Fantom Language Support

Rich language support for Fantom in Visual Studio Code, powered by a full Language Server Protocol implementation.

Features

Code Intelligence

• Hover -- type signatures, documentation, and constructor details for types and slots from your code and compiled pods.
• Go to Definition -- compiler-backed bindings distinguish same-named types and slots, typed/inferred receivers, inheritance, chained calls, closures, and it-blocks. Cross-pod calls open workspace source; installed pods open source when available.
• Go to Declaration -- jump to the declaration of a type or slot.
• Find References -- find occurrences bound to the same symbol, not every matching name. Locals and parameters stay within their declaring scope.
• Rename Symbol -- precise workspace edits for proven bindings; unsafe, external, ambiguous, or incomplete targets are refused with an explanation.
• Call Hierarchy -- browse incoming and outgoing calls for any method or constructor.
• Type Hierarchy -- browse supertypes and subtypes for classes and mixins.

Editing

• Completion -- context-aware autocomplete: pod names in using statements, dot-completion on receivers, keywords, method locals, and types (including nested types). Method snippets include parameter placeholders. Missing usings can be added via auto-import on accept. Resolve fills documentation.
• Signature Help -- parameter hints while typing function calls, with the active parameter highlighted.
• Code Actions -- quick fixes including Add missing using, Remove unused using, Organize usings, and Uncomment line.
• On-type indent -- indent when you type }.
• Document links -- using statements link to source when src is available.

Navigation

• Document Symbols -- outline and breadcrumb navigation for the current file.
• Workspace Symbol Search -- Ctrl+T fuzzy search across all indexed symbols.
• Document Highlights -- highlight other occurrences of the symbol under the cursor.
• Folding Ranges -- fold types, methods, and comment blocks.
• Selection Range -- expand/shrink selection by AST nesting.
• Linked Editing -- edit same-symbol occurrences together in the current file, excluding unrelated matching names.
• Code Lens -- lazy, precise reference counts on methods, constructors, and fields. Click a nonzero count to open the references peek; N+ references means coverage is incomplete.
• Inlay Hints -- inferred types for local variables.

Diagnostics

• Real-time parser errors on every keystroke.
• Compiler diagnostics on open/save, with automatic cross-file refresh (including configured test/ source directories). Background semantic warm-up follows workspace indexing.
• Unused local warnings in addition to unused usings.

Formatting

• Full-file and range formatting with Allman (default) or K&R bracket style.
• Correctly handles triple-quoted multiline strings and list literal indentation.
• Respects your editor tab size and spaces/tabs preference.

Syntax Highlighting

• Semantic token support that goes beyond the bundled TextMate grammar, distinguishing classes, methods, fields, enums, and mixins with modifiers like declaration, readonly, static, and abstract. Full document and range tokens.
• VS Code configurationDefaults enable editor semantic highlighting for Fantom.

Server control

• Status bar restart -- restart the language server from the status bar without reloading the window.

Getting Started

Prerequisites

• Java 11+ on your PATH.
• Fantom or SkySpark installed locally.

Setup

1. Install the extension from the Marketplace.
2. Open Settings (Ctrl+,) and set fantom.home to your Fantom or SkySpark installation directory (e.g. C:\Skyspark\skyspark-4.0.5). If you already have the FAN_HOME environment variable set, you can skip this step.
3. Open a .fan file. The language server starts automatically.

Settings

Running without VS Code

Build the server from the server directory with fan build.fan. Run it over standard input/output with fan fantomLsp::Main. The process speaks JSON-RPC using the LSP stdio transport. This is useful for protocol-level testing and other LSP clients.

Troubleshooting

The extension does not start

1. Verify fantom.home points to a valid installation containing lib/java/sys.jar.
2. Confirm Java is available: run java -version in a terminal.
3. Check the Fantom LSP Launch output channel (View > Output, then select Fantom LSP Launch) for the exact command that was attempted.

No completions or hover information

• Wait a few seconds after opening a .fan file for workspace indexing to finish.
• For large projects, increase memory: set fantom.javaOpts to "-Xmx2048m" or higher.
• Check the Fantom Language Server output channel for errors.
• Build/install dependency pods before expecting exact cross-pod resolution. Use fantom.envPath for additional roots containing their lib/fan builds.
• Workspace/configured lookup roots are separate from the JVM runtime path: current workspace .pod files are read by the compiler namespace, not loaded into the JVM. Rebuilt dependencies are picked up on subsequent lookup/compile without a server restart or workspace-pod JVM file locks. fantom.home / FAN_HOME locate the installed runtime; the extension's server and installed runtime remain on the runtime path (D6).

Diagnostics are missing or stale

• Compiler diagnostics refresh on save. Parser diagnostics update on every keystroke.

Formatting produces unexpected results

• Check that fantom.formatting.bracketStyle matches your preference.
• The formatter uses your editor's Tab Size and Insert Spaces settings.

High memory usage or crashes

• Increase the heap: set fantom.javaOpts to "-Xmx2048m".
• Enable fantom.trace.server at "verbose" to capture logs, then file an issue.

Known Limitations

• Fallback resolution uses the recovering parser for dynamic -> calls, unparseable files, unknown receivers, and regions edited since the last compile. Results are a deterministic ranked peek list or nothing, never an arbitrary first match. Unchanged lines can still use the last compiler bindings; compilation is not performed on every keystroke.
• Unbuilt dependencies can prevent compiler name resolution. Build/install them on the workspace lookup path; fallback navigation and reference coverage may be incomplete until then.
• Rename requires a proven workspace binding and complete semantic coverage (refreshing stale pods with a bounded wait). Locals/parameters remain scope-bounded. Virtual, abstract, override, and mixin slot families are conservatively refused: exact-key edits do not safely maintain dispatch families. Constructor shorthand is not a supported slot rename token.
• Slot rename is deliberately conservative: any workspace subtype of the declaring type blocks it, even for a nonvirtual slot and a subtype unrelated to a mixin. The subtype audit requires current coverage of the entire workspace: an unrelated pod with a stale/unresolved/missing snapshot, duplicate pod names, or a source-file hash mismatch can block all slot renames. prepareRename never compiles. Rename's reference refresh is bounded and does not guarantee whole-workspace hierarchy coverage; with fantom.semanticIndex.backgroundCompile=false, unrelated unopened pods may remain unavailable despite reference refresh. Open/save those pods or re-enable warm-up, then retry. Local rename does not require this global subtype audit.
• Installed source may be absent. Definition then returns nothing, while hover can still show the installed signature/documentation.
• Compiler type-token coverage varies with compiler APIs; type positions without source locations (such as some local/generic type annotations) use the scope-aware fallback. Completion and semantic tokens continue to use the recovering-parser indexes.
• Inlay hints cover inferred locals, not fields.
• Request cancel ($/cancelRequest) is best-effort (tracked ids only).
• Compiler diagnostics are computed asynchronously after open/save. Indexing walks folders that contain build.fan (works with a large multi-repo workspace).

License

Free to use. Source code is proprietary. See the LICENSE file included with the extension for details.
