Force Cockpit

A VSCode extension that provides a Salesforce utilities cockpit. It connects to Salesforce orgs via the SF CLI and offers operational tools for monitoring and general utilities — all from within VSCode. Contact: Pablo Fernández Posadas @paferpo

Installation

From the VS Code Marketplace

Open the Extensions panel (Ctrl+Shift+X / Cmd+Shift+X).
Search for Force Cockpit.
Click Install.

From a `.vsix` file

Download the latest .vsix file from the releases.
In VSCode, open the Extensions panel.
Click the ... menu → Install from VSIX... and select the file.

Alternatively, install from the terminal:

code --install-extension force-cockpit-<version>.vsix

Prerequisites

Salesforce CLI (sf) must be installed and on your PATH.
You must be authenticated to at least one Salesforce org (sf org login web).

Getting Started

Open a workspace that contains an SFDX project (or any folder).
Use the Salesforce extension to set your default org (SFDX: Set a Default Org command, or click the org name in the status bar).
Force Cockpit auto-connects to the target-org set in .sf/config.json at startup — and reconnects automatically whenever you switch orgs via the Salesforce extension.
Open the cockpit panel via the Command Palette: Force Cockpit: Open Cockpit.

If you switch orgs while an operation is in progress, a confirmation dialog appears. Confirming cancels any running operations and connects to the new org.

If the panel doesn't pick up an org change automatically (e.g. the file watcher missed an event, or the SF CLI hasn't finished writing the new credentials), click the 🔄 button next to the connection status in the panel header to force a fresh re-read of .sf/config.json and a reconnect. The same 🔄 Refresh action also appears inside the "No org connected" card.

Tabs

Tab	Description
Overview	Org info card, storage usage bars, SOQL Quick Query editor (tabs, history, autocomplete, Tooling toggle) with a filterable, sortable results table
Utils	Built-in utilities (Clone User, Reactivate OmniScript) and custom YAML scripts
Monitoring	SOQL-powered Chart.js dashboards loaded from YAML config files

Overview Tab

The Overview tab shows org connection details and storage usage bars (Data Storage and File Storage), and provides a SOQL Quick Query editor (run with Run Query or Cmd/Ctrl+Enter).

The editor supports:

Query tabs — keep several queries open at once. Use + to add a tab, double-click a tab to rename it, and × to close it. New tabs start pre-filled with SELECT Id FROM (cursor ready for the object name). Tab names and queries are saved per workspace and restored when you reopen the panel (results are not persisted).
History — every query you run is recorded under History ▾ → Recent (newest first, deduped). Click ★ Save to store the current query under a name (History ▾ → Saved); pick any entry to load it into the active tab.
SOQL autocomplete — as you type, suggestions appear for sObjects (after FROM), fields and relationships (in SELECT / WHERE / ORDER BY / GROUP BY, including dotted traversal like Account.Owner.Name), and picklist values inside WHERE … = '…'. Press Ctrl/Cmd+Space to force suggestions; ↑/↓ to move, Enter/Tab to insert, Esc to dismiss.
Tooling API — tick Tooling API to run the query against the Tooling API (e.g. ApexClass, Flow).

The results table supports:

Filter — type in the filter box above the table to narrow rows by a case-insensitive match across all columns; a counter shows how many of the total rows match.
Sort — click any column header to sort; click again to reverse.
Copy column as IN-list — click the ⧉ button on a column header to copy that column's values (deduped, as 'a', 'b', 'c') to the clipboard, ready to paste into another query's IN (…) clause. Respects the current filter.
Open records — any Salesforce record Id in a cell renders as a link that opens the record in your browser.
Record counts — SELECT COUNT() FROM … queries show the count instead of "0 records".
Export — Export CSV / Export JSON writes the current (filtered and sorted) view to a timestamped query-result-… file in your workspace root and opens it in the editor.

Utils Tab — YAML Scripts

Scripts can also be created and edited directly in the UI — no need to write YAML by hand.

[!TIP] The code field in the new/edit form is a simple textarea. For comfortable editing — syntax highlighting, multi-cursor, find & replace — click ✎ Open in editor to edit the code body in a real VS Code editor tab. Saving there (Ctrl/Cmd+S) syncs the code straight back into the form (the form stays open); nothing is written to disk and your other fields are untouched. Click the form's Save to persist the whole script.

[!TIP] Need a near-duplicate of a script? Open it for editing and click Clone — the form is pre-filled with every field of the original and _copy is added to the name. Tweak whatever you need and click Save to create the copy. Nothing is written until you Save, so the original stays untouched if you cancel.

[!TIP] Prefer hand-editing the raw YAML? When editing an existing script, click 📄 Open YAML to open its underlying .yaml file in a VS Code editor tab. The edit form closes (you've switched to raw editing, so there's no risk of a stale form Save overwriting your changes), and the script list refreshes automatically when you save the file. (The button only appears when editing an existing script.)

The Scripts sub-tab executes scripts defined in YAML files. Four script types are supported (Apex, Command, JavaScript, and AI — see AI scripts). Scripts live under force-cockpit/scripts/{category}/*.yaml (shared) or force-cockpit/private/scripts/{category}/*.yaml (private, git-ignored). Sub-categories are also supported: {category}/{sub-category}/*.yaml gives a second row of pills for drilling down.

[!TIP] Repository examples: Ready-to-use YAML script examples are available under force-cockpit/scripts/examples/.

# Apex script — requires org connection
name: My Apex Script
description: What this script does.
apex: |
  System.debug('Hello from Apex');

# Terminal command — no org connection required
name: My Command
description: Runs a local shell command.
command: npm run build

# JavaScript script — runs in Node.js VM sandbox, org connection is optional
name: My JS Script
description: Query Salesforce with jsforce.
js: |
  const result = await query("SELECT Id, Name FROM Account LIMIT 5");
  log(JSON.stringify(result.records, null, 2));

Exactly one of apex:, command:, js:, or ai: is required. Click Execute on any script card to run it.

Configurable Inputs

Scripts can declare input variables that are prompted at execution time. Add an inputs: section to your YAML:

name: Update Order Status
description: Updates an order and its line items.
inputs:
  - name: orderId
    label: Order ID
    required: true
  - name: status
    label: Status
    type: picklist
    required: true
    options:
      - New
      - Submitted
      - Completed
      - Cancelled
      - In Progress
apex: |
  Id orderId = '${orderId}';
  // ... use orderId and status in your Apex code

Each input supports: | Field | Required | Description | |-------|----------|-------------| | name | Yes | Variable identifier (alphanumeric + underscore) — used as ${name} in the script body | | label | No | Display label (defaults to name) | | type | No | string (text input, default) or picklist (dropdown) | | required | No | If true, Execute is disabled until the field is filled | | options | Picklist only | List of selectable values |

Write ${variableName} in your script code where you want the value substituted. Escaping is handled automatically (Apex-safe for apex, JSON-safe for js, raw for command).

System Placeholders

In addition to user-defined inputs, scripts can use built-in system placeholders that are automatically resolved from the connected org:

Placeholder	Description
`${orgUsername}`	Salesforce username (not alias) of the connected org

System placeholders use the same ${name} syntax and type-appropriate escaping as user inputs. If no org is connected, they resolve to an empty string. If a user-defined input has the same name as a system placeholder, the user input takes precedence.

name: Show My User
apex: |
  System.debug('Running as: ${orgUsername}');

Type	Badge	Org required	Output
Apex	Blue	Yes	Debug log (USER_DEBUG filter available)
Command	Purple	No	stdout/stderr
JavaScript	Green	No	`log()` / `console.log()` output
AI	Orange	Yes	Streamed model analysis

JS script context: connection (jsforce Connection or null), org (OrgDetails or null), query(soql), log(), error(), console, fs, path, yaml.

AI scripts

An AI script optionally gathers Salesforce data with a fixed, author-defined step and then uses a language model (via VS Code's built-in Language Model API, powered by GitHub Copilot) to analyse it. The analysis streams into the script's output. The gather step is optional — omit it (uncheck "Gather data first" in the form) for a script driven purely by its prompt + inputs.

Requirements: GitHub Copilot must be enabled in VS Code (the first run shows a one-time consent prompt), and an org must be connected.

name: Energy account analysis
description: Summarises energy-industry accounts.
model: auto                         # the chosen model's id — the form requires one and defaults to Copilot's "Auto"
inputs:
  - name: industry
    label: Industry
    required: true
gather:                             # OPTIONAL fixed data step — exactly one of soql / apex / apex-file (omit for a prompt-only script)
  soql: SELECT Id, Name, AnnualRevenue FROM Account WHERE Industry = '${industry}'
ai: |                               # the analysis prompt (use ai-file: to load it from a file)
  Summarise the accounts below and flag anything unusual about their revenue.
allow-followup-queries: true        # optional — lets the model run follow-up SOQL for extra context
allow-read-workspace-files: true    # optional — lets the model search & read workspace files (any non-gitignored source/metadata)
skills:                             # optional — ids of skills the model may read on demand
  - data-quality-checklist

How it works and why it's safe:

You control the data step. The gather SOQL/Apex is yours and runs exactly as written — the model never writes or chooses Apex, so there is no risk of it modifying data.
The model only analyses. It receives the gathered data + your prompt and replies with text.
Optional follow-up queries. With allow-followup-queries: true, the model may run additional SOQL queries (SELECT only) to pull more context. It can never run anything that writes.
Optional workspace file access. With allow-read-workspace-files: true, the model can search workspace files by name (a case-insensitive regular expression — a plain word like Selector matches OrderSelector, AccountSelector) and read any matching source/metadata file (Apex, objects, fields, flows, LWC, permission sets…). Handy for diagnosing stack traces across your metadata. Anything excluded by your .gitignore (e.g. force-cockpit/private/) is never listed or read.
Model picker. Picking a model is required (the field is marked with a red *). The list is populated from the models Copilot offers — de-duplicated and sorted alphabetically — and defaults to Copilot's "Auto" model when it's available. If a script's saved model is no longer available at run time, Force Cockpit falls back to Auto (or the first available model), prepends a warning to the output, and shows a notification — so the run still completes. Note: some models don't support follow-up queries — gather + analyse still works regardless.
Skills (reusable playbooks). Tick Skills in the form to attach Agent Skills — markdown guides stored as {skill-id}/SKILL.md under .claude/skills or .github/skills in your workspace. The model sees a short catalogue (id + description) of the attached skills and can pull a skill's full content on demand via a tool; nothing is auto-injected. Override the scanned folders with skillsPaths in force-cockpit/config.yaml.
Schema is cached locally. Before querying, the model checks object fields via a describe_object tool. Results are cached per workspace under force-cockpit/.describe-cache/ (git-ignored, 2-week expiry) and shared with the Overview Quick Query autocomplete, so repeated lookups don't hit the org. Click the 🔄 refresh button next to the connection status to clear the cache and re-pull the latest schema.
Open as markdown. AI analysis is written in Markdown. Once a run finishes, an Open as markdown button (next to Open in editor / Copy to clipboard) opens the output in VSCode's built-in Markdown preview — headings, lists, tables, and code blocks rendered nicely. Nothing is written to disk; it opens an in-memory untitled document. The gathered data is shown as a code block in the preview.

${input} and ${orgUsername} placeholders work in both the prompt and the gather step.

Private scripts

Check Private when creating or editing a script to save it to force-cockpit/private/scripts/ instead of the shared folder. The extension automatically adds force-cockpit/private/ to .gitignore on startup. Private scripts show a 🔒 badge and can be filtered with the All / Shared / Private control. You cannot save a private script with the same category + name as an existing shared one.

Monitoring Tab

The Monitoring tab displays live charts built from SOQL queries. Each chart is defined by a YAML configuration file. Charts are rendered using Chart.js and can be refreshed manually or on a timer.

Where charts come from

Charts are loaded from two sources (merged at runtime, later wins):

Source	Path	Purpose
User-defined	`{workspace}/force-cockpit/monitoring/{category}/*.yaml`	Your own charts, committed to git
Private	`{workspace}/force-cockpit/private/monitoring/{category}/*.yaml`	Personal charts, not committed to git

The user-defined path can be customised via the VSCode setting forceCockpit.cockpitPath (see Configuration).

Private charts

Checking Private in the chart edit form saves the config to force-cockpit/private/monitoring/ instead of the shared folder. The extension automatically adds force-cockpit/private/ to .gitignore on startup so these files are never committed.

Private charts show a 🔒 badge on their card. Use the All / Shared / Private filter above the category pills to show only the configs you care about.

You cannot save a private chart with the same category + name as an existing shared one (and vice versa) — the extension will show an error.

Sub-categories

Monitoring configs support two levels of nesting: {category}/{sub-category}/*.yaml. Clicking a parent category pill reveals a second row of narrower sub-pills to drill down.

Adding a new monitoring chart

Pick or create a category folder under force-cockpit/monitoring/ in your workspace:

{workspace}/
└── force-cockpit/
    └── monitoring/
        └── orders/          ← any name you like
            └── my-chart.yaml

Create the YAML file using the schema below.
Reload the Monitoring tab — your chart appears automatically. No rebuild or restart needed.

Deleting a chart

Click Edit on the card → click the red Delete button in the form → confirm in the modal. User and private charts are removed from disk. Built-in (bundled) charts cannot be deleted from disk, so they are hidden in your workspace instead — a "Restore hidden built-ins (N)" link appears in the top toolbar so you can bring them back.

YAML schema

name: Open Orders by Status          # Display name shown on the card
description: Count of open orders grouped by status.  # Subtitle shown on the card

soql: |
  SELECT Status, COUNT(Id) RecordCount
  FROM Order
  WHERE Status != 'Cancelled'
  GROUP BY Status

labelField: Status        # API name of the field used as chart labels (X-axis or pie slices)

valueFields:              # One or more datasets to plot
  - field: RecordCount    # API name of the numeric field
    label: Orders         # Legend label for this dataset
    format: number        # optional: number | currency | percent

chartType: bar            # bar | line | pie | doughnut | metric | table
stacked: false            # true = stacked bars/lines (bar and line only)
notifyOnIncrease: false   # true = fire a notification when totalRows grows between two refreshes
refreshInterval: 0        # Auto-refresh in seconds. 0 = manual refresh only

Field reference

Field	Required	Values	Description
`name`	Yes	string	Card title
`description`	No	string	Card subtitle
`soql`	Yes	SOQL string	Any valid SOQL query
`labelField`	Yes*	API name	Field whose values become chart labels or the first table column. *Not required for `metric` type.
`valueFields`	Yes	array	At least one `{ field, label }` entry
`valueFields[].field`	Yes	API name	Field to plot or display
`valueFields[].label`	Yes	string	Dataset legend label or column header
`valueFields[].format`	No	`currency` \| `percent`	Number formatting on axes, tooltips, and table cells
`chartType`	No	`bar` \| `line` \| `pie` \| `doughnut` \| `metric` \| `table`	Default chart type (user can override for chart types)
`stacked`	No	`true` \| `false`	Stack bars or lines (bar and line only)
`notifyOnIncrease`	No	`true` \| `false`	Fire a VSCode warning whenever the row count grows between two auto-refreshes (e.g. new error records appearing). Snoozable for 1 hour or for the day.
`refreshInterval`	No	integer (seconds)	`0` disables auto-refresh

Background notifications: Charts with thresholds or notifyOnIncrease: true keep auto-refreshing in the background even when the Force Cockpit panel is closed, so threshold breaches and row-count growth alerts still fire. Row-count growth also plays a short OS audio cue (best-effort, uses the system audio command for your platform). Charts without these flags only refresh while the panel is open. Disconnect from the org and the background polling stops.

Multiple datasets (grouped charts)

You can plot multiple fields from the same query side by side:

name: Order Amounts by Status
soql: |
  SELECT Status, SUM(TotalAmount) Total, COUNT(Id) Count
  FROM Order
  GROUP BY Status
labelField: Status
valueFields:
  - field: Total
    label: Total Amount (€)
    format: currency
  - field: Count
    label: Number of Orders
chartType: bar
refreshInterval: 60

Stacked bars

Add stacked: true to a bar or line chart with multiple valueFields to render them as stacked segments:

name: Revenue by Category
soql: SELECT Name, Hardware__c, Software__c, Services__c FROM Account__c
labelField: Name
valueFields:
  - field: Hardware__c
    label: Hardware
    format: currency
  - field: Software__c
    label: Software
    format: currency
  - field: Services__c
    label: Services
    format: currency
chartType: bar
stacked: true

Metric cards (KPI)

Use chartType: metric to display a single large number. labelField is not required. The first value of the first valueField is shown as the headline number:

name: Open Orders
description: Total orders waiting to be processed.
soql: SELECT COUNT(Id) Cnt FROM Order WHERE Status = 'Open'
valueFields:
  - field: Cnt
    label: Open Orders
chartType: metric
refreshInterval: 30

Table view

Use chartType: table to render a scrollable, sortable table. Works with any SOQL — aggregate or not. Click any column header to sort. Use format: currency or format: percent on valueFields to format numeric columns.

Each table card has a search box above the table that filters its rows in real time by any field (case-insensitive substring match across every column). A small counter next to the input shows X of Y so you can see how aggressive your filter is. The filter text persists across auto-refresh of the same card.

Any cell whose value is an 18-character Salesforce record Id (validated via the standard Salesforce case-safe checksum) is rendered as a clickable link that opens the record in your browser — no extra configuration needed. This works for Id, OwnerId, AccountId, and any other lookup or aliased Id column. 15-character Ids pasted into custom text fields are not auto-linked, since they have no checksum to verify and would risk false positives on plain text values.

name: Recent Orders
description: Last 20 orders by creation date.
soql: |-
  SELECT OrderNumber, Status, TotalAmount
  FROM Order
  ORDER BY CreatedDate DESC
  LIMIT 20
labelField: OrderNumber
valueFields:
  - field: Status
    label: Status
  - field: TotalAmount
    label: Amount (€)
    format: currency
chartType: table

Examples

[!TIP] Repository examples: There are example charts in this repository under force-cockpit/monitoring/examples/.

Editing and saving charts in the UI

Each card has an Edit button that opens an inline form. Changes to the SOQL field trigger an auto-preview after 800 ms. Check Private to save to the private folder; leave unchecked to save to the shared workspace path. Clicking Save writes the YAML — it never overwrites bundled extension charts.

Configuration

Most extension settings are managed via a config.yaml file — making them easy to share across a team by committing the file to git.

The extension loads configuration in this order (later layers override earlier ones):

Hardcoded defaults — built into the extension
Bundled config.yaml — shipped with the extension at its root
User config.yaml — at force-cockpit/config.yaml in your workspace (or the custom cockpitPath)

Only keys present in a layer override the previous layer — omitted keys keep their default values.

Available settings

Key	Type	Default	Description
`apiVersion`	string	`"66.0"`	Salesforce API version for all API calls
`protectedSandboxes`	string[]	`[]`	Sandbox org names that require confirmation before destructive actions
`skillsPaths`	string[]	`[".claude/skills", ".github/skills"]`	Workspace-relative folders scanned for Agent Skills attachable to AI scripts

Example `force-cockpit/config.yaml`

apiVersion: "66.0"
protectedSandboxes:
  - staging
  - uat
skillsPaths:
  - .claude/skills
  - .github/skills

VSCode setting

One setting remains in VSCode's settings.json because it determines where the config file lives:

Setting	Default	Description
`forceCockpit.cockpitPath`	`""`	Absolute path to the `force-cockpit` folder. Defaults to `{workspace root}/force-cockpit` if empty.

Note: Changes to config.yaml are picked up automatically — no window reload needed.

Releases

New versions are published automatically via GitHub Actions.

To create a release:

Go to the Actions tab in the GitHub repository.
Select Release → Run workflow.
Choose the version bump type (patch, minor, or major) or enter an explicit version string.
Click Run workflow.

The workflow will:

Bump the version in package.json
Update CHANGELOG.md with the version and date
Push a version commit and git tag to main
Build and package the .vsix
Create a GitHub Release with the .vsix attached
Publish the extension to the VS Code Marketplace

The .vsix for every release is available on the GitHub Releases page.

Development

npm install
npm run build       # Build extension (copy assets + esbuild bundle)
npm run watch       # Build in watch mode
npm run compile     # TypeScript type-check only
npm run package     # Build + create .vsix
npm run audit:prod  # Check production dependencies for known vulnerabilities

Security

Dependency auditing: Every PR runs npm audit against production dependencies in CI. Dependabot opens weekly PRs when vulnerable packages have updates available.
.npmrc hardening: audit-level=high, engine-strict=true, and save-exact=true ensure safe and reproducible installs.

Force Cockpit

Noriabits

Force Cockpit

Installation

From the VS Code Marketplace

From a .vsix file

Prerequisites

Getting Started

Tabs

Overview Tab

Utils Tab — YAML Scripts

Configurable Inputs

System Placeholders

AI scripts

Private scripts

Monitoring Tab

Where charts come from

Private charts

Sub-categories

Adding a new monitoring chart

Deleting a chart

YAML schema

Field reference

Multiple datasets (grouped charts)

Stacked bars

Metric cards (KPI)

Table view

Examples

Editing and saving charts in the UI

Configuration

Available settings

Example force-cockpit/config.yaml

VSCode setting

Releases

Development

Security

From a `.vsix` file

Example `force-cockpit/config.yaml`
