ADO Pipeline Manager

VS Code extension for managing Azure DevOps pipelines directly from the editor. Monitor runs, approve deployments, inspect Terraform plans, diagnose failures, and trigger pipelines — all without leaving VS Code.

PAT Permissions

Create a Personal Access Token with these minimum permissions:

The User Profile scope is automatically available with any valid PAT and is used to resolve the authenticated user identity.

Setup and Usage

See README-features.md for setup instructions, screenshots, and usage walkthroughs.

Features

Pipeline Runs

• Recent Runs tree view — see your pipeline runs with status, branch, result, and duration at a glance
• Run details — expand a run to see its timeline stages, jobs, tasks, and pending approvals
• Trigger & cancel runs directly from the UI
• Retry runs while preserving the original run's queue-time variables
• Favorite pipelines — starred pipelines display a bright green star icon and sort to the top
• Pipeline filtering — filter pipelines by name or folder
• Status bar — current run status always visible; shows a spinner during failure diagnosis and a bell icon for pending approvals
• Failure diagnosis — automatically detect failed runs and generate an AI-powered fix guide

Approvals

• Pending approvals view — the Recent Runs icon changes to a bell when a run is waiting for approval
• Approval notifications — notifications are shown for both environment-based approvals (/_apis/pipelines/approvals) and timeline checkpoints such as ManualValidation tasks
• Open in Browser — jump straight to the approval page in Azure DevOps to approve or reject

Terraform Plan Review

• AI-generated summary — Copilot reads the full raw terraform plan output and produces a concise bullet-point summary
• Risk highlighting — destructive changes, replacements, IAM/security modifications flagged with ⚠️
• Resource group cards — parsed resource-action groupings (Resources to Create / Update / Replace / Destroy)
• Per-resource details — counts, stats, and grouped resource change cards with explanations
• Raw Plan Output — full line-numbered, color-coded plan text at the bottom of the webview
• Large plan handling — plans over ~8000 chars are truncated before sending to Copilot; a note is shown in the UI

Custom Prompt

The built-in default prompt lives at src/defaultPrompt/terraform-summary-prompt.md. You can override it with your own markdown file:

"adoPipelineManager.terraformSummaryPromptPath": "${workspaceFolder}/terraform-prompt.md"

Example terraform-prompt.md:

You are a Terraform plan reviewer. A full terraform plan output is provided below.

Summarize in bullet points, in German. Focus only on:
- Destructive changes (replacements, destroys)
- Security group / IAM changes
- Any resources being deleted

Keep it under 4 bullet points.

If the setting is empty or the file doesn't exist, the built-in default prompt is used.

Failure Diagnosis

• Automatic detection — when a Recent Run transitions to failed, the extension fetches the timeline, extracts error snippets from failed task logs, and calls GitHub Copilot for a fix guide
• HTML fix guide — opens in a webview with color-coded sections: Failures found, Root cause, Fix, and How to verify
• Manual trigger — right-click any completed failed run and choose ADO: Diagnose Failure
• Deduplication — each failed run is diagnosed once per VS Code session; select Ignore in the notification to prevent repeated prompts
• Smart log excerpts — error windows plus the tail of each failed task log are sent to Copilot, capped by failureDiagnosisMaxLogChars

Custom Prompt

The built-in default prompt lives at src/defaultPrompt/failure-diagnosis-prompt.md. You can override it with your own markdown file:

"adoPipelineManager.failureDiagnosisPromptPath": "${workspaceFolder}/failure-diagnosis-prompt.md"

If the setting is empty or the file doesn't exist, the built-in default prompt is used.

Logs & Artifacts

• View logs — fetch task logs for a run or individual timeline task and display them in the ADO Pipeline Manager output channel
• Download artifacts — download all artifacts for a run as ZIP files to a folder of your choice

Configuration

Commands
