XLSX, CSV, TSV & Markdown Editor - VS Code Extension

This open-source extension lets you view and edit XLSX, CSV, TSV, and GitHub Flavored Markdown files directly in VS Code. XLSX, CSV, and TSV now share one unified spreadsheet editor, one webview, and one editing pipeline, so selection, virtualization, sorting, filtering, conversion, settings, and save behavior stay consistent across tabular formats.

Overview

The extension turns VS Code into a practical spreadsheet and Markdown workspace. You can inspect large datasets, edit tabular files, format spreadsheet content, convert between CSV/TSV/XLSX, and author Markdown with a synchronized preview without leaving the editor.

Notice: This extension has evolved from separate XLSX, CSV, and TSV editors into a unified spreadsheet webview backed by a single custom editor provider.

Key Features

Full-Featured Spreadsheet Editor (XLSX, CSV, TSV)

• Unified spreadsheet webview: XLSX, CSV, and TSV are handled by one shared grid implementation.
• Google Sheets-style editing: Rich text formatting, text/background colors, strikethrough, alignment, borders, font size, font family, wrapping, clear formatting, and format painter in styled mode.
• CSV/TSV styled mode: CSV and TSV can use temporary local style persistence for formatting that delimited files cannot store directly.
• Advanced cell controls: Checkboxes, dropdowns, ratings, dates, and images are supported in the spreadsheet grid where the underlying format supports them.
• Find, sort, and filter: Built-in find plus column header sorting and filters for contains, equals, starts-with, non-empty, and case-sensitive matching.
• Cross-format conversion: Convert files between CSV, TSV, and XLSX from the editor toolbar.
• Version history and rollback: Recent states are archived so you can preview and restore prior file versions.
• Autosave and persistence: Configurable autosave for text, controls, formatting, and structure changes.
• Large file virtualization: Windowed rendering keeps CSV, TSV, and XLSX responsive on large datasets.
• Excel-like selection and navigation: Multi-cell selection, row/column selection, resizing, auto-fit, and keyboard navigation.
• Plain view mode: Hide styling for a simpler data-first view.

Advanced Markdown Viewer & Editor

• Split view with sync scroll: Edit Markdown on one side and preview it on the other.
• Preview edit mode: Edit Markdown directly from the rendered preview with a rich formatting toolbar.
• GitHub-Flavored Markdown: Tables, task lists, code blocks, and footnotes are supported.
• Interactive outline panel: Navigate long documents with an auto-scrolling table of contents.
• Local asset support: Render relative links and local images.
• Code block enhancements: Copy buttons and line numbers are built into fenced code blocks.

Native VS Code Experience

• Theme integration: The UI follows the active VS Code light, dark, or high-contrast theme.
• Configurable layout: Toggle headers, sticky toolbars, sticky headers, spacious cells, and hyperlink previews.
• In-editor feedback: Use Help & Feedback from the toolbar to report issues or suggestions.

Usage Guide

Working with Spreadsheets

1. Open any .xlsx, .csv, or .tsv file from the VS Code explorer.
2. Click a cell to select or edit it. CSV/TSV plain mode supports direct table editing.
3. Toggle styled mode when you need formatting for CSV/TSV, or work directly in styled mode for XLSX.
4. Select cells and use the toolbar to apply colors, borders, alignment, wrapping, fonts, or clear formatting.
5. Right-click a column header to sort or filter. Multiple column filters are combined.
6. Click Convert to convert between CSV, TSV, and XLSX.
7. Click the history icon to preview or restore previous file versions.

Unified Spreadsheet Architecture

The tabular editor is now merged into a single implementation:

• SpreadsheetEditorProvider handles XLSX/CSV/TSV file IO, virtual row requests, saves, style persistence, conversion, settings, and version history.
• spreadsheetWebview.ts handles the shared grid UI, selection, edit modes, toolbar actions, sorting, filtering, and virtualization.
• CSV/TSV plain mode writes directly to the delimited file.
• CSV/TSV styled mode stores formatting in local extension state and can carry that formatting into XLSX conversion.

Working with Markdown

1. Open a .md file and use Open in Preview from the editor title bar or command palette.
2. Edit Markdown in split view with synchronized scrolling.
3. Use Edit Preview to modify the document from the rendered view.

Settings & Configuration

Key settings include:

• Autosave (xlsxViewer.*.autoSave): Enable or disable automatic saving for supported file types.
• Sticky elements (xlsxViewer.*.stickyToolbar, xlsxViewer.*.stickyHeader): Keep toolbars and headers visible while scrolling.
• Spacious cells (xlsxViewer.*.spaciousCells): Increase cell padding for a more readable grid.
• Spreadsheet controls (xlsxViewer.xlsx.allowInteractiveControlsOutsideEditMode): Allow interactive controls outside table edit mode.
• Markdown layout (xlsxViewer.md.previewPosition, xlsxViewer.md.syncScroll): Control preview placement and synchronized scrolling.

Open VS Code Settings and search for xlsxViewer to see all options.

Installation

1. Open VS Code.
2. Go to the Extensions Marketplace with Ctrl+Shift+X.
3. Search for XLSX, CSV, TSV & Markdown Editor.
4. Click Install.

You can also install it from the command line:

code --install-extension muhammad-ahmad.xlsx-viewer

Feedback & Support

• In-app feedback: Use the Help & Feedback button in the extension toolbar.
• Marketplace review: Rate the extension on the VS Code Marketplace if it is useful for your workflow.
• GitHub: Submit issues, feature requests, or pull requests at Mahmadabid/XLSX-CSV-TSV-MARKDOWN-Editor-Vscode-Extension.

License

This project is licensed under the MIT License.
