CubeMX STM32 Adapter

Turn a CubeMX-generated STM32 project into one you can build, flash and debug from VS Code — without giving up the ability to regenerate it in CubeMX.

The extension never edits the part of the Makefile that CubeMX owns. Every change it makes lives in a separate cubemx-adapter.mk, pulled in by a single -include line appended to the end of the file. Regenerate in CubeMX as often as you like; if a regeneration drops that line, the extension notices and puts it back, settings intact.

What it does

• Parameterises the build. The toolchain directory, the OpenOCD binary, the debug probe, the OpenOCD scripts and the flash address all become variables you can override per invocation:

  make TOOLCHAIN_PATH=/opt/gcc-arm/bin/ flashload


• Adds flashing and debugging targets driven by OpenOCD: flashload, flashbin, erase, reset and openocd-server.

• Manages what gets compiled. Add or remove .c, .cpp and header files from the Files tab. CubeMX-owned sources are excluded rather than deleted from the CubeMX list, so regeneration keeps working. Headers contribute their directory to the include path.

• Compiles C++. Adding a .cpp file switches on the C++ rules, a configurable -std=, and the C++ runtime in LDFLAGS.

• Sets the build options from the Build & Debug tab: optimization level, debug information, C and C++ standard, -Wextra / -Werror, link-time optimization, floating point in printf, and free-text compiler and linker flags. Nothing rewrites a CubeMX line — the flags are appended, and GCC lets the last -O, -g and -std= win. Each one is an overridable variable, so a single build can still deviate:

  make ADAPTER_OPT=-O0 ADAPTER_LTO=0


• Sets up the debug session on the same tab: stop at main or at the reset vector, and an SWO console on ITM port 0 so printf can go out through the probe instead of a UART.

• Quietens the build log. A CubeMX build echoes several hundred characters of compiler command line per file, with the warnings that matter buried between them. Compact build log replaces each with one short line, so a build reads as its own progress:

    CC      Core/Src/main.c
    CC      Core/Src/stm32f4xx_it.c
    LD      build/sample-project.elf
     text    data     bss     dec     hex filename
     3420       4    1564    4988    137c build/sample-project.elf


  Warnings and errors still come through untouched, and make V=1 brings the full commands back for a single build. Running the build as a VS Code task additionally shows a progress notification counting the objects as they land.

• Shows the peripheral registers while you debug. The STM32 Peripherals view in the Run and Debug sidebar lists every peripheral from the SVD, each register decoded into its named bit fields. Values are re-read every time the core halts. Any writable register or field is edited in the row itself — click the value, type, press Enter; fields the SVD gives names to become a drop-down of those names. Escape or clicking away cancels without writing.

• Shows where the firmware's bytes went. The Firmware tab reads the linked .elf and reports how full each memory region from your linker script is, what the space is spent on, a per-section table and the largest functions and variables. Initialized data is charged to both flash and RAM, because its starting values are stored in the image and copied into RAM before main() runs — the one thing a single "size" number cannot tell you.

• Manages preprocessor defines from the Defines tab.

• Follows CubeMX on its own. Turn on Keep the project in sync with CubeMX on the Overview tab and the .ioc and Makefile are watched from then on. Every regeneration puts the -include hook back and rebuilds the .vscode files from the new include paths, defines and device — no refresh, no re-adapt. A regeneration that happened while VS Code was closed is picked up when the window opens. It re-applies the configuration already recorded in cubemx-adapter.mk; adapting a project the first time stays a deliberate step.

• Writes the .vscode configuration — c_cpp_properties.json, launch.json (Cortex Debug), tasks.json, settings.json and extensions.json — from what it found in your project. Configurations you wrote by hand, and the comments around them, are preserved.

Every operation backs up the files it touches and rolls all of them back if any step fails. Before the hook is added for the first time, your original Makefile is copied to Makefile.cubemx-adapter.bak.

Requirements

You need these on your machine; the extension does not install them.

They can be on PATH or pointed at through the settings below.

Getting started

1. Open the folder containing your CubeMX project — the one with the Makefile and the .ioc beside it.
2. Run CubeMX Adapter: Open Home from the Command Palette.
3. On the Overview tab, set the toolchain and OpenOCD paths, pick your probe, and press Adapt.
4. Build with make, flash with make flashload, debug with F5.

make adapter-info prints the configuration the generated makefile resolved to, which is the fastest way to check a path or a probe setting.

Settings

The build options are not settings — they live in cubemx-adapter.mk with the rest of the project's configuration, so they travel with the repository.

Commands

What ends up in your project

your-project/
├── Makefile                       # CubeMX's, plus a 3-line -include at the end
├── Makefile.cubemx-adapter.bak    # your original, kept from the first adapt
├── cubemx-adapter.mk              # everything the extension manages
└── .vscode/                       # IntelliSense, debugging and build tasks

cubemx-adapter.mk is regenerated on every change, so edit it through the extension rather than by hand. It is readable on purpose — each section explains what it does and why — so you can check exactly what was added to your build.

Notes and limits

• The file list shows files that exist on disk. Delete one outside the extension and the next refresh drops it from the build automatically; an entry that CubeMX still lists keeps its exclusion, because removing it would put a missing file straight back into the link.
• A project whose Makefile carries no CubeMX markers is still adapted, but the extension says so — verify the build before flashing.
• -Werror together with -Wextra fails the build on ST's own HAL and LL drivers, which do not compile warning-free. Those sources cannot be excluded, so either narrow the warnings with a -Wno-… in the extra compiler flags, or keep -Werror off.
• The SWO console needs the core clock to match what the target actually runs at; the probe derives the trace bit rate from it, so a stale value decodes to nothing.
• Writing a field in the register view writes the whole register back, because that is what the bus does. A write-1-to-clear flag that happened to be set when the register was read is cleared as a side effect.
• The register view reads a peripheral only when you expand it. A peripheral whose clock is off raises a bus fault instead of returning data; the affected rows say so rather than the view failing.
• Registers declared with <dim> or inside a <cluster> are left out of the view. Nothing in the bundled ST catalog uses either, but an SVD from elsewhere might, and placing such a register at a single address would make the view write to the wrong one.
• The Firmware tab needs a build to look at, and reports the last one — it does not build for you. Percentages need a MEMORY block in the linker script; a project without one gets absolute sizes instead of percentages.
• The symbol list shows names as the compiler wrote them, so C++ names appear mangled. A function that was inlined at every call site has no symbol and no entry, which is why the symbol sizes do not add up to the section total.

License

MIT — see the LICENSE file shipped with the extension.
