CCL Language Support for VS Code

A comprehensive VS Code extension providing syntax highlighting, IntelliSense, and code formatting for CCL (Cerner Command Language).

Features

🎨 Syntax Highlighting

• Full CCL syntax highlighting with TextMate grammar
• Support for keywords, functions, data types, operators, and comments
• Proper color coding for different language elements

🧠 IntelliSense

• Auto-completion for CCL keywords, functions, and data types
• Context-aware suggestions based on cursor position
• Function signatures with parameter hints
• Hover documentation for functions and keywords

✨ Code Formatting

• Automatic code formatting with configurable options
• Indentation management for control structures
• Keyword case conversion (upper/lower/preserve)
• Configurable indentation size

⚙️ Configuration

• Enable/disable formatting and IntelliSense
• Customizable indentation size
• Keyword case preferences
• Language-specific settings

Installation

1. Install the extension from the VS Code marketplace
2. Open a .ccl or .prg file
3. The extension will automatically activate

Usage

File Associations

The extension automatically associates with:

• .ccl files
• .prg files

Commands

• CCL: Format CCL Document - Format the entire document
• Right-click context menu: "Format Document" when editing CCL files

Configuration Options

Add these settings to your VS Code settings.json:

{
  "ccl.format.enable": true,
  "ccl.format.indentSize": 2,
  "ccl.format.keywordCase": "upper",
  "ccl.intellisense.enable": true
}

Configuration Details

• ccl.format.enable (boolean, default: true)

  • Enable or disable CCL code formatting

• ccl.format.indentSize (number, default: 2)

  • Number of spaces to use for indentation

• ccl.format.keywordCase (string, default: "upper")

  • Case for SQL keywords: "upper", "lower", or "preserve"

• ccl.intellisense.enable (boolean, default: true)

  • Enable or disable IntelliSense for CCL

Supported CCL Features

Keywords

• Control flow: IF, ELSE, WHILE, FOR, CASE, BEGIN, END
• SQL operations: SELECT, INSERT, UPDATE, DELETE, FROM, WHERE
• Joins: JOIN, LEFT JOIN, RIGHT JOIN, INNER JOIN, OUTER JOIN
• Functions: COUNT, SUM, AVG, MIN, MAX, CAST, CONVERT

Data Types

• Numeric: INT, BIGINT, DECIMAL, FLOAT, REAL
• String: CHAR, VARCHAR, TEXT
• Date/Time: DATE, TIME, DATETIME, TIMESTAMP
• Other: BOOLEAN, BIT, BINARY, XML, JSON

Functions

• Date/Time: GETDATE, CURRENT_TIMESTAMP, YEAR, MONTH, DAY
• String: SUBSTRING, LEN, UPPER, LOWER, REPLACE
• Mathematical: ROUND, CEILING, FLOOR, ABS, POWER
• Aggregate: COUNT, SUM, AVG, MIN, MAX

Development

Building the Extension

1. Clone the repository
2. Install dependencies:

   npm install


3. Compile TypeScript:

   npm run compile


4. Package the extension:

   vsce package


Project Structure

├── src/
│   ├── extension.ts          # Main extension entry point
│   ├── completionProvider.ts # IntelliSense provider
│   ├── hoverProvider.ts      # Hover documentation provider
│   └── formatter.ts          # Code formatting provider
├── syntaxes/
│   └── ccl.tmLanguage.json   # TextMate grammar for syntax highlighting
├── language-configuration.json # Language configuration
├── package.json              # Extension manifest
└── tsconfig.json            # TypeScript configuration

Contributing

1. Fork the repository
2. Create a feature branch
3. Make your changes
4. Add tests if applicable
5. Submit a pull request

License

This extension is licensed under the MIT License.

Support

For issues, feature requests, or questions:

• Open an issue on GitHub
• Check the documentation
• Review the configuration options

Changelog

Version 1.0.0

• Initial release

• Syntax highlighting for CCL

• IntelliSense with auto-completion

• Code formatting with configurable options

• Hover documentation for functions and keywords

• Language configuration for CCL files

• Developed By - Noah William Lim, a Developer at LHSC
