Rat — VS Code Extension

Run code cells in Markdown (.md) and Quarto (.qmd) files, powered by rat kernels.

Works on top of whatever Markdown / Quarto extension you already use — it only adds code execution.

Features

Feature	How
Run cells	`▶ Run` CodeLens above each cell, or `Ctrl+Enter`
Output cells	Results appear in ```output ``` blocks below
Plots	Matplotlib PNGs saved to `_assets/`, inserted as images
Execution queue	Cells queue up, execute in order
Pause / Cancel	Status bar toggle, `Ctrl+Shift+C` to cancel
Completions	Live from kernel — sees your DataFrames, imports, etc.
Hover	Rich inspection on hover (type, shape, docs, methods)
stdin prompts	`input()` pops a VS Code input box
Run Above / Run All	Execute cells from top, or the whole file
Rendered Markdown editor	Optional mrmd-powered editable Markdown view with rat-backed code cells

Prerequisites

The extension can install the rat CLI for you on first use on supported macOS, Linux, and Windows platforms. When you run a cell and rat is not found, choose Install Rat and the extension downloads the CLI into VS Code's extension storage.

Manual install is still supported:

# macOS / Linux
curl -fsSL https://runanything.dev/install.sh | sh

# Windows PowerShell
irm https://runanything.dev/install.ps1 | iex

rat install py    # or sh, r, ju, js

If you already have a custom binary, set rat.path or run Rat: Install CLI / Set rat.path from the prompt.

Install the extension

cd vscode-rat
npm install
npm run build

# Option A: development mode
# Open this folder in VS Code, press F5

# Option B: install globally
npm run package
code --install-extension rat-0.1.0.vsix

Usage

Open any .md or .qmd file with fenced code blocks:

```python
import pandas as pd
df = pd.read_csv("data.csv")
df.head()
```

Click ▶ Run above the cell. Output appears below:

```output
   region quarter  revenue
0   East      Q1    42000
1   West      Q1    38000

✓ 150ms | 2 vars
```

Rendered Markdown editor

For a more rendered, notebook-like editing surface, run Rat: Open Rat Markdown Editor or Markdown: Open Preview (Rat Markdown) from the Command Palette, or use Open With… → Rat Markdown on a Markdown/Quarto/R Markdown file.

This opens an editable mrmd-powered view (not VS Code's Markdown preview). Markdown renders inline, focused sections remain editable, and code cells execute through the same rat runtime resolution as the normal text editor.

If you want Ctrl+Shift+V / Cmd+Shift+V to open Rat Markdown instead of VS Code's built-in Markdown preview, run Rat: Use Rat Markdown for Ctrl+Shift+V Preview or set rat.replaceMarkdownPreviewShortcut to true. To make Rat Markdown the default editor for .md / .qmd / .rmd files in the current workspace, run Rat: Use Rat Markdown as Default Markdown Editor.

Keybindings

Key	Action
`Ctrl+Enter`	Run cell at cursor
`Shift+Enter`	Run cell and advance to next
`Ctrl+Shift+Enter`	Run all cells above (inclusive)
`Ctrl+Shift+C`	Cancel execution

Runtime resolution

The extension decides which rat kernel to use:

Front matter — per-file override:
```
---
rat:
  python: py-ml
---
```

VS Code setting — per-workspace:

{ "rat.runtimes": { "python": "py-ml" } }

Default — canonical language name (py, sh, r, …)

CWD is always the VS Code workspace folder.

Plots

When your code calls plt.show(), the figure is saved as a PNG in _assets/ (configurable via rat.assetsDir) and inserted as a Markdown image after the output block:

![plot](https://github.com/maximerivest/rat/raw/HEAD/_assets/fig-1234567890-0.png)

Settings

Setting	Default	Description
`rat.path`	`"rat"`	Path to the rat binary. Leave as `"rat"` to use an extension-managed install when present, otherwise PATH.
`rat.autoInstall`	`"prompt"`	Offer to install the rat CLI into VS Code extension storage when missing (`"prompt"`, `"never"`)
`rat.runtimes`	`{}`	Map fence language → named runtime
`rat.maxOutputLines`	`100`	Max lines in output cells (0 = unlimited)
`rat.assetsDir`	`"_assets"`	Plot image directory (relative to workspace)
`rat.replaceMarkdownPreviewShortcut`	`false`	Use Rat Markdown for `Ctrl+Shift+V` / `Cmd+Shift+V` in Markdown-like files

Commands

All available via the Command Palette (Ctrl+Shift+P):

Rat: Run Cell / Run Cell and Advance / Run Above / Run All Cells
Rat: Install CLI — download the rat binary into VS Code extension storage
Rat: Cancel Execution / Clear Queue / Pause / Resume Queue
Rat: Clear All Outputs — remove all ```output ``` blocks
Rat: Show Variables — open variable overview in a side panel
Rat: Stop Kernel / Restart Kernel
