script to be deleted and click on Delete



• Select 'yes' from the prompt



List Vantage Points

• Expand APM Domains, select required domain

• Right click on the Monitors option and click on List vantage points

• Copy name param of the vantage point which will be used in create monitor command.



Create Availability Monitors

The plugin provides the abililty to create new Availability monitors. Prerequisite: Script is already created (to create script refer Create Script section) and list of Vantage Points are available (to get list of vantage points refer List Vantage Points section). Below are the steps:

• Expand APM Domains, select required domain

• Right click on the Monitors option and click on Create



• Upload existing JSON file or use template to create.

• Click on

  • Create to create monitor.
  • Save as JSON button to save input values as JSON file and use this file later to create monitor(s)

View Monitor Details

• Right click on monitor to view its details and click on Get Details



View Availability Monitor in Browser

• Right click on monitor to be viewed in browser and click on View in browser...



Edit Availability Monitor

• Right click on monitor to be edited and update values.
• Click on
  • Edit to edit monitor.
  • Save as JSON button to save input values as JSON file and use this file later to create monitor(s)

Run Now Monitor

• Right click on monitor for run now execution and click on Run Now



Copy Monitor OCID

• Right click on monitor and click on Copy OCID

View Monitor Execution Results

• Right click on monitor, expand Execution results, select Get execution results



View Error Message

• Right click on monitor, expand Execution results, select View error message

View HAR, Screenshots

• Right click on monitor, expand Execution results, select View execution HAR or View execution screenshots.
• It will prompt for timestamp, enter its value (get this value from the output of Get execution results command), then select vantage point for which you want to view the result.
• To download the results, Download button can be clicked.
• Select location to download file, this will download the file on the local system.

Download Logs

• Right click on monitor, expand Execution results, select Download execution logs.
• It will prompt for timestamp, enter its value (get this value from the output of Get execution results command), then select vantage point for which you want to download the result.
• Select location to download file, this will download the file on the local system.

Delete Availability Monitor

The plugin provides an option to delete Availability monitor. Below are the steps:

• Right click on monitor to be deleted and click on Delete



• Select 'yes' from the prompt



Contributing

This project welcomes contributions from the community. Before submitting a pull request, please review our contribution guide.

License

Copyright (c) 2025, Oracle and/or its affiliates. All rights reserved. This software is licensed to you under the Universal Permissive License (UPL) 1.0 as shown at https://oss.oracle.com/licenses/upl.

See LICENSE for more details.
