OpenSwiftUI Preview for VS Code

Find #Preview and PreviewProvider declarations in the current Swift file and run a selected view in a native macOS window or iOS Simulator app. VS Code manages the build and session. The linked OpenSwiftUI runtime handles input, gestures, state changes, and redraws in the external window.

Requirements

• Local macOS with Xcode 26.6 / Swift 6.3 and the required Simulator runtime.
• VS Code 1.88 or later and the Swift extension (swiftlang.swift-vscode).
• A trusted workspace with an Xcode application target or Swift package library target that depends on OpenSwiftUI.

Install and run

1. Run Extensions: Install from VSIX and select the packaged extension. To create a VSIX from source, see development instructions.
2. Run Developer: Reload Window after installation or an update.
3. Open the project or package folder and a Swift file with #Preview or PreviewProvider. Generated Xcode projects, such as Tuist projects, must already have a project or workspace. A Swift package needs its manifest.
4. Open Preview in the left Activity Bar and select a row under Current File, or click Run Preview above a declaration.
5. Choose the owning target if more than one target contains the file, then select This Mac or an iOS Simulator.

Automatic mode does not require a preview target, host source files, or JSON configuration. It saves the selected file before building. Edits made during save, including format-on-save changes, can require selection again.

Both declaration styles can appear in the same file:

#Preview("Macro Preview") {
    ContentView()
}

struct ContentView_Previews: PreviewProvider {
    static var previews: some View {
        ContentView()
            .previewDisplayName("Legacy Preview")
    }
}

The sidebar uses explicit names first, then the root View type name. Before a build, the list uses source information. After a build, each provider expands into its runtime previews, including names computed by Swift code. Each child can be selected and rebuilt separately. If no usable View type can be determined, the label falls back to the source location. The list refreshes when the active file or its contents change.

How it works

The extension scans the editor buffer and resolves the owning target. For an Xcode app, it prepares a derived project in extension storage and retains the target's source paths, dependencies, resource phases, and package resource bundles. For a Swift library package, it creates an application host that references the original local package and its dependency graph. It does not add a target to the package manifest or copy the package's dependency graph.

Automatic mode first builds with the project's original #Preview macro and reads its compiler expansion. A SwiftSyntax helper adapts the generated registry into a cached source overlay for a second native host build. It does not replace the project's macro with a custom declaration. Access stays in the original module, including internal and private view types. Unsupported expansion shapes and preview traits fail with a diagnostic. Original source and project files stay unchanged.

A compiled registry supplies the previews that actually exist in the selected build. The extension matches the source selection to that registry, then starts a separate native host. The source list can include inactive #if declarations; these cannot run unless the selected build compiles them.

Resources come from the target's build graph. The extension does not infer which assets a closure uses. The normal application entry point is bypassed; preview code must supply any models, services, or environment values that app startup would normally provide. See architecture and maintenance guidance for implementation details.

Commands and session behavior

One preview session runs at a time. A failed build leaves the previous preview running. After a successful build, the old host stops before compiled discovery; a later discovery or launch failure does not restore it. Stop does not shut down a shared Simulator.

Rebuild starts a new process and resets state. It retains the selected source-location ID, so moving a declaration or adding lines above it can require Run Preview to select it again. Rebuild does not inject changed code into a running process. If the configuration pins previewID, update or remove that value before selecting again.

Optional dedicated host configuration

Use this path for a manually maintained preview host. Explicit configuration takes priority over automatic target resolution and describes the build target, not a catalog of source declarations. This compatibility path uses the bundled standalone macro shim; automatic mode uses the project's original macro.

Add the four native host templates and the view sources to a dedicated macOS/iOS app target that links OpenSwiftUI. This target must not include another @main app. See host integration for build settings and protocol details.

Create .vscode/openswiftui-previews.json in the project folder:

{
  "version": 1,
  "previews": [
    {
      "id": "custom-host",
      "name": "Custom Preview Host",
      "project": "MyApp.xcodeproj",
      "scheme": "MyPreviewHost",
      "target": "MyPreviewHost",
      "configuration": "Debug",
      "platforms": ["macos", "ios-simulator"]
    }
  ]
}

• Use either project or workspace. Paths are relative to the folder that contains the configuration. ${workspaceFolder} expands to that folder.
• id identifies the build profile and must be unique in that folder. name is its display label. Neither field limits the source preview list.
• Omit previewID to choose a declaration. To pin one, use its exact compiled ID: fileID:line:column for a macro, with :provider:<childID> appended for a provider child. An explicit source selection takes priority over this default.
• arguments and environment apply to the host process. Variables beginning with OPENSWIFTUI_PREVIEW_ and --openswiftui-list-previews are reserved.
• buildArguments accepts Xcode build settings such as CODE_SIGNING_ALLOWED=NO, not shell commands or destination/output overrides. developerDirectory selects a specific Xcode Contents/Developer directory.

Open a provider's Swift file before running it: provider registration covers the selected file. Without an active Swift file, Run uses the configured target and its compiled declaration picker.

Try the examples

Both examples contain the same globe image, Hello, world! text, and unnamed #Preview { ContentView() }. Select ContentView in Preview > Current File, then choose the destination. Neither example has preview host sources, a custom macro declaration, or preview JSON.

The first dependency resolution can download the pinned 0.24.3 package and its frameworks. See the example guide for recorded verification and the native acceptance checklist. These minimal views do not test gestures.

Limits and troubleshooting

• Automatic mode supports Xcode application targets and Swift package library targets with a linkable library product. Xcode library, test, and Swift package executable targets need additional host support.
• Automatic iOS Simulator previews reject apps with embedded extensions such as Widgets. Use a dedicated host without embedded extensions for these projects.
• Preview traits, generic declaration scopes, and automatic preview files with explicit #sourceLocation directives are unsupported. Provider device, layout, and orientation settings are not applied; the host has a fixed initial window size.
• Apple SwiftUI, visionOS, Linux native rendering, and remote hosts are not implemented in this extension.
• Gesture, keyboard, and focus behavior depends on the linked OpenSwiftUI runtime. A visible window or a ready signal does not prove interaction works. Complete macOS and iOS Simulator gesture acceptance remains pending.
• If an update still reports no macro named 'Preview', run Developer: Reload Window. Check Show Preview Log for the active extension version and the first compiler error.

Development commands, source responsibilities, test scopes, and maintenance constraints are in AGENTS.md.
